INSTRUCTION MANUAL
BEVERAGE COOLER MODEL: RAÇO - 16SE01 A0
- Please read these instructions carefully before operating this appliance.
- Check if local voltage corresponds to the unit label.

SAFETY

- This appliance is designed to operate on alternative current (A.C.) Only
- DO NOT CONNECT TO DIRECT CURRENT (D.C.).
- Care should be taken when operating this appliance, as HOT SURFACES may cause
burns.
- DO NOT SHAKE OR TURN UPSIDE DOWN because it can damage the refrigeration
system.
- When not in use for long period unplug the appliance.

OPERATION

- Install the equipment on a counter 50" (1.2m) height (at least).
- Find a place well ventilated, protected from solar rays and away from heat sources.
- Plug the equipment without the product container and turn on. After some minutes you will
see a thin ice layer on the evaporator (drawing nº 18) that will melt a short time later and this
cycle will repeat.
- Replace the product container and the equipment is ready to use.
- As a "tip" fill in the product container with a already cooled product to get a best
performance.
- Obs.: The temperature is controlled by a thermostat that keeps the liquid around 41ºF
(5ºC).
- Remember that when positioning the jet tube( nº 6), observe that the hole in the tube must
be directed to evaporator.

CLEANING

- For your safety unplug the equipment before any maintenance service.
Body: Use only a damp cloth or sponge dipped in soapy water.
Product Container: Use only water and neutral soap. Avoid abrasive materials.
Product Dispenser: Use only water and neutral soap after disassemble (see drawing nº
7 and 46).
RAÇO-16SE01 A0
