- Page 1 MobileMapper 60 Handheld User Guide...
- Page 2 Part 15 of the FCC Rules. These limits are designed to Release Notice provide reasonable protection against harmful interference in a This is the June 2019 release (Revision A) of the MobileMapper 60 residential installation. This equipment generates, uses and can handheld documentation. It applies to the Android operating system radiate radio frequency energy and, if not installed and used in 8.0.
- Page 3 +31 497 53 24 30 and ask for the “WEEE Associate”. Or, mail a request for recycling instructions to: Trimble Europe BV c/o Menlo Worldwide Logistics Meerheide 45 5521 DZ Eersel, NL Spectra Geospatial MobileMapper 60 Handheld User Guide | 3...
- Page 4 Spectra Geospatial MobileMapper 60 Handheld User Guide | 4...
-
Page 5: Table Of Contents
Connecting to an office computer 2 Using the Android operating system Using the Home screen(s) Interacting with the handheld Entering information Using the menus Using the on-screen keyboard Editing text Managing notifications Selecting the language Spectra Geospatial MobileMapper 60 Handheld User Guide | 5... - Page 6 Using the camera in Still mode Using the camera in Panorama mode Using the camera in Video mode Camera setting options Working with photos and videos in the Android Photos or Gallery app Spectra Geospatial MobileMapper 60 Handheld User Guide | 6...
-
Page 7: Safety Information
Radio use Radio use The MobileMapper 60 handheld contains a Bluetooth® radio, a WLAN (Wi-Fi) radio, and a 4G cellular modem radio. In some situations, you may be required to turn off the radios. For example, aviation authority regulations restrict the use of wireless transmission devices on board aircraft. -
Page 8: Exposure To Radio Frequency (Rf) Signals
Spectra Geospatial therefore believes the internal wireless radios are safe for use by users. The level of electromagnetic energy emitted is hundreds of times lower than the electromagnetic energy emitted by wireless devices such as mobile phones. -
Page 9: Telecommunications & Internet Association (Tia) Information
Make certain that the adaptor has prongs compatible with your outlets. Do not use the AC adaptor in wet outdoor areas; it is designed for indoor use only. Unplug the AC adaptor from power when not in use. Spectra Geospatial MobileMapper 60 Handheld User Guide | 9... -
Page 10: Battery Safety
If battery fluid gets into your eyes, immediately rinse your eyes with clean water and seek medical attention. Do not rub your eyes! If battery fluid gets onto your skin or clothing, immediately use clean water to wash off the battery fluid. Spectra Geospatial MobileMapper 60 Handheld User Guide | 10... -
Page 11: Electrostatic Discharge
You can do so by touching an unpainted metal surface. Spectra Geospatial MobileMapper 60 Handheld User Guide | 11... -
Page 12: Exposure To Loud Audio
Safety information Exposure to loud audio To prevent possible hearing damage, do not listen at high volume levels for long periods. Spectra Geospatial MobileMapper 60 Handheld User Guide | 12... -
Page 13: Getting Started
Parts of the MobileMapper 60 handheld Accessories Powering the handheld Storing data Inserting and removing a SIM card and SD card Attaching the handstrap Resetting the handheld Calibrating the compass Connecting to an office computer Spectra Geospatial MobileMapper 60 Handheld User Guide | 13... -
Page 14: Introduction
1 Getting started Introduction This user guide describes how to set up and use the MobileMapper 60 handheld. The information in this guide supplements the information in the MobileMapper 60 Handheld Quick Start Guide, which you received with the handheld. -
Page 15: Additional Help
1 Getting started Additional help If you still cannot find the information that you need, contact your Spectra Geospatial reseller. Use and care of the handheld The device’s rugged design allows you to run your device in harsh outdoor environments. Here are some considerations that will help you protect your device and get the most out of it when working in very wet, hot or cold conditions. - Page 16 These batteries contain recyclable materials and are accepted for recycling. NOTE – In the event of battery failure, return the device to Spectra Geospatial or an Authorized Service Provider. Spectra Geospatial disposes of used batteries in accordance with local regulations.
-
Page 17: Parts Of The Mobilemapper 60 Handheld
19 External GNSS antenna port *Note - The device does not have a stylus accessory, but a capacitive stylus can be used with the device and tethered to the device here. Spectra Geospatial MobileMapper 60 Handheld User Guide | 17... -
Page 18: Accessories
1 Getting started Accessories The following standard accessories ship with the MobileMapper 60 handheld: Handstrap kit Lanyard Screen protector AC charger USB cable The following optional accessories are available to purchase: External magnetic GNSS antenna ... -
Page 19: Turning The Handheld On And Off
Internal storage is used for storing apps and private app data, as well as the Android operating system. Full capacity of this storage memory is 64 GB. Actual space available is less, due to operating system installation. Spectra Geospatial MobileMapper 60 Handheld User Guide | 19... -
Page 20: Memory Cards
You can do so by touching an unpainted metal surface. Spectra Geospatial MobileMapper 60 Handheld User Guide | 20... - Page 21 3. Remove the required SIM or SD card(s). 4. Replace the battery and push the battery lock right to the locked position. Replace the battery cover and lock it into place. Spectra Geospatial MobileMapper 60 Handheld User Guide | 21...
