Before You Begin:
Recommended Tools:
Note on Electric Drills:
Note on Roof Panel Spacing:
Note on Caulk and Sealing:
Note on Cutting and Drilling:
If you have any questions during installation, please call us at 1-888-442-2928
1) Please read all instructions and notes carefully. Check the Parts List or Bill of Materials for
any missing parts and gather necessary tools. To prevent scratching of painted materials,
place on a tarp, paper, or other protective material.
2) You may be required to obtain a building permit for this structure from your local building
authority. Contact your local building department for details.
3) Note that this shade structure is not designed to carry additional loads such as hanging
heavy plants, swings, people, or other objects.
Saftey Glasses, Tape Measure, Carpenters Level, Framing Square, Hex Head Nut Drivers,
Chalk Line, Electric Drill w/ Bits, Pliers, Metal Hack Saw, Silicone Caulking,
Regular and Phillips Screw Drivers
We recommend lowering the speed of your drill during this installation. Installing Tek screws
at a high rpm may cause the Tek screws to become damaged or break during installation.
The center to center of roof panel lock spacing MUST be maintained as the panels are
installed. If this is not done, problems may not show up until towards the end of installation
when parts may appear to be cut too short or too long. If this happens, go back and check the
spacing and re-set if necessary. The spacing is 24" for the W shaped panel, 10" for the
V shaped panel, and 8" or 18" for the flat panel.
We strongly recommend using a high grade sealant, such as our 100% Silicone Caulk and Sealant.
Caulking should be applied uniformly without skips. A poor caulking job can cause leaks.
Cutting and drilling will cause metal shavings. These shavings must be carefully removed by
sweeping or brushing. If this is not done, the metal shavings will quickly rust and stain the
surface finish.
COLONIAL SHELTER
ASSEMBLY INSTRUCTIONS
Rev. - 3/01/2012
Advertisement
Table of Contents
Related Manuals for AMERICANA OUTDOORS COLONIAL
Summary of Contents for AMERICANA OUTDOORS COLONIAL
- Page 1 COLONIAL SHELTER ASSEMBLY INSTRUCTIONS Before You Begin: 1) Please read all instructions and notes carefully. Check the Parts List or Bill of Materials for any missing parts and gather necessary tools. To prevent scratching of painted materials, place on a tarp, paper, or other protective material.
- Page 2 STEP 1 -Layout footings according to the plans provided. Pour and reinforce concrete to satisfy local building codes. Anchor bolts are not included and must be furnished at the time of installation. Consult local building codes for requirements. -Anchor (2) base angles at each post location according to the plans provided. Attach a post to each pair of base angles using (2) 5/8"...
- Page 3 STEP 2 -Attach a rafter between the (2) angle brackets at each post using (2) 5/8" x 1-1/2" bolts per rafter (see Fig. 2-1). NOTE: The flat face of the rafters at both ends of the shelter should face OUT. -Attach (2) angle brackets at the peak of each rafter using (2) 5/8"...
- Page 4 STEP 3 -Attach the J-channel to the gable chord at both ends of the shelter using #12 x 1-1/4" HWH #5 Tek screws at 24" on center. -Position the gable fill panels in the J-channel with the backs agains the flat side of the rafters. Attach the panels to the J-channel using #8 x 3/4"...
- Page 5 STEP 4 -After the gutter is installed on both sides of the shelter, position the fascia trim so that the end is flush with the gutter. Attach the fascia trim to the gutter by caulking and installing a corner cap using #8 x 3/4" HWH #2 Tek screws (see Fig. 4-1). -Attach the top lip of the fascia to the roof panel using #8 x 3/4"...
