- Page 1 SCSS-700VS VIP-Series Voice Integration Panel Installation/Operation Manual Copyright © 2010 Document 53796 All Rights Reserved 03/23/10 Rev: Published in U.S.A. P/N 53796:GA...
- Page 3 Installation Procedure Installation Precautions - Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be connected to the fire alarm control panel. Disconnect all sources of power before servicing. Control unit and associated equipment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized.
- Page 4 detectors, heat detectors, manual pull stations, audible warning devices, and a fire alarm control with remote notification capability - can provide early warning of a developing fire. Such a system, however, does not assure protection against property damage or loss of life resulting from a fire.
-
Page 5: Table Of Contents
Content Section 1 Overview ..............................1-1 Optional Accessories ..........................1-1 Features ..............................1-2 About This Manual ..........................1-3 1.3.1 Terms Used in this Manual ....................... 1-3 Section 2 Agency Listings, Approvals, and Requirements ........2-1 Federal Communications Commission (FCC) ..................2-1 Underwriters Laboratories (UL) ...................... - Page 6 3.8.5 VBUS Wiring ..........................3-20 3.8.6 SBUS Wiring ..........................3-21 3.8.7 Connecting AC Power ........................3-22 3.8.8 Backup Battery for VIP-50 ......................3-24 3.8.9 Calculating Current Draw and Standby Battery ................3-25 Installing the VIP-125 ..........................3-26 3.9.1 VIP-125 Board Layout ........................3-26 3.9.2 Mounting the VIP-125 ........................
-
Page 7: Overview
SCSS-700VS VIP-VCM (Voice control module) Optional Accessories This manual also contains information on how to install the following compatible accessories with the VIP series equipment: Model Number Description VIP-SW16 Adds 16 additional switches to the VIP-VCM or SCSS-700RM to manually select various voice output groups for emergency announcements from the on-board microphone. -
Page 8: Features
VIP-Series Voice Integration Package Installation/Operation Manual Features VIP-Series • The VIP-VCM has a built-in Digital Message Repeater. • Single enclosure for system control components. • SBUS addressable amplifier. The system can support a combination of up to eight VIP-50s/VIP-125s (50/125 watt amplifiers) for a maximum of 1000 watts per system. •... -
Page 9: About This Manual
Overview About This Manual This manual is intended to be a complete reference for all installation and operation tasks. Please let us know if the manual does not meet your needs in any way. We value your feedback! 1.3.1 Terms Used in this Manual The following terminology is used with the VIP system: Term Description... - Page 10 VIP-Series Voice Integration Package Installation/Operation Manual Limitations of Fire Alarm Systems Manufacturer recommends that smoke and/or heat detectors be located throughout a protected premise following the recommendations of the current edition of the National Fire Protection Association Standard 72 (NFPA 72), manufacturer’s recommendations, State and local codes, and the recommendations contained in Guide for the Proper Use of System Smoke Detectors, which is made available at no charge to all installing dealers.
- Page 11 Overview • Heat detectors do not sense particles of combustion and are designed to alarm only when heat on their sensors increases at a predetermined rate or reaches a predetermined level. Heat detectors are designed to protect property, not life. •...
- Page 12 VIP-Series Voice Integration Package Installation/Operation Manual Requirements and recommendations for proper use of fire alarm systems in- cluding smoke detectors and other fire alarm devices: Early fire detection is best achieved by the installation and maintenance of fire detection equipment in all rooms and areas of the house or building in accordance with the requirements and recommendations of the current edition of the National Fire Protection Association Standard 72, National Fire Alarm Code (NFPA 72), the manufacturer’s recommendations, State and local codes and the recommendations contained in Guide for the Proper Use of...
- Page 13 Overview SURVIVABILITY: Per the National Fire Alarm Code, NFPA 72, all circuits necessary for the operation of the notification appliances shall be protected until they enter the evacuation signaling zone that they serve. Any of the following methods shall be considered acceptable as meeting these requirements: 1) A 2-hour rated cable or cable system 2) A 2-hour rated enclosure...
- Page 14 VIP-Series Voice Integration Package Installation/Operation Manual 53796...
-
Page 15: Agency Listings, Approvals, And Requirements
Section 2 Agency Listings, Approvals, and Requirements Federal Communications Commission (FCC) 1. The following information must be provided to the telephone company before the FACP can be connected to the phone lines: Manufacturer: Honeywell International Inc Model Number: SCSS-700 FCC registration number: AC6 USA-34758-AL-E and AC6USA-23901-AL-E Ringer equivalence: 0.8B... -
Page 16: Underwriters Laboratories (Ul)
VIP-Series Voice Integration Package Installation/Operation Manual Underwriters Laboratories (UL) 2.2.1 Requirements for All Installations General requirements are described in this section. When installing an individual device, refer to the specific section of the manual for additional requirements. The following subsections list specific requirements for each type of installation (for example, Central Station Fire Alarm systems, Local Protected Fire Alarm systems, and so on). -
Page 17: Installation
Section 3 Installation This section of the manual is intended to help you plan your tasks to complete the installation. Please read this section thoroughly, especially if you are installing a VIP-Series control for the first time. Environmental Specifications It is important to protect the control panel from water. To prevent water damage, the following conditions should be AVOIDED when installing the units: •... - Page 18 VIP-Series Voice Integration Package Installation/Operation Manual • Route the wiring around the inside perimeter of the cabinet. It should not cross the circuit board where it could induce noise into the sensitive microelectronics or pick up unwanted RF noise from the high speed circuits. See Figure 3-1 for an example. High frequency noise, such as that produced by the inductive reactance of a speaker or bell, can also be reduced by running the wire through ferrite shield beads or by wrapping it around a ferrite toroid.