-
Page 22: Attaching The Handstrap
④ Assigning apps to the programmable buttons To assign apps to the programmable buttons on the MobileMapper 60 handheld: 1. Tap Settings/ System / SidekeyFNF1F2 set key. 2. Select the F key you want to assign an application to, then select the application you want to assign to it. -
Page 23: Resetting The Handheld
1 Getting started Resetting the handheld You can factory-reset the MobileMapper 60 handheld if you forget the password that you use to lock the device, or to delete all of your personal data from the handheld's internal storage, system and app settings, and any downloaded apps. -
Page 24: Using The Android Operating System
Locking the device Sending and receiving email The MobileMapper 60 handheld is powered by the Android operating system. When you start the handheld, the Home screen appears. From here you can access all the features on the handheld. Spectra Geospatial MobileMapper 60 Handheld User Guide | 24... -
Page 25: Using The Home Screen(S)
Drag. Hold your finger on an item for a moment and then, without lifting your finger, move your finger on the screen until you reach the target position. Drag in a list to select multiple items. Drag items on the Home screens to reposition them. Spectra Geospatial MobileMapper 60 Handheld User Guide | 25... - Page 26 Customized (4 Assigning apps to the programmable buttons, page buttons; 1 on the left side, and 3 at the bottom front of the device) Spectra Geospatial MobileMapper 60 Handheld User Guide | 26...
-
Page 27: Entering Information
Tap the Delete key to delete characters to the left of the cursor. To enter numbers, tap the ?123 key. To return to letters, tap ABC. Spectra Geospatial MobileMapper 60 Handheld User Guide | 27... -
Page 28: Editing Text
When you receive a notification, its icon appears in the Status bar, along with a summary that appears briefly. To open the Notifications panel to view a list of all your notifications, swipe down from the top of the screen with one finger. Spectra Geospatial MobileMapper 60 Handheld User Guide | 28... -
Page 29: Selecting The Language
3. Select any existing alarm to turn it on , or tap the alarm to change the alarm details. To add a new alarm, tap + at the bottom of the screen. Spectra Geospatial MobileMapper 60 Handheld User Guide | 29... -
Page 30: Display Settings
2. Select the required option, and follow the instructions that appear on the screens. The next time you turn on the handheld or wake up the screen, you must slide the padlock, enter your PIN or password, or draw your unlock pattern to unlock it. Spectra Geospatial MobileMapper 60 Handheld User Guide | 30... -
Page 31: Sending And Receiving Email
2 Using the Android operating system Sending and receiving email You can set up access to an existing email account from the MobileMapper 60 handheld to send and receive emails. 1. Make sure you are connected to a network. See... -
Page 32: Using The Wi-Fi (Wlan) And Bluetooth Radios
Working with paired Bluetooth-enabled devices Accessing a corporate network The MobileMapper 60 handheld includes an integrated Bluetooth radio and Wi-Fi (WLAN) radio, and provides a number of options for connecting to networks and other devices. To use the Wi-Fi (WLAN) or Bluetooth radio, you need to turn it on (see Turning on and turning off the Wi- Fi (WLAN) and Bluetooth radios, page... -
Page 33: Turning On And Turning Off The Wi-Fi (Wlan) And Bluetooth Radios
Connecting to a Wi-Fi (WLAN) access point To use Wi-Fi (WLAN) on the MobileMapper 60 handheld, you must access a wireless access point, or “hotspot.” Some hotspots are open and you can easily connect to them. Others are hidden or implement other security features, so you must configure the handheld so it can connect to them. -
Page 34: Adding A Wi-Fi Network
The IP address assigned to the handheld by the Wi-Fi network you are connected to. Connecting to a Bluetooth-enabled device The MobileMapper 60 handheld has an integrated Bluetooth radio that you can use to establish a wireless connection to other Bluetooth devices that are within range. The MobileMapper 60 handheld can only connect to paired Bluetooth devices. -
Page 35: Working With Paired Bluetooth-Enabled Devices
2. Make sure the Bluetooth radio is turned on. If it is not, tap the slider it to turn it on. 3. The MobileMapper 60 handheld has a generic name by default, which is visible to other devices when you connect to them. You can change the name so that it is more recognizable. Tap Bluetooth, then and tap Rename this device. -
Page 36: Unpairing A Bluetooth Device
2. Tap VPN. The VPNs configured in the handheld are listed on the VPN settings screen. Tap the VPN that you want to edit. 3. Tap Edit profile, then make the required changes and tap Save. Spectra Geospatial MobileMapper 60 Handheld User Guide | 36... - Page 37 1. Tap Settings / Network & Internet. 2. Tap VPN. The VPNs configured in the handheld are listed on the VPN settings screen. Tap the VPN that you want to delete. 3. Tap Delete profile. Spectra Geospatial MobileMapper 60 Handheld User Guide | 37...
