SecureSync 2400
Option Card Field Installation Guide
Purpose of this Document
The SecureSync 2400 time and frequency synchronization system offers customizability and expandability via
the addition of a range of modular option cards. Depending on your unit's specifications, up to 6 cards can be
accommodated to offer not only synchronization to a variety of input references, but also numerous types of out-
put signals, supporting an extensive number of traditional and contemporary timing protocols.
Typically, SecureSync units are shipped with custom-ordered option cards pre-installed at the factory. In the
event that an option card is purchased at a later time, field installation will be necessary. This option card install-
ation guide contains information and instructions for installing option module cards in your SecureSync unit.
This procedure should only be attempted by qualified personnel, while following the enclosed safety instructions.
Note:
The installation procedure varies, depending on the type of option card and the installation
location to be installed. Read instructions completely before beginning.
SecureSync 2400 Option Card Field Installation Guide
Document Part Number 2400-5000-0052 Rev 2
May 4, 2021
•
Technical Note
Page
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SecureSync 2400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Orolia SecureSync 2400

Summary of Contents for Orolia SecureSync 2400

  • Page 1 Document Part Number 2400-5000-0052 Rev 2 Purpose of this Document The SecureSync 2400 time and frequency synchronization system offers customizability and expandability via the addition of a range of modular option cards. Depending on your unit's specifications, up to 6 cards can be accommodated to offer not only synchronization to a variety of input references, but also numerous types of out- put signals, supporting an extensive number of traditional and contemporary timing protocols.

  • Page 2: Outline Of The Installation Procedure

    SecureSync 2400 Option Card Field Installation Guide Outline of the Installation Procedure The general steps necessary for installing SecureSync option cards are as follows: 1. If adding or removing option cards that provide a reference, optionally backup your SecureSync con- figuration (refer to "[2]: Saving Refererence Priority Configuration"...

  • Page 3: Saving The System Configuration Files

    SecureSync 2400 Option Card Field Installation Guide [1]: Unpacking On receipt of materials, unpack and inspect the contents and accessories (retain all original packaging for use in return shipments, if necessary). The following additional items are included with the ancillary kit for the field installation of option card(s).
  • Page 4 SecureSync 2400 Option Card Field Installation Guide 3. Click in the grey confirmation window that displays. 4. Save the configuration file to a directory where it will be safe. Note: The Reference Priority configuration must be saved BEFORE beginning with the hardware installation.
  • Page 5 SecureSync 2400 Option Card Field Installation Guide [3]: Determining the Installation Procedure The installation procedure for option cards varies, depending on: i. option card model ii. installation slot chosen by you, and iii. for upper slots only: if the bottom slot is used or not.
  • Page 6 SecureSync 2400 Option Card Field Installation Guide c. Identify your installation steps via the table below. i. Find your part number in the left-hand column. Some cards require special installation steps or spe- cific locations. ii. Choose your Installation Location (as determined above).
  • Page 7 SecureSync 2400 Option Card Field Installation Guide [4]: Slot 1 & 2 Installation Option cards installed in Slot 1 or Slot 2 sit on top of and are screwed into pre-installed standoffs and plug in to the unit through the included ribbon cable.
  • Page 8 SecureSync 2400 Option Card Field Installation Guide e. Using the supplied M3 screws, screw the board, and the option card plate into the chassis, applying a torque of 0.9 Nm/8 in-lbs. f. Take the supplied 50-pin ribbon cable and carefully press it into the connector on the mainboard (lining up the indicated end of the cable with PIN 1 on the mainboard), then into the connector on the option card (see Figure below).
  • Page 9 SecureSync 2400 Option Card Field Installation Guide [5]: Bottom Slot Installation Instructions for installing an option card into one of the bottom slots (3, or 5): a. Safely power down the unit and remove the top cover of the main chassis (housing). Save the screws.
  • Page 10 SecureSync 2400 Option Card Field Installation Guide [6]: Top Slot Installation, Bottom Slot Empty Instructions for installing an option card into an upper slot (4, or 6) of the SecureSync unit, with no card populating the bottom slot: a. Safely power down your SecureSync unit and remove the top cover of the main chassis (housing). Save the screws.
  • Page 11 SecureSync 2400 Option Card Field Installation Guide f. Take the supplied 50-pin ribbon cable and carefully press it into the connector on the mainboard (lining up the indicated end of the cable with PIN 1 on the mainboard), then into the connector on the option card (see Figure below).
  • Page 12 SecureSync 2400 Option Card Field Installation Guide [7]: Top Slot Installation, Bottom Slot Occupied Instructions for installing an option card into an upper slot (4, or 6), above a populated bottom slot: a. Safely power down the SecureSync unit, and remove the top cover of the main chassis (housing). Save the screws.
  • Page 13 SecureSync 2400 Option Card Field Installation Guide Figure 7: Bottom card with standoffs installed f. Insert option card into the slot above the existing card, lining up the screw holes with the standoffs. g. Using the supplied M3 screws, screw the board into the standoffs, and the option plate into the chassis, applying a torque of 0.9 Nm/8 in-lbs.
  • Page 14 SecureSync 2400 Option Card Field Installation Guide [8]: Frequency Output Cards: Wiring Additional installation instructions for the following option card models: Frequency Output cards: 1MHz (PN 1204-26) 5MHz (PN 1204-08) 10 MHz (PN 1204-0C) 10 MHz (PN 1204-1C) For the cable installation, follow the steps detailed below: a.
  • Page 15 SecureSync 2400 Option Card Field Installation Guide [9]: Alarm Relay Card, Cable Installation Additional steps for the installation of the Alarm Relay Output card (PN 1204-0F). a. Connect the supplied cable, part number 8195-0000-5000, to the mainboard connector J19, pins 3 - 8.
  • Page 16 Additional steps for the installation of the NEMA-compliant card (PN 1204-1F). Note: The double-wide NEMA card can only be installed in slots 1 & 2 on the SecureSync 2400. a. After installation in slots 1 and 2, connect the supplied cable, part number 8195-0000-5000, to the main- board connector J19, pins 3 - 8.

  • Page 17: Verifying Hw Detection And Sw Update

    Orolia periodically releases new versions of software for SecureSync. These updates are offered for free and made available for download from the Orolia website. If you register your product, you will be notified of software updates.
  • Page 18 SecureSync 2400 Option Card Field Installation Guide Perform update: Perform the software upgrade. Perform clean update: Factory settings will be applied during the upgrade; any custom settings you may have applied previously will be overwritten! This also includes the unit's static IP address (if you applied one): it will be replaced by the default DHCP address (i.e., 0.0.0.0.) Also note that the browser...

  • Page 19: Uploading Configuration Files

    SecureSync 2400 Option Card Field Installation Guide [12]: Restoring Reference Priority Configuration If you saved your Reference Priority configuration under STEP [2], you can now restore it: Uploading Configuration Files To upload configuration files from a PC: 1. Navigate to TOOLS >...

  • Page 20: Technical Support

    Thank you for your cooperation. Regional Contact Orolia operates globally and has offices in several locations around the world. Our main offices are listed below: Country Location Phone France Les Ulis +33 (0)1 64 53 39 80 West Henrietta, NY +1 585 321 5800...
