Vicon NOVA V1400 Installation Manual

Digital control system
Hide thumbs Also See for NOVA V1400:

Advertisement

Quick Links

Download this manual
Warning: To reduce a risk of fire or electric shock, do not
expose this product to rain or moisture.
Vicon Industries Inc. does not warrant that the functions contained in this
equipment will meet your requirements or that the operation will be entirely
error free or perform precisely as described in the documentation. This
system has not been designed to be used in life-critical situations and
must not be used for this purpose.
Copyright © 2002 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TEL: 631-952-CCTV (2288) FAX: 631-951-CCTV (2288) TOLL FREE: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266)
UK: +44 (0) 1489 566300 INFOFAX: 800-287-1207 WEB: www.vicon-cctv.com
Vicon Part No. 8009-8007-00-01
XX007
V1400 Digital
Control System
Rev 702 Section 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the NOVA V1400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon NOVA V1400

Summary of Contents for Vicon NOVA V1400

  • Page 1 Warning: To reduce a risk of fire or electric shock, do not expose this product to rain or moisture. Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation.
  • Page 3 This page intentionally left blank.
  • Page 4 FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception.

  • Page 6: Table Of Contents

    Contents Introduction .........................1 V1400X-CI-M Control Interface...................2 V1400X-SV-M Supervisor....................3 V1400X-AC-M Alarm Control ....................5 V1400X-TC-M Titler CPU .....................6 V1400X-VC-M Video Switcher ....................6 Shipping Instructions ......................7 Contents • i XX007 Rev 702 NOVA V1400...
  • Page 7 RISK OF ELECTRIC SHOCK to the video product. Use only with a mounting accessory DO NOT OPEN recommended by Vicon, or sold with the video product. Any mounting of the video product should follow Vicon’s CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, instructions, and a mounting accessory recommended DO NOT REMOVE COVER (OR BACK).
  • Page 8 This prevents damage to the video product due replacement parts specified by Vicon or that have the to lightning and power-line surges. same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other 15.
  • Page 9 This page intentionally left blank. iv • Important Safeguards XX007 Rev 702 NOVA V1400...

  • Page 10: Introduction

    Introduction The NOVA V1400 is a microprocessor-based CCTV control system designed by Vicon to meet large system requirements. The system contains six card slots with connectors accessible from the rear. These cards are listed below, in card slot order from top to bottom, and shown in Figure 1.

  • Page 11: V1400X-Ci-M Control Interface

    V1400X-DL-1 Distribution Line Control (DL) units being used to connect multiple receivers to the system. Refer to Table 3 for pin connections. You must fabricate the cables using parts supplied in your accessory kit. Vicon recommends the cables shown in Table 2. Note that the cables must be shielded using the connector shells.

  • Page 12: V1400X-Sv-M Supervisor

    CPU supervises and coordinates the activities of the alarm, video switcher and other CPUs. The monitor connected to the Supervisor is used to view programming menus. To use all of the RS-232 commands available to the NOVA V1400, use connector J7 on the V1400X-SV-M Supervisor to connect a host computer to the system.
  • Page 13 Line Control. V1400X-DL-1 V1400X-DL-1 V1400X-DL-1 Up to 9 Up to 9 units per units per Rcvr. Rcvr. Dome Dome Keyboard Keyboard V1400X-DL-1 V1400X-DL-1 V1400X-DL-1 Figure 3 Connections to the V1400X-SV-M Supervisor 4 • V1400X-SV-M Supervisor XX007 Rev 702 NOVA V1400...

  • Page 14: V1400X-Ac-M Alarm Control

    RS-232 command code set. To use all of the RS-232 commands available to the NOVA V1400, use connector J7 on the V1400X-SV-M Supervisor CPU. The same two ports (J11 and J12 on the Alarm Control panel) can be used for alarm serial printers and host computers, so that if you have three host computers, you do not have a serial printer.

  • Page 15: V1400X-Tc-M Titler Cpu

    External CPU Control In connector Control In connector Matrix66 Matrix66 Monitors 1-64. Monitors 65-128. (More than one (More than one Matrix66 required) Matrix66 required.) Figure 6 Connections to V1400X-VC-M Video Switcher 6 • V1400X-TC-M Titler CPU XX007 Rev 702 NOVA V1400...

  • Page 16: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.
