FIRETRACKER FT1020G3 - QUICK OPERATION
1 - TO SILENCE PANEL BUZZER:
Press
Button once to silence panel buzzer.
2 -TO SILENCE ALARM DEVICES:
Press
Button once to silence all alarm devices, Occupant Warning System
(OWS) or sounders and wait for a few seconds.
Pressing the
3 - TO RESET FIRE ALARM:
IMPORTANT: Alarm devices must be silenced before pressing "Reset" button.
Press and hold the
reset sequence. The system will now automatically reset all alarms.
Alarms may re-trigger in the system if the alarm condition is still present. Wait for 30 seconds
and try again.
4 - TO DISABLE (ISOLATE) AN ACTIVE ALARM:
IMPORTANT: Alarm devices must be silenced before pressing "Disable" button.
Button to isolate device in alarm (H2/B1) – system will now illuminate
Press
the
manual re-enabled via Menu H2/B1 button.
FT1020G3 Quick Operation Guide
Button again will cause the alarms to resound.
Button for 1 second until the Fire Alarm Panel starts its
LED. This zone / address point will remain disabled until
GUIDE
2022/01/06
Page 1 of 6

Advertisement

loading

Related Manuals for Brooks FIRETRACKER FT1020G3

Summary of Contents for Brooks FIRETRACKER FT1020G3

  • Page 1 2022/01/06 FIRETRACKER FT1020G3 - QUICK OPERATION GUIDE 1 - TO SILENCE PANEL BUZZER: Press Button once to silence panel buzzer. 2 -TO SILENCE ALARM DEVICES: Press Button once to silence all alarm devices, Occupant Warning System (OWS) or sounders and wait for a few seconds.
  • Page 2 2022/01/06 5 - TO DISPLAY MORE THAN ONE ALARM : When the more than one alarm are queued, red LEDs are illuminated. Press the Button to see the additional Alarms. 6 - TO MANUALLY DISABLE (ISOLATE) A ZONE OR ZONE ADDRESS FROM THE MENU: 1.
  • Page 3 2022/01/06 7 - MANUALLY RE-ENABLE A ZONE OR ZONE ADDRESS FROM THE MENU: 1. Press Menu Button 2. Select “Building Officer” Login then Key Enter Access Code. 3. Scroll to the Disable or re-enable menu (H2) by pressing Button/s then press Accept 4.
  • Page 4 2022/01/06 10 – TO ACKNOWLEDGE FAULT 1. Press Menu Button 2. Select “Building Officer” Login then Key Enter Access Code. 3. Scroll to the FAULT ACKNOWLEDGE menu (H6) by pressing Button/s then press to Accept 4. Scroll to check the list of faults by pressing Button/s then press to Accept 5.
  • Page 5 2022/01/06 FAULT: L-C mixed COM loop x, Control Unit xx Page: 66 FAULT: Loop unit, Technical number xxxxxx Page: 66 FAULT: Loop unit zone: xxx address: xx Page: 66 FAULT: Loop unit zone: xxx address: xx and zone: yyy address:yy Page: 66 FAULT: Low battery capacity, Control Unit xx Page: 66...
  • Page 6 2022/01/06 13 – OPERATION MANUAL FT1020G3 Rev 2.4 Scan QR code to Search instructions and other relevant operational procedures. Software download Restart Perform Monthly test (H1) Disable or re-enable (H2) Set Calendar and Clock (H3) Present System Status (H4) Service (H5) Acknowledge Faults (H6) Perform Zone Test (Test Mode) (H7) Maintenance (H8)
