Welcome to the family. Let's get started.
MPS 250S
XL PROPANE SMOKER
Manual applies to the following model number(s)
MB20053418, MB20053518, MB20053618
Your model number
Mfg. Date - Serial Number
These numbers are located on the rating label of the unit.
IMPORTANT
Please record this information immediately and keep in a safe place for future use.
Manual Code: 9805180013 180830-GSB
AGA certificate No. 8687 G
Master it. Masterbuilt.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MB20053418 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Masterbuilt MB20053418

Summary of Contents for Masterbuilt MB20053418

  • Page 1 Welcome to the family. Let’s get started. MPS 250S XL PROPANE SMOKER Manual applies to the following model number(s) MB20053418, MB20053518, MB20053618 Your model number Mfg. Date - Serial Number These numbers are located on the rating label of the unit.

  • Page 2: Carbon Monoxide Hazard

    CARBON MONOXIDE DANGER HAZARD IF YOU SMELL GAS: Burning wood chips gives off carbon monoxide, which has no odor and can cause death. 1. Shut off gas to the appliance. DO NOT burn wood chips inside homes, 2. Extinguish any open flame. vehicles, tents, 3.

  • Page 3: General Warnings And Safety Information

    • Never use unit for anything other than its intended use. This unit is NOT for commercial use. • Accessory attachments not supplied by Masterbuilt Manufacturing, LLC are NOT recommended and may cause injury. • Use of alcohol, prescription or non-prescription drugs may impair user’s ability to properly assemble or safely operate unit.
  • Page 4 GENERAL WARNINGS AND SAFETY INFORMATION WARNINGS & IMPORTANT SAFEGUARDS CONTINUED FROM PAGE 3 • LP gas cylinder being used must be constructed and marked in accordance with specifications for LP gas cylinders of the US Department of Transportation (DOT) or the Standard for Cylinders, Spheres and Tubes for the Transportation for Dangerous Goods, CAN/CSA-B339.
  • Page 5 • Store only when fire is completely out and all surfaces are cold. • When not in frequent use and using a cover, remember to check your smoker periodically to avoid possible rust and corrosion due to moisture buildup. CHECK OUT MASTERBUILT.COM FOR MORE TIPS AND RECIPE VIDEOS.
  • Page 6 WARNING PERFORM “SOAPY WATER TEST” BEFORE EACH USE. SEE “SOAPY WATER TEST” SECTION IN MANUAL. EXTINGUISH ALL OPEN FLAMES BEFORE CONNECTING REGULATOR TO GAS CYLINDER. TURN GAS OFF AFTER EACH USE. SOAPY WATER TEST WARNINGS & PROCEDURES WARNINGS • Soapy water test MUST be performed each time gas cylinder is connected to burner/hose or each time it is used.

  • Page 7: Ignition Instructions

    IGNITION INSTRUCTIONS REGULATOR, BURNER AND GAS VALVE CONNECTION & OPERATION COUNTER • Inspect hose before each use. If there are signs of abrasion, wear, cuts, or leaks, the hose must CLOCKWISE CLOCKWISE be replaced. DO NOT USE. • Inspect burner before each use. Check burner and burner venturi tube for insects and insect Fig.

  • Page 8: Troubleshooting Guide

    MATCH LIGHT INSTRUCTIONS 1. Read all instructions and warnings before lighting. 2. Check gas control valve and gas cylinder valve to be certain it is in OFF position before connecting to gas cylinder. 3. Perform soapy water test before each use. 4.
  • Page 9 * Also see Troubleshooting solutions: “Causes” Low or No Flow/Vapor Lock/Excess flow below. TROUBLESHOOTING SOLUTIONS: “CAUSES” LOW OR NO FLOW/VAPOR LOCK/EXCESS FLOW Symptom Cause Possible Solution Burner doesn’t light after pressing Low/no gas flow Turn burner control knobs to “OFF” position. ignitor button Turn gas cylinder valve knob to OFF.

  • Page 10: Parts List

    PARTS LIST Actual product may differ from picture shown. HARDWARE LIST M6x12 #10x3/8 M6x30 Qty-45 Qty-6 Qty-4 Qty-3 M4x10 M5x10 Qty-16 Qty-4 Qty-4 Qty-4 Wing Nut Wing Screw (packed with temperature gauge) (pre-assembled to tank retainer) Qty-1 Qty-1...
  • Page 11 PARTS LIST DESCRIPTION Smoking Rack Support Large Smoker Door w/window Body Handle (rear) Smoking Rack Large Door Handle Small Door Handle Small Smoker Door Smoker Body Water Bowl Holder Water Bowl Air Damper (round) Temperature Gauge Propane Tank Retention Bracket Wood Chip Tray w/Lid Grease Tray Grease Tray Support...
  • Page 12 ASSEMBLY...
  • Page 13 ASSEMBLY PUSH HEAT SHIELD ONTO BURNER BOX...
  • Page 14 ASSEMBLY Align venturis over valve orifices and attach ignition wires to piezo ignitor on control panel. Attach flame sensor connectors to valves. Flame Valve Sensor Orifice Venturi Piezo Ignitor Flame Sensor Ignition Wires Venturi Valve Venturi Orifice Short Long...
  • Page 15 ASSEMBLY Take out racks to clean after each use.
  • Page 16 ASSEMBLY Chip tray placement per burner(s) used. Left Right Both...
  • Page 17 ASSEMBLY Take out grease trays to clean after each use.
  • Page 18 GASMATE BARBEQUES AND ACCESSORIES PRODUCT RANGE SITRO GROUP AUSTRALIA (S.G.A.) warrants the purchaser of this product against defects in workmanship and materials for the following periods from the date of purchase: For domestic use, this table applies:- Stainless steel components 5 years (surface oxidization excluded) Enamel components 5 years (chips excluded)
  • Page 20 Rest assured, we’re here to help. Do not return to place of purchase. For any queries or assistance call Customer Service (Australia Only) 1300 174 876 Hours of operation: Monday to Friday 8am - 5pm EST Keep your purchase receipt. This will be required to make any claims under the 12 month warranty.
