- Page 1 LOGICA FM CONTROL UNIT BY BEGHELLI code 21102 Control Unit for the centralised control of normal and emergency lighting systems INSTALLATION AND OPERATING INSTRUCTIONS...
-
Page 2: Table Of Contents
• INSTALLATION • Use and termination of RS 485 lines Operations required to make the Logica FM Control Unit Operational Keyboard and Display Functions Date and Time Settings Searching for Logica FM Control Units (Node searching) Scheduling Functional and Autonomy Tests •... -
Page 3: What Is The Logica Fm Control Unit By Beghelli
WHAT IS THE LOGICA FM CONTROL UNIT BY BEGHELLI The Logica FM Control Unit by Beghelli (code 21102) is a device designed for the centralised con- trol of normal and emergency lighting systems: it controls and supervises up to 992 Logica FM series luminaires via radio. -
Page 4: Installation
INSTALLATION Use the layout below for reference to connect the Logica FM Control Unit to the Logica FM radio circuit and to the optional DIN printer (RS232 bus). The connection with the system, using the Logica Visual or the SD Manager software, can be established through different channels: - RS485-A;... -
Page 5: Keyboard And Display Functions
OPERATIONS REQUIRED TO MAKE THE LOGICA FM CONTROL UNIT OPERATIONAL KEYBOARD AND DISPLAY FUNCTIONS Keys allow you to navigate through pages on screen to view information and select operating modes. The three main menus are LUMINAIRES, MAINTENANCE AND STATUS; - to move from one menu to another, use the "DOWN"... - Page 6 TIME AND DATE SETTINGS At the first start up, the system displays the LUMINAI- RES menu: LUMINAIRES MAINTENANCE Press the keys shown on the right in sequence to go Mai n tenance CTRL UNI T MGT. to the menu for time setting: Ctrl Uni t Mgt.
- Page 7 Note: Install the Control Unit and activate the wizard for luminaire searching before starting to install the luminaires. By doing so, whenever a luminaire is powered on, the Logica FM Control Unit will detect it and will display a prompt. At the end of installation, the counter on the Control Unit display should report the exact number of installed luminaires (if not, check for turned off or faulty luminaires).
-
Page 8: Date And Time Settings
If a test reveals a luminaire is faulty, this information will be transferred from the luminaire to the Logica FM Control Unit: an error mes- sage will be displayed on screen and the error will be recorded in the Logbook. -
Page 9: Groups
GROUPS Luminaires connected to each Logica Control Unit by Beghelli can be divided into groups to perform separate operations on system sections. Each luminaire can belong to a group, multi- ple groups or no group. The total number of groups available is 16. -
Page 10: Menu
Most operations available can be applied to the entire system or to parts of it, as shown in the following table: For: go to (menu): all luminaires in the system a single luminaire (e.g. luminaire LOGICA SA SA/PS F01234 code F01234) all luminaires in Group yy GROUP 03 There are 3 menus: LUMINAIRES, MAINTENANCE AND STATUS. -
Page 11: Emergency
Manual Tests will not change the time intervals and durations set for automatic tests. Use the MANUAL TEST menu to perform operations described in the following table: go to (menu): run a Functional Test FUNCTION run an unlimited time test that will stop when ON INDEFINITELY the battery is completely discharged an Autonomy Test of 1 hour... -
Page 12: Management Test
For further details on how to set test dates, times and time intervals, see section "Scheduling Functional and Autonomy Tests". Based on their unique identifying addresses, LOGICA luminaires are divided into EVEN-numbe- red and ODD-numbered luminaires. Using the EVEN-ODD TEST menu, you can decide whether to perform an autonomy test on all luminaires simultaneously or first on the odd-numbered lumi- naires, then, 7 days later, on the even-numbered luminaires. -
Page 13: Control Unit Management
CONTROL UNIT MANAGEMENT Date & Time Changes To set the date and time on the Logica FM Control Unit,, see section "Date and Time Settings". Printing Note: Printing will be available if the Logica FM Control Unit is connected to a Logica DIN RS232 serial printer by Beghelli (code 3284). -
Page 14: Language
Language The user can set a different display language. Available languages: ITALIAN, GERMAN and ENGLISH. Outputs OUT1 - OUT2 - OUT3 on/off The user can enable or disable one or more outputs to signal errors in the system. Outputs OUT1 - OUT2 - OUT3 Active Open/Closed Once enabled, outputs can be set in N/C or N/A mode;... -
Page 15: Configuration
CREATE RADIO NETWORK Unit and all luminaires in the system At the first installation (see section "Searching for Logica FM Luminaires (Node searching)") and whenever luminaires are added to the system, run "FIND NODES CONT.". If one or more luminaires are replaced or deleted from the system, run "DELETE NODES" and then "FIND NODES CONT.". -
Page 16: Technical Features
. b e g h e l l i . c o m BEGHELLI S.p.A. - Via Mozzeghine 13/15 - Monteveglio 40053 Valsamoggia (BO) - ITALY Phone +39 051 9660411 - Fax +39 051 9660444 - Toll-free no. 800 626626...
