July 2022
SP30 FAQs
What is the SP30 handheld?
The Spectra Geospatial SP30 handheld is an ultra-rugged, all-in-one smartphone and high
accuracy GNSS data collector. It features an array of powerful features such as a bright 6-inch
display, 2.2 GHz processor, Android™ 10 operating system, and large memory and storage.
For high-accuracy positioning virtually anywhere in the world, the SP30 supports L band and
can connect to Trimble Field point RTX service. The SP30 handheld is completely
customizable with Google Mobile Services and is compatible with MobileMapper Field and
office software, Trimble Penmap® for Android software, as well as third-party Android
compatible apps such as Esri® Collector for ArcGIS®. With an enhanced all-day battery, 4G
LTE connectivity, Bluetooth® 4.1, and durable exterior, this next generation SP30 handheld is a
powerful, comprehensive solution for reliable communication and data collection.
What are the key features of the SP30 handheld?
High accuracy GNSS receiver, 6-inch touch screen, two cameras (front and back), up-to-date
connectivity, dependable ruggedness, high processing power, high capacity replaceable
battery, Android 10 operating system.
This document is for informational purposes only and is not a legally binding agreement or offer. Spectra Geospatial makes no warranties
and assumes no obligations or liabilities hereunder.
© 2022, Trimble Inc. All rights reserved. Spectra Geospatial is a Division of Trimble Inc. Spectra Geospatial and the Spectra Geospatial logo
are trademarks of Trimble Inc. or its subsidiaries. All other trademarks are the property of their respective owners.
www.spectrageospatial.com
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spectra Geospatial SP30
Summary of Contents for Spectra Geospatial SP30
- Page 1 © 2022, Trimble Inc. All rights reserved. Spectra Geospatial is a Division of Trimble Inc. Spectra Geospatial and the Spectra Geospatial logo are trademarks of Trimble Inc. or its subsidiaries. All other trademarks are the property of their respective owners.
- Page 2 Operating System What operating systems does SP30 handheld support? The SP30 handheld is powered by the Android 10 operating system. This is an open and fully GMS-certified operating system enabling you to run any application, for example, Spectra Geospatial MobileMapper Field, and third party applications such as Esri collector for ArcGIS, etc.
- Page 3 The upgrade will be done automatically over the air. Can the SP30 Android version be upgraded? SP30 is running Android 10.0 and can be upgraded to a new Android 10 version via GOTA (automatic upgrade over the air). SP30 will not be upgradable to Android 11.
- Page 4 What is the SGIM application? Spectra Geospatial Installation Manager (SGIM) is preinstalled on SP30 and will replace GNSS loader which was used for SP20. It will be used to install SP30 configurations and upgrade the GNSS firmware if needed, ● Install Accuracy configuration on SP30. Start Spectra Geospatial Installation Manager and select "Download license".
- Page 5 Google Play Store. What size is the SIM card? The SP30 handheld requires a NanoSIM. SP30 has two slots for Sim cards. How do I change the SD and SIM card? The SIM card and SD card slots are located underneath the battery cover on the back of the device.
- Page 6 Do I need a screen protector? Yes. Spectra Geospatial strongly recommends using a screen protector. One screen protector is installed on SP30 handheld out of the box, you just need to remove the protection mask as shown below One more screen protector is also provided in the SP30 box as a spare.
- Page 7 Use of polarized glasses with SP30 When using polarized glasses with SP30 you can experience difficulties to have clear vision of the display. In that case you can try to rotate the SP30 in order to improve visibility of the SP30 display.
- Page 8 Which are the cellular networks supported by SP30? It is difficult for us to give a detailed list of supported networks but SP30 will run on most of the LTE cellular networks worldwide. Note that SP30 is not specifically PTCRB certified even if the cellular component is the same as MobileMapper 60 which is PTCRB certified.
- Page 9 Battery removal There is no hot-swap capability on the SP30 so removing the battery will irremediably switch off the unit. First unlock the 6 lockers, 2 at the top and 2 on each side.
- Page 10 The batteries are not dead but in sleep mode. This prevents the batteries from degrading when shipping or being on a shelf. The batteries will "wake up" once charged in a SP30 handheld or the charging dock (available as an accessory). The very first task after unpacking is to connect...
- Page 11 In sleep mode (short press) only the display is off but all GNSS functions are still alive Dual battery charger No hot swap function is available on SP30 unfortunately but still the possibility to have an additional battery always fully charged in hands. An external battery charger is available as an accessory and can charge 2 batteries simultaneously.
- Page 12 When starting SP30, GNSS reception is activated automatically and will remain on, even when the receiver is made idle. So it is important to switch the SP30 off when not used in order to save battery life. What are the different SP30 configurations available for sale? There are 4 different SP30 configurations available: –...
- Page 13 Which corrections source can be used with SP30? SP30 is able to handle any type of corrections except UHF ones. It can be SBAS, NTRIP, Direct IP or RTX (both from the Internet or L Band). The supported formats of corrections are: ATOM, CMR, CMR+, RTCM, CMRx and sCMRx.
- Page 14 Customers might be interested in testing the SP30 accuracies before making their final decision. To be able to demonstrate the 4 accuracy levels, you need to have an SP30 with cm level activated. This is because you can only demonstrate the levels of accuracy that are below the accuracy level of your receiver.
- Page 15 The use of the monopole in conjunction with the SP30 is a very efficient way to guarantee the accuracy of the collected features, while keeping maximum product portability. SP30 is shipped with an accessory to be mounted to the back of the antenna part in order to adapt on the monopole.
- Page 16 GNSS antenna phase center above the ground. What is the benefit of the “Camera logging “workflow? In order to make accurate logging possible with the SP30, while still holding the receiver in your hand, we have implemented in Mobile Mapper Field and PenMap applications a special workflow consisting of using the rear camera to better aim at a point.
- Page 17 SP30 and Origin. GIS configuration For GIS, the MobileMapper Field software can be used on the SP30. This GIS data collection application is a basic but efficient solution for any GIS job. MobileMapper Field needs to be used in combination with the SPace application.
- Page 18 How many function keys does the SP30 handheld have? The SP30 handheld has 4 physical F-keys (function keys). They are located to the bottom of the screen on the front of the device, and one on the left side of the device.
