- Page 1 DIAMOND HARROW HAR60S ASSEMBLY INSTRUCTIONS FOR MODELS: • HAR60S PURCHASE DATE MODEL NO. DEALER...
- Page 2 PARTS LIST *Recommended tools: 22 mm & 16 mm spanners A. 2x - 2 Hole Beam or 7/8” and 5/8” spanners B. 2x – 3 Hole Beam C. 4x – 5 Hole Beam D. 5x – 5 Hole Beam (Short) E.
- Page 3 Parts Instructions Fasten Part F to smaller hole using Part G, then using Part H 2. 1x Part F hold the other side in place, as shown. 1x Part G 1x Part H Ensure that Part G and F are assembled correctly, as shown in close-up photo.
- Page 4 Parts Instructions Fasten Part C using H parts to assembly, as shown 4. 1x Part C 2x part H Parts Instructions Fasten Part D using H parts to assembly, as shown 5. 1x Part D 2x part H HAR60S ASSEMBLY INSTRUCTIONS...
- Page 5 Parts Instructions Fasten Part C using H parts to assembly, as shown 6. 1x Part C 3x Part H Instructions Parts Fasten Part C using H parts to assembly, as shown 7. 1x Part C 3x Part H HAR60S ASSEMBLY INSTRUCTIONS...
- Page 6 Parts Instructions Fasten Part D using H parts to assembly, as shown 8. 1x Part D 3x Part H Parts Instructions Fasten Part D using H parts to assembly, as shown 9. 1x Part D 3x Part H HAR60S ASSEMBLY INSTRUCTIONS...
- Page 7 Instructions Parts Fasten Part F to smaller hole using Part G, then using Part H 10. 1x Part F hold the other side in place, as shown. 1x Part G 1x Part H Ensure that Part G and F are assembled correctly, as shown in close-up photo.
- Page 8 Parts Instructions Fasten Part B using H parts to assembly, as shown 12. 1x Part B 3x Part H Parts Instructions Fasten Part F using H parts to assembly, as shown 13. 1x Part A 2x Part H HAR60S ASSEMBLY INSTRUCTIONS...
- Page 9 Parts Instructions Loosen and remove nuts shown, then add part E to assembly 14. 1x Part E as shown. Tighten nuts to assembly, once part E is added Parts Instructions Loosen and remove nuts shown, then add part E to assembly 15.
