Signware
MultiStand
B
A
2 Split Rails
2 Full Rails
12-0200-B
12AF100RT-B
1
Lay out the base components prior to assembling as shown (be sure that the upright assembly bosses
are facing upward). Use the two rectangular tubes to connect the base sides. Press joints together
firmly to ensure connectors engage the tubing.
Part Layout
Completed base
AnoFrame ™ is a trademark of Rose Displays, Ltd. Neither the manufacturer nor any sales
agent may be held liable for injury, loss or damage resulting from the use of these products.
35 Congress Street, Salem, MA 01970 | 800.631.9707 | www.rosedisplays.com | signware@rosedisplays.com
C
4 Pairs Brackets
PN#
(Up)
F
E
(2) Bosses face
upward
(4)Threaded
corners face
floor
D
E
1 Short
2 long base connec-
Rail
tors
E
Caution
Sharp
Corners!
F
AnoFrame Top Load
F
2 Base Sides
1 Right PN#
1 Le PN#
(Up)
G
4 Casters
PN#
P1
