Four-Sided Indoor Hockey
Installation and Maintenance Manual
Display Serial No. _________________
Display Model No. _________________
Date Installed ____________________
LED Scoreboards
®
All Sport
is a registered trademark of Daktronics, Inc.
Model Numbers
H-2024-9
H-2026-9
ED-11992
H-2031-9
ED-11992
Product 1152
Rev 3 – 29 June 2001
Copyright
2000-2001
Daktronics, Inc.
All rights reserved. While every precaution
has been taken in the preparation of this
manual,
the
publisher
responsibility for errors or omissions. No part
of this book covered by the copyrights
hereon may be reproduced or copied in any
form or by any means – graphic, electronic or
mechanical, including photocopying, taping
or information storage and retrieval systems
– without written permission of the publisher.
DAKTRONICS, INC.
DAKTRONICS, INC.
DAKTRONICS, INC.
DAKTRONICS, INC.
nd
P.O. Box 5128, 331 32
Ave. Brookings, SD 57006
Tel (605) 697-4036 or (877) 697-1115 Fax (605) 697-4444
www.daktronics.com
e-mail: helpdesk@daktronics.com
assumes
no
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Daktronics H-2024-9
Summary of Contents for Daktronics H-2024-9
- Page 1 Four-Sided Indoor Hockey LED Scoreboards Installation and Maintenance Manual ED-11992 ® All Sport is a registered trademark of Daktronics, Inc. Model Numbers H-2024-9 H-2026-9 H-2031-9 ED-11992 Product 1152 Rev 3 – 29 June 2001 Copyright 2000-2001 Daktronics, Inc. All rights reserved. While every precaution...
-
Page 3: Table Of Contents
Adjusting Horn Volume .....................3-3 Troubleshooting......................3-3 Replacement Parts List ....................3-4 Warranty and Maintenance Program ................3-5 3.10 Daktronics Exchange/Repair and Return Programs ...........3-6 Appendix A: Reference Drawings ...................A-1 Appendix B: Hoist/Suspension Systems ................B-1 Appendix C: Hockey Goal Lights ..................C-1 Table of Contents... -
Page 5: Introduction
Figure 1: Daktronics Drawing Label The serial and model number of a Daktronics scoreboard can be found on the identification label, which is located on the display. This label will be similar to the one shown in Figure 2. When calling... -
Page 6: Scoreboard Overview
Daktronics is not responsible for structures and suspension systems designed and installed by others. Scoreboard Overview The Daktronics four-sided hockey LED scoreboards are part of a family of scoreboard systems designed to offer simple installation, easy readability and reliability. Microprocessor control assures consistent operation and accuracy. -
Page 7: Mechanical And Electrical Installation
Each method has its own benefits and drawbacks. Refer to the publication SL3710 in Appendix B and call Daktronics for help in making the best choice for your installation. Note: Do not attach items to the scoreboard without prior approval. To properly review and approve a proposed attachment, Daktronics requires information on the size, weight and method by which the item will be attached to the scoreboard. -
Page 8: Electric Hoist Systems
Daktronics will inspect hoists installed by Daktronics. Daktronics will certify the scoreboard weight but will require a liability waiver signed by the customer before the scoreboard is shipped. Once the hoist is installed according to the specifications of the hoist manufacturer and the building engineer: 1. -
Page 9: Assembly Details
WARNING: •= Never ride in or work on or below the scoreboard while the hoist is powered up. Daktronics recommends having an audible horn warning to indicate that the hoist system is on. •= Never operate the hoist system during public events or when there are people below the scoreboard. -
Page 10: 10' Frame Assembly
h h h h Please review the following section completely before beginning assembly. 10' Frame Assembly Reference Drawing: Frame Assembly; 4-Sided ............Drawing A-107157 The 10' frame is shipped as two 5' x 10' sections (refer to Drawing A-107157). Note that each section has two corners with a brace across the corner and two corners without a brace. -
Page 11: Mounting An Optional Top Ad Panel Or Message Center
4. Join the two sections at their common top corner using a top bracket with ‚l bolts, washers and nuts as shown in Detail A on Drawing A-107887. Once the two sections are joined, they will not require additional support during assembly. 5. -
Page 12: Attaching Corner Shrouds
To connect the power and signal: 1. Connect the signal cables provided to the jacks in the back, matching the input and output numbers as labeled. Message board signal connections use the six-position plugs provided with the displays. Connect as shown in Drawing A-109746. 2. -
Page 13: Power
If the scoreboard is to be suspended from a hoist: 1. Start by attaching the cable sling to the four eyebolts in the corners of the frame. 2. Lower the hoist cables and attach them to the cable slings. 3. Raise the scoreboard a foot or two from the floor and level the scoreboard by adjusting the turnbuckles built into the slings. -
