Flip Mino2HD Quick Start Manual

Get Started

q u ic k s tart gu ide

Welcome to Flip MinoHD

Consult Safety Instructions Before Use.
1 Press power button to turn on. Camcorder setup
appears automatically when you first power on.
Note: Camcorder is shipped with a partially charged battery.

Setting Language

• Use + and – to select your language.

Setting Date

• Use + and – to adjust the current setting.
• Use < and > to select month/day/year.

Setting Time

• Use + and – to adjust the current setting.
• Use < and > to select hour/minute/am/pm.
Turning Off Tones
• Use < and > to toggle the tones on and off.
Turning Off Recording Light
• Use < and > to toggle the recording light on and off.
To Return to Camcorder Setup Later
Starting with the camcorder OFF:
1 Press power button to turn on.
2 When Flip Video
TM
hold record button until SET LANGUAGE appears.
Record and Play

Touch-Sensitive Buttons

Gently touch lighted icons with your finger to
activate the controls on the back panel.

Recording Videos

1 Press record button to start/stop.
2 Touch up/down buttons to zoom in/out.

Playing Videos

3 Touch play button to start/pause.
4 Touch left/right buttons to view previous/next.
Tip: Hold left/right during playback to rewind/fast-forward.
3

Deleting Videos

5 Touch delete button. Select YES to confirm.
Tip: Delete button is locked when you first power on.
To unlock, press and hold delete button.
4
1
TM
•
for setup
Hold
2
logo appears, press and
Save, Edit, and Share
FlipShare TM preloaded software makes
organizing, editing, and sharing video
incredibly simple. When you plug in your
camcorder, open FLIPVIDEO and launch
Setup FlipShare (PC) or Start FlipShare
TM TM
FlipShare TM Features
• Browse, play, and edit your videos.
• Save your videos to your computer.
• Make custom movies with music.
2
• Snap photos from your videos.
• Share your videos online or by email.
5 • Upload to Facebook TM , MySpace TM ,
YouTube TM , and others.
4
2
Click HELP inside FlipShare TM for
detailed instructions on all features.

Camcorder Features

8
4 5
7
1 6
1
14
3
2
1 Power Button Press to turn on/off.
2
Wrist Strap Hook Attach wrist strap, (included in package).
3 Tripod Mount Attach a tripod or a Flip Video TM accessory. Learn more at www.theflip.com/accessories.
4 Lens Wipe clean with a soft, dry cloth.
5 Recording Light Red light turns on during recording.
6 Microphone Built-in wide-range stereo microphone.
7 USB Latch Slide down to release USB arm.
8 USB Arm If space does not permit proper connection, use a USB "A"-type extension cable.
9 HDMI™ Mini Port Connect HDMI™ cable accessory to your HDTV. Learn more at www.theflip.com/accessories.
10
Screen Recording viewfinder/playback screen.
11 Play Button Touch to play/pause. Touch and hold to play all.
12 Delete Button Touch to delete. Touch and hold to lock/unlock the delete button.
13 Record Button Press and release to start/stop recording.
14 Up Button While Recording: Touch to zoom in. During Playback: Touch to increase volume.
15 While Recording: Touch to zoom out. During Playback: Touch to decrease volume.
Down Button
16 Left Button While Paused: Touch to skip to previous video. During Playback: Touch and hold to rewind.
17 Right Button While Paused: Touch to skip to next video. During Playback: Touch and hold to fast-forward.
View On HD Television
1 Power off camcorder and television.
2 Connect camcorder to television with
3 Power on camcorder and television.
(Mac).
4 Switch your television to VIDEO input.
My Movies
5 Touch play button to start/pause playback.
Camcorder
Computer
My Movies
Vacations
Anniversary
Birthday Party
Wedding
Concert
At The Beach
Our Dog
Baby Videos
Note: You can use any brand of HDMI™ Cable
that has an HDMI Connector (Type A) on one end
and HDMI Mini Connector (Type C) on the other end.

Connect to Computer

10 1 Slide USB latch down. USB arm flips up
automatically.
12
2 Connect USB arm to computer's USB port.
17
11 15 • Your camcorder will begin recharging and you
13
can install FlipShare TM
16
9
Recharge Battery
1 Slide USB latch down. USB arm flips up
automatically.
2 Connect USB arm to computer's USB port.
3 Recording light turns on to indicate charging.
When charged, the recording light turns off.
• The camcorder uses a sealed, rechargeable battery.
• Recharging a discharged battery takes about
three hours.
• The camcorder may remain connected to
your computer after it is fully charged, but
disconnecting it will help preserve the
battery's lifespan and performance.
• The optional Flip Video Power Adapter can
charge the battery in about two hours.
Note: Your computer must be powered on for the camcorder to charge.
optional HDMI TM Cable from Flip Video TM .
Learn more at www.theflip.com/accessories.
• Camcorder screen turns off when
connected to television.
• See television manual for instructions.
2
software on your computer.
3
2
Included In This Box
• Flip MinoHD Camcorder • Quickstart Guide
TM
• Wrist Strap • Warranty/Safety Info
• Soft Case
Flip Video TM Registration and Support
Go to www.theflip.com/support
Declaration of Conformity
Responsible Party: Cisco Systems, Inc.
30 Maiden Lane, 6th Floor, San Francisco, CA 94108
FCC Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Radio and TV Interference
This equipment has been tested and found to comply with the limits
for a Class B digital device in accordance with the specifications in Part 15
of FCC rules. These specifications are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the manufacturer's
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
The supplied interface cable must be used with the equipment in order to
comply with the limits for a digital device pursuant to Subpart B of Part 15
of FCC Rules.
CAUTION: Changes or modifications to this device not authorized by Cisco,
Inc. may void the user's authority to operate this device.
Canadian ICES-003 Statement:
This Class B digital apparatus complies with Canadian ICES-003.
© 2009 Cisco Systems, Inc. and/or its affiliates ("Cisco"). All rights
reserved. THE FLIP VIDEO LOGO, FLIP VIDEO, FLIP MINO HD, and
FLIPSHARE are trademarks of Cisco. Designed in the USA. Made in China.
For more information, visit www.theflip.com. Facebook, MySpace, and
YouTube are trademarks of their respective owners. Mac is a registered
trademark of Apple Inc. HDMI, the HDMI Logo and High-Definition
Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
600-0130-100
