- Page 1 ARNSTEAD HERMOLYNE ORPORATION Type D0800 Bantam Cartridge Holder OPERATION MANUAL AND PARTS LIST SERIES 494 Model # Voltage D0800 D0805 60119 • 3/12/98...
-
Page 2: Table Of Contents
Table of Contents Safety Information .............................. 3 Alert Signals ..............................3 Warnings ................................3 General Specifications ............................4 Cartridge Specifications ........................... 5 High Capacity ..............................5 Ultrapure (Mixed Resin) ..........................5 Installation ................................6 Unpacking ................................ 6 Choosing a Site ..............................6 Mounting ................................ -
Page 3: Safety Information
Safety Information Alert Signals Important Information This manual contains important operating and safety information. The user must carefully read and understand the contents of this Warning manual prior to the use of this equipment. Warnings alert you to a possibility of personal injury. Safety Information Caution Cautions alert you to a... -
Page 4: General Specifications
General Specifications Note Pure water exposed to the ° 9 ° 0 atmosphere will absorb CO This will lower resistivity and pH. " 4 " 4 " 4 " 6 " 8 " 2 Using average tap water. Delivers deionized water in continuous flow at atmospheric pressure. Although the cartridge holder can be operated at inlet pressures up to 700 kPa (100 psig), the cartridge holder cannot without any back pressure. -
Page 5: Cartridge Specifications
Cartridge Specifications High Capacity This cartridge (catalog no. D0803) has the capacity to remove 113 grams (1740 grains) of dissolved ionized impurities (as NaCl) to an endpoint of 50,000 ohm-cm. This high capacity configuration produces water with an electrical resistivity of about 175,000 ohm-cm. Each cartridge will purify about 660 liters (175 gallons) of water containing 170 mg/liter (10 grains/gallon, as NaCl). -
Page 6: Installation
Installation Unpacking Unpack the Bantam Holder carefully so that none of the parts will be marred or damaged. Ensure that any loose parts — such as tubing and fittings for the plumbing service connections — are not discarded with the packing materials. Choosing a Site Move the Bantam Holder to the desired operating location. - Page 7 NSTALLATION 1/8" NPT x 1/4" OD straight connector provided to connect the Bantam Holder inlet to the raw water supply. If the raw water supply service connection is not 3/8" NPT, use another brass fitting as required. 3. Cut a piece of tubing from the 2.1m (7') of 1/4"...
-
Page 8: Elbow-Tubing Assembly
NSTALLATION Caution 6. Connect the remaining tubing to the Do not restrict the tubing and run plumbing service connection marked the tubing in an upward direction “drain” and extend the tubing into the from the top of the unit. Any sink to allow the holder to be drained in restriction on the outlet can result in an unrestricted manner. -
Page 9: Cartridge Installation
NSTALLATION Cartridge Installation Install a cartridge in the holder as follows: 1. Install the large o-ring (part no. 06419) on the cartridge holder. A small o-ring should be on the bottom of the cell. The large o-ring is packaged separately during shipment. 2. -
Page 10: Operation
Operation Operate the Bantam Holder as follows: 1. Close the drain valve. Caution Do not exceed a flow rate of 38 2. Open the inlet valve one to two turns LPH (10 GPH). Leakage will occur if and allow a couple of minutes for the this flow is exceeded. -
Page 11: Maintenance And Servicing
Maintenance and Servicing Maintenance of the Bantam Holder should be minimal, involving cartridge replacement and Warning o-ring seal replacement. Also, an occasional To avoid electrical shock, always calibration check of the purity meter might be disconnect the power supply necessary. Cartridges should be stored away before maintenance and from heat. -
Page 12: Replacement Parts List
Exploded View... - Page 13 Replacement Parts Model Type: D0800 Product Name: Bantam Cartridge Holder Series Number: " 8 " 4 , l l " 4 " 8 r t r r t r y t i v i t...
-
Page 14: Ordering Procedures
Ordering Procedures Please refer to the Specification Plate for the complete model number, serial number, and series number when requesting service, replacement parts or in any correspondence concerning this unit. All parts listed herein may be ordered from the Barnstead Thermolyne dealer from whom you purchased this unit or can be obtained promptly from the factory. -
Page 16: Warranty
One Year Limited Warranty Barnstead|Thermolyne Corporation warrants that if a product manufactured by Barnstead|Thermolyne and sold by it within the continental United States or Canada proves to be defective in material or construction, it will provide you, without charge, for a period of ninety (90) days, the labor, and a period of one (1) year, the parts, necessary to remedy any such defect.
