Distributed By:
STORAGE FREEZERS
Models SCF694
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND
Model No. ________________________
Serial No. _________________________
COMMERCIAL
SCF1094 SCF1095S
SCF1494 SCF1495S
SCF1694 SCF1695S
SCF1894 SCF1895S
Instruction Manual
OPERATING INSTRUCTIONS.
Write Model Number and Serial Number
(on rating label) here:
Felix Storch, Inc.
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
SCF695S
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elcold Summit SCF694
Summary of Contents for Elcold Summit SCF694
- Page 1 Distributed By: Felix Storch, Inc. 770 Garrison Avenue Bronx, NY 10474 www.summitappliance.com COMMERCIAL STORAGE FREEZERS Models SCF694 SCF695S SCF1094 SCF1095S SCF1494 SCF1495S SCF1694 SCF1695S SCF1894 SCF1895S Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Model Number and Serial Number (on rating label) here: Model No.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety ............Important Safeguards ..........Location of Parts, Temperature Control ....Technical Information ..........Installation Instructions ..........8-10 Moving and Installing Your Appliance ..... Attaching the Casters ..........Electrical Connection ..........9-10 Extension Cord ............Operating Your Appliance .......... 10-12 Turning On the Freezer ........... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 • Replace all panels before operating. • It is recommended that a separate circuit serving only your appliance be provided. Use receptacles that cannot be turned off by a switch or pull chain. • Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or explosion.
- Page 5 • Make certain that the pipes are not pinched, kinked or damaged during installation. • Check for leaks after connection. • To avoid damage, never place hot or heavy items on top of the freezer. • Never allow children to operate, play with or crawl inside the appliance.
-
Page 6: Location Of Parts, Temperature Control
LOCATION OF PARTS Handle Sliding glass doors Lock Storage basket Drain hole Dial thermostat Ventilation slots Casters (4) Power cord Temperature Control The temperature inside the freezer is controlled by a dial thermostat with settings ranging from 0 (Off) to 7 (coldest). A moderate setting (from 3 to 5) is recommended for most purposes. -
Page 7: Technical Information
TECHNICAL INFORMATION Model SCF694/695S SCF1094/1095S Installation Free-standing Free-standing Capacity 7.4 ft /5.8ft3 10.7 ft /9.4ft Temp. Range -5°F to +5°F -5°F to +5°F Electrical Input 115/120V AC 115/120V AC 60Hz 60Hz Refrigerant R134a R134a Unit Weight 154lbs 187 lbs Unit 28.5"W x 41.5"W x Dimensions... -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS This appliance is meant for free-standing installation; it should not be built-in. Do not store or install the appliance outdoors. This appliance is designed for the storage of frozen items. Do not use it to store medicine or other medical products. Moving and Installing Your Appliance •... -
Page 9: Attaching The Casters
Attaching the Casters You will find a carton of four (4) casters packed inside the unit. The casters can be slid into position in the four slotted areas on the bottom of the freezer. Electrical Connection Improper use of the grounded plug can result in the risk of electrical shock. -
Page 10: Extension Cord
obligation to have it replaced with a properly grounded 3-prong wall outlet. To prevent accidental injury, the cord should be secured behind the appliance and not left exposed or dangling. The appliance should always be plugged into an exclusive, properly grounded wall outlet which has a voltage rating that matches the rating label on the appliance. -
Page 11: Storing Items In The Unit
CAUTION • If power is disconnected, do not try to restart the freezer within 5 minutes of the power disconnect. • Do not make holes through the walls of the unit in order to mount other items. • Avoid splashing water on the unit. •... -
Page 12: Lock And Keys
Lock and Keys Your unit is provided with a lock and set of keys. The keys are located inside the plastic bag that contains the Instruction Manual. Insert the key into the lock and turn it clockwise to unlock the door. -
Page 13: Power Failure
• Failure to unplug the appliance during cleaning could result in electrical shock or other personal injury. • Young children and infirm persons should not operate the appliance without supervision. • Young children should be warned not to play with the appliance. Power Failure Most power failures are corrected within a few hours and should not affect the temperature of your freezer if you minimize the number of... -
Page 14: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. PROBLEM POSSIBLE CAUSE SOLUTION Temperature control is set Adjust temperature control. - Page 15 If the freezer develops problems that cannot be solved by referring to the chart above, do not try to dismantle the unit yourself. This could void your warranty. Instead, refer to an authorized service center or call SUMMIT Customer Service at 1-800-932-4267.
-
Page 16: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
