- Page 1 Catalog No.BK-P408 Static Electricity Removing Static Electricity Removing Unit Ionizer Air gun type Air gun type DTY-ELG41 Change the shape and handling, to support Change the shape and handling, to support various situations! various situations! Provides the Provides the optimal...
- Page 2 Air gun type DTY-ELG41 □ Features ● The product is designed for easy holding, and has a 185g [6.53 oz] light weight body. (DTY-ELG41) 10% reduction in weight (compared to our products) ● A high-frequency AC method provides high efficiency of electrostatic charge removal and outstanding ion balance.
- Page 3 □ Features ● You can bend the main unit to switch the ionizer between air gun shape and straight shape. ● When the ionizer is in straight shape, you can use it by suspending it. * The suspension bracket is movable. Air gun shape Straight shape Suspension bracket...
-
Page 4: Switching Method
Applicable examples ● E lectrostatic charge removal and dust removal work by ● E lectrostatic charge removal and dust removal work suspending the ionizer from the ceiling in the ceiling of a box Switching method ● Switch the ionizer to air gun shape before use Air gun shape Lock button Straight shape... -
Page 6: Specifications
5 to 15 Ozone generation amount 0.04 or less Medium Air (clean air, water vapor and oil removed) DTY-ELG41: 0.05 to 0.6 [7 to 87] Operating air pressure range MPa [psi] DTY-ELG41-PAU: 0.2 to 0.6 [29 to 87] Operating Environment Indoors: 0 to 40°C [0 to 104°F]/65% or less (non-condensation) - Page 7 ■ Static charge removal characteristics DTY-ELG41 DTY-ELG41-PAU Static charge removing time for supplied air pressure Static charge removing time for supplied air pressure Measuring distance: 50mm Measuring distance: 50mm Pulse frequency: 15Hz Air pressure [MPa] 1 MPa = 145 psi...
- Page 8 21.2 [0.835] Dimensions Lighting LED switch (mm [in.]) For straight shape ● Main unit DTY-ELG41 Lock button DTY-ELG41-PAU 87 [3.425] Suspension bracket 16 [0.630] (177.3 [6.980]) φ24 [0.945] 27 [1.063] (150.3 [5.917]) 24VDC 100mA SYNC SYNC ION/ALM ION/ALM Lighting LED...
- Page 9 DTY-Z □ -G31 N1: Replacement nozzle N2: Extension nozzle Replacement nozzle Extension nozzle 90 [3.543] 83.5 [3.287] 33.5 [1.319] φ18 [0.709] φ18 [0.709] 27 [1.063] Ion air outlet Ion air outlet NOTE: This product is a replacement nozzle only for DTY-ELG31/DTY-ELG41.
-
Page 10: General Precautions
2. Warranty scope and disclaimer 6. Do not use the AC adapter cable or the power and signal (1) If a failure attributable to KOGANEI CORP. is found in a lines attached to this product with any moving parts. Doing product purchased from KOGANEI CORP. - Page 11 Memo...
- Page 12 • KOGANEI CORP. warrants its products to be free from defects KOGANEI CORP. shall in no way be liable or responsible for injuries or damage to persons or property arising out of the in material and workmanship subject to the following provisions.
