1. Identifying the Parts
FAKRA connectors
Follow the sequence to connect the cameras.
Note: To update the firmware, toggle the switch to the programming mode (right side) and strongly suggest operating this procedure by a technician.
2. How to Assemble the Card and the Cameras
1.
Push down the grabber card into the PCIe slot directly.
2.
Make sure the golden finger of the card is inserted firmly, and secure the card with a screw.
3.
Connect the coaxial cable into the FAKRA connector of the frame grabber card on the I/O rear panel of the computer and the other end to a
camera. Follow the sequence mentioned in the
2
1
2
3
4
Identifying the Parts
1
Quick Install Guide
4-Port Vizionlink™ Frame Grabber Card (PCIE-VL-3440)
Firmware update switch
Grabber card gold finger
section to connect other cameras.
3