-
Page 38: Using The Cellular Modem
Using the Smartphone Messaging The MobileMapper 60 handheld features a 4G cellular modem that you can use to connect to the Internet, make voice calls and send / receive data and messages. It also has two nanoSIM slots that can be used for connection between two seperate mobile carriers. -
Page 39: Manually Connecting To A Cellular Network From The Modem
This process can take several minutes. Switching between SIM card networks The MobileMapper 60 handheld has two nanoSIM slots that can be used for connection between two seperate mobile carriers. To switch between networks, go to Settings / Network & Internet / Mobile network / SIM cards and select the preferred SIM card for the Default 4G / 3G Subscription and Cellular data. -
Page 40: Using The Call History Log
4 Using the cellular modem NOTE – You can use a Bluetooth headset with the MobileMapper 60 handheld. To make a phone call: 1. Make sure that a SIM card is installed. See Inserting and removing a SIM card and SD card, page 2. -
Page 41: Messaging
If you are working in a message window, messages that you receive are displayed in it. Otherwise, you receive a new message notification and a new message icon appears in the Status bar. See Managing Spectra Geospatial MobileMapper 60 Handheld User Guide | 41... -
Page 42: Changing Messaging Settings
Roaming auto-retrieve. When not selected, only the header of multimedia messages is downloaded when connected to other carrier’s data networks. This is useful for avoiding unexpected charges, if your contract has limits on data roaming. Spectra Geospatial MobileMapper 60 Handheld User Guide | 42... -
Page 43: Using The Gnss Receiver
Using an external GNSS antenna Using an external GNSS receiver The MobileMapper 60 handheld contain an integrated uBlox Neo-M8T GNSS receiver, which is set to ensure the best possible performance in the field for data collection and full compatibility with Spectra Geospatial field and office software. -
Page 44: Receiving Signals From Gnss Satellites
For optimal GNSS reception, hold the handheld at 15° from horizontal allowing it visibility of the sky. When collecting point data with a MobileMapper 60 handheld, it is recommended that you remain stationary at the point for at least 10 seconds before beginning to log GNSS positions. This allows the GNSS receiver’s internal algorithms to stabilize, and ensures the best possible point feature accuracy. -
Page 45: Using An External Gnss Antenna
5 Using the GNSS receiver Using an external GNSS antenna The MobileMapper 60 handheld provides an external GNSS antenna port on the back of the device, and a GPS external antenna is available as an accessory to be used with the receiver. -
Page 46: Using The Camera
Working with photos and videos in the Android Photos or Gallery app The MobileMapper 60 handheld has a 5 megapixel front- facing integrated digital camera, and a 13 megapixel rear camera with geotagging, which you can use to capture photos or video. -
Page 47: Starting And Closing The Camera App
1. Start the camera, and make sure Panorama mode is selected; tap the icon in the bottom right corner ( depending on what mode you are in) and tap 2. Use the viewfinder to frame the start of the panorama you want to capture. Spectra Geospatial MobileMapper 60 Handheld User Guide | 47... -
Page 48: Using The Camera In Video Mode
The video you recorded is saved in the Android Photos app. Videos are stored as .mp4 files. See Working with photos and videos in the Android Photos or Gallery app, page 50 for more information. Spectra Geospatial MobileMapper 60 Handheld User Guide | 48... -
Page 49: Camera Setting Options
Tap the Effects icon at the top of the screen to set to None, Mono, Sepia, Negative, Solarize, Posterize, Aqua, Emboss, Sketch, Neon. NOTE – These options are not available if HDR is turned on. Spectra Geospatial MobileMapper 60 Handheld User Guide | 49... -
Page 50: Working With Photos And Videos In The Android Photos Or Gallery App
Tap the edit (pencil) icon at the bottom left of the screen to edit the file. Tap the trash can icon at the bottom left of the screen to delete the file. To close the Gallery app, tap Spectra Geospatial MobileMapper 60 Handheld User Guide | 50...