Page 14: Signal
Displays with team name message centers have four signal jacks. Refer to Drawing A-28124 for more information. Special Note to Users of Daktronics All Sport 4000 Series and Daktronics Pro Sport 6000 Control Consoles: Current standard models in the Daktronics scoring and timing display lines are configured at the manufacturing plant to operate with the All Sport Series 5000 Control Console. -
Page 15: Maintenance And Troubleshooting
Section 3: Maintenance and Troubleshooting Important Notes 1. Disconnect power before any repair or maintenance work is done on the scoreboard display! 2. Access to internal display electronics must be made only by qualified service personnel. 3. Disconnect power when the scoreboard display is not in use. Suspension System Periodic Inspection Static System The static mounted system should be inspected one year after initial installation and once every... -
Page 16: Segmentation And Digit Designation
Output connectors 1 through 16 each have nine pins. Pin 7 provides power to the digit or the indicators wired to that connector. The other eight pins provide switching connections. Special Note to Users of Daktronics All Sport 4000 Series and Daktronics Pro Sport 6000 Control Consoles: Current standard models in the Daktronics scoring and timing display lines are configured at the manufacturing plant to operate with the All Sport Series 5000 Control Console. -
Page 17: Schematics
If the standard electronic horn is not loud enough for your facility, a trumpet horn can provide significantly greater volume. On a four-sided scoreboard, a single trumpet horn may be mounted behind one of the scoreboard faces, pointing down at the playing area. Contact Daktronics for more information and pricing. -
Page 18: Replacement Parts List
Symptom/Condition Possible Cause Corrective Action Scoreboard will not Console not connected or poor Check signal cable. light. connection. No power to control console. Check power to console No power to the scoreboard. Check power to scoreboard Wrong code entered into All Sport Verify code to console Garbled display. -
Page 19: Warranty And Maintenance Program
Daktronics recommends that each customer keep an inventory of essential parts in case problems arise. If equipment fails, the customer's local service technician can get the equipment operational again with spare parts kept on hand. The failed components can then be shipped to Daktronics for parts exchange. -
Page 20: 3.10 Daktronics Exchange/Repair And Return Programs
Help Desk – (877) 605-1115 – if you have questions regarding the exchange program or any other Daktronics service. When you call the Daktronics Help Desk, a trained service technician will work with you to solve the equipment problem. You will work together to diagnose the problem and determine which exchange replacement part to ship. - Page 21 This is how to reach us: Mail: Customer Service Daktronics, Inc. P.O. Box 5128 331 32nd Avenue Brookings, SD 57006 Phone: Daktronics Help Desk: 1 (877) 605-1115 (toll free) or 1 (605) 697-4036 Fax: 1 (605) 697-4444 E-mail: helpdesk@daktronics.com Maintenance and Troubleshooting...
-
Page 23: Appendix A: Reference Drawings
Appendix A: Reference Drawings A Drawings Signal Connection, Installation ..............Drawing A-28124 Segmentation, 7 Segment Bar Digit.............Drawing A-38532 Rear View, A/S 5010 Connectors ..............Drawing A-102142 Frame Assembly; 4-Sided .................Drawing A-107157 Bottom 4-Side Ad Panel Mounting ..............Drawing A-107664 Top; 4-Side Ad Panel Mounting ..............Drawing A-107665 4 Sided Installation Details ................ -
Page 47: Appendix B: Hoist/Suspension Systems
Appendix B: Hoist/Suspension Systems Centerhung Scoreboard Hoist/Suspension Specifications ........... SL3610 Scoreboard Hoist Systems Defined ................SL3710 Hoist/Suspension Systems... - Page 49 Shall have security system that can permit only authorized and trained personnel to change the operating parameters of the system. Daktronics, Inc. ® P.O. Box 5128 331 32nd Avenue Brookings, SD 57006 Phone (605) 697-4300 or (888) 325-8766 Fax 697-4700 www.daktronics.com e-mail sales@daktronics.com Page 1 of 2 Copyright © 1999-2001 Daktronics, Inc. SL011801-3610...
- Page 50 Document must originate from the gear drive manufacturer. n Calculations on maximum transitional load to structure if overspeed brakes where activated. NOTE: These specifications are subject to change without notice. Please contact Daktronics for the most current revision of this document.
-
Page 53: Appendix C: Hockey Goal Lights
Appendix C: Hockey Goal Lights Goal Light Components................Drawing A-22927 Hockey Goal Lights...
