Related Manuals for EVGA XR1 PRO
Summary of Contents for EVGA XR1 PRO
-
Page 2: Inside The Box
Inside The Box Please check all these items are included. EVGA XR1 PRO Quick Guide HDMI Cable USB 3.0 Type-C 3.5mm Audio Cable to Type-A Cable... -
Page 3: Specification
Specification Interface USB 3.0 Type-C Input & Output (Pass Through) HDMI 480p / 576p / 720p / 1080p@240fps / Input 1440p@144fps / 2160p@60fps HDR 480p / 576p / 720p / 1080p@240fps / Pass Through 1440p@144fps / 2160p@60fps HDR Capture Max Resolution 2160p@30fps 130mm x 86.4mm x 32.95mm With the Control Dial Dimension... - Page 4 Control Dial Function Up: Select Lighting Effect Down: Select Lighting Effect Left: Switch to Adjust the Volume of Mic In Right: Switch to Adjust Volume of Console Party Link Volume Adjustment Mode: Control the Volume of Mic In / Console Party Link Lighting Adjustment Mode: Control the LED Lighting Effect / Speed Press...
-
Page 5: Led Indications
LED Indications USB 3.0 Mode Gradient White Standby with USB 3.0 Connection Mode USB 2.0 Mode Gradient Yellow Standby with USB 2.0 Connection Mode Flashing White Twice Resetting Device Solid Red Mic In Muted Gradient Red USB signal issue (No Video) Gradient Green USB signal issue (No Support for Up Scale) Gradient Blue... - Page 10 first time. It will attempt to find the most appropriate settings that your PC can handle. You can manually change these settings later. (Reference the EVGA XR1 PRO Capture Card’s Quick Guide on how to connect your device to the EVGA XR1 PRO Capture Card and to your streaming device.) OBS doesn’t capture any video by default, you will need to enable your EVGA XR1 PRO Capture Card...
