JL Audio 12W3v3-2 Owner's Manual page 3

S UBWOOF ER
Vo lu me
(net i nt. )
1. 250 f t³
1 2 W3 v 3 -2
35. 4 l i tres
1. 125 f t³
1 2 W3 v 3 -4
31. 8 l i tres
1. 250 f t³
1 2 W3 v 3 -8
35. 4 l i tres
S UBWOOF ER
Vo lu me
(net i nt. )
1. 75 f t³
1 2 W3 v 3 -2
49. 6 l i tres
1. 75 f t³
1 2 W3 v 3 -4
49. 6 l i tres
1. 75 f t³
1 2 W3 v 3 -8
49. 6 l i tres
• The enclosure recommendations listed are external
dimensions which assume the use of 3/ 4" (19mm)
thick material. If you are using 5/ 8" (16mm) thick
material, subtract 1/ 4" (6. 5mm) from each dimension.
Do not use any material with a thickness of less than
5/ 8" (16mm) as this may compromise the rigidity of
the enclosure.
• Al l encl osure vol umes l i sted are net i nternal vol umes!
Box volume displacement, port displacement and
brace displacement must be added to obtain the final
gross internal volume.All enclosure dimensions listed
have already taken this into account.
• When using two subwoofers in a common
enclosure simply doubl e the required volume and,
in the case of a ported enclosure,use two ti mes the
recommended port(s).
• We recommend the use of this speaker in a bi -
ampl i f i ed system using high-quality satellite speakers
and amplifiers. We do not recommend the use of
thissubwoofer with apassi ve crossover (coi l ), as thi s
type of device will adversely affect performance.
JL A U D I O 12W3v3- 2/ 12W3v3- 4/ 12W3v3- 8
Al l speci f i cati ons are subj ect to change wi thout noti ce.
RECOMMENDED S EAL ED ENCL OS URES
Ex t e r n a l Dime n s io n s
(Wi dth x Hei ght x Depth)
23 i n. x 14 i n. x 10 i n.
584 mm x 356 mm x 254 mm
23 i n. x 14 i n. x 9. 25 i n.
584 mm x 356 mm x 235 mm
23 i n. x 14 i n. x 10 i n.
584 mm x 356 mm x 254 mm
RECOMMENDED PORTED ENCL OS URES
En c lo s u r e Ex t e r n a l Dime n s io n s
(Wi dth x Hei ght x Depth)
29 i n. x 14 i n. x 12. 625 i n.
737 mm x 356 mm x 321 mm
29 i n. x 14 i n. x 12. 625 i n.
737 mm x 356 mm x 321 mm
29 i n. x 14 i n. x 12. 625 i n.
737 mm x 356 mm x 321 mm
Prol onged exposure to sound pressure l evel s i n excess of 100dB can cause permanent heari ng l oss. Thi s hi gh-perf ormance
speaker can exceed thi s l evel . Pl ease exerci se restrai nt i n i ts operati on i n order to preserve your abi l i ty to enj oy i ts f i del i ty.
When i nstal l i ng a subwoof er i n your vehi cl e, i t i s extremel y i mportant to secure the encl osure f i rml y. We recommend
bol ti ng the encl osure through the metal of the f l oorpan or the f rame of the vehi cl e wi th l arge di ameter washers f or
rei nf orcement. I f an encl osure i s not f i rml y attached, i t can become a proj ecti l e i n a col l i si on. Thi s i s parti cul arl y i mportant
i n a hatchback, stati on wagon, sports uti l i ty vehi cl e, or van.
F 3 F c
Qt c
(Hz) (Hz)
41. 8 50. 4 0. 96
43. 7 50. 2 0. 83
41. 5 50. 5 0. 91
S lo t Po r t S p e c s Re c . S lo t Po r t In t e r n a l Dime n s io n s
Sl ot Area x Sl ot Lengt h S l ot Wi dt h x S l ot Hei ght x S l ot L ength
17. 1875 sq. i n. x 26. 125 i n.
110.9 sq.cm.x 664 mm
17. 1875 sq. i n. x 26. 125 i n.
110.9 sq.cm.x 664 mm
17. 1875 sq. i n. x 26. 125 i n.
110.9 sq.cm.x 664 mm
1. 375 i n. x 12. 5 i n. x 26. 125 i n.
35 mm x 318 mm x 664 mm
1. 375 i n. x 12. 5 i n. x 26. 125 i n.
35 mm x 318 mm x 664 mm
1. 375 i n. x 12. 5 i n. x 26. 125 i n.
35 mm x 318 mm x 664 mm
" EL " ( Po r t Ex t e n s io n L e n g t h )
1 2 W3 v 3 -2 : 13. 5 i n. (343 mm)
1 2 W3 v 3 -4 : 13. 5 i n. (343 mm)
1 2 W3 v 3 -8 : 13. 5 i n. (343 mm)
Tu n e t o : F 3
(Hz) (Hz)
30. 0 36. 0
30. 0 35. 0
30. 0 35. 0
3