-
Page 19: Sbus Specifications
FACP Installation Manual SCSS-700VS 53722 Mounting the Cabinet This section provides instructions on how to install the VIP series cabinet for surface or recessed mounting. Refer to Section 3.1 when choosing a mounting location. 3.4.1 Preventing Water Damage Water damage to the fire system can be caused by moisture entering the cabinet through the conduits. -
Page 20: Surface Mounting
VIP-Series Voice Integration Package Installation/Operation Manual 3.4.2 Surface Mounting The cabinet can be mounted on the wall surface by using the mounting holes in the back of the cabinet (see Figure 3-2). 1. Insert two screws level with each other, 14" apart for the top cabinet key shaped holes. See Figure 3-2. -
Page 21: Recessed Mounting
Installation 3.4.3 Recessed Mounting This section describes how to recess mount the cabinet into a wall. To recess mount the cabinet you will need to have the optional trim ring P/N VIP-TR (ordered separately). Follow these steps to recess mount the cabinet: 1. -
Page 22: Cabinet Door And Dead Front Removal
VIP-Series Voice Integration Package Installation/Operation Manual 4. Place the trim ring around the cabinet. See Figure 3-4. Trim Ring Cabinet Figure 3-4 Trim Ring Around cabinet 5. Secure the trim ring to the cabinet using the self-tapping sheet metal screws from the inside of the cabinet into the trim ring. -
Page 23: Connecting Ac Power And Batteries
Installation Re-Attaching the Cabinet Door To re-attach the cabinet door reverse the procedure in section 3.4.3.1. Connecting AC Power and Batteries Refer to the FACP’s installation manual for proper AC power connections. VIP-Series Model Number FACP Installation Manual SCSS-700VS 53722 53796... -
Page 24: The Vip-Vcm
VIP-Series Voice Integration Package Installation/Operation Manual The VIP-VCM This section provides information on how to install or remove the VIP-VCM to the control cabinet and how to make the proper wiring connections. 3.6.1 VIP-VCM Board Layout The following is a description of the VIP-VCM voice control module components. SBUS Address DIPs Dead Front Panel... -
Page 25: Connecting The Vip-Vcm To The Sbus
Installation Active Label Windows and LEDs Dead Front Dead Front Panel Mounting Panel Mounting Holes Holes Select Buttons and LEDs Figure 3-7 Front View VIP-VCM 3.6.2 Connecting the VIP-VCM to the SBUS Refer to Figure 3-8 to properly connect the VIP-VCM to the FACPs SBUS. VIP-VCM Supervised Power Limited... -
Page 26: Installing The Microphone
VIP-Series Voice Integration Package Installation/Operation Manual See Section 3.12 to set SBUS addressing. 3.6.3 Installing the Microphone To install the microphone follow these steps: 1. Clip the microphone into the micro phone clip. See Figure 3-9. Figure 3-9 Sliding Microphone into Microphone Clip 2. -
Page 27: To Remove The Vip-Vcm
Installation 3. Attach strain relief clip to microphone cord. The strain relief clip should have about 2-¾” of micro phone cord through it. See Figure 3-11. 2-3/4” Figure 3-11 Installing Strain Relief Clip 4. Push the strain into the hole in the dead front panel. 3.6.4 To Remove the VIP-VCM To remove the VIP-VCM follow these steps:... - Page 28 VIP-Series Voice Integration Package Installation/Operation Manual 4. Unplug the Microphone from the microphone connector. See Figure 3-12. Figure 3-12 Back View of Dead Front Panel 5. Remove the six 1/4 hex nuts that hold the VIP-VCM in place. 6. Lift the VIP-VCM off of the dead front panel. 3-12 53796...
-
Page 29: Installing The Vip-Sw16 Switch Expander
Installation Installing the VIP-SW16 Switch Expander The VIP-SW16 adds 16 switches to the VIP-Series controls for a total of 32 (with the VIP- VCM). This section provides instruction on how to properly install the VIP-SW16. Follow these steps to install the VIP-SW16: 1. - Page 30 VIP-Series Voice Integration Package Installation/Operation Manual 6. Connect one end of the wiring harness (P/N 130398 supplied) to the VIP-VCM and the other end to the VIP-SW16 as shown in Figure 3-14. Wire Harness Figure 3-14 Wire Harness Connection 7. Restore AC power. 8.
-
Page 31: Installing The Vip-50
Installation Installing the VIP-50 This section provides information on how to install the VIP-50 for use with the VIP-Series products. 3.8.1 VIP-50 Board Layout Figure 3-15 shows the location of terminals, DIPs, and Expander connection, used in the installation of the VIP-50. VBUS SBUS SBUS... -
Page 32: Mounting The Vip-50
VIP-Series Voice Integration Package Installation/Operation Manual 3.8.2 Mounting the VIP-50 The VIP-50 is equipped with a separate enclosure. Refer to Section 3.1 when selecting a mounting location for the VIP-50. The panel should be accessible to main drop wiring runs. It should be mounted as close to the center of the building as possible and located within a secured area, but should be accessible for testing and service. -
Page 33: Wiring Specifications
Installation 3.8.3 Wiring Specifications All wiring and devices installed in the system must meet the standards described in National Electrical Code (NFPA 70), NFPA Standard 72, and Life Safety Code (NFPA 101). To avoid induced noise (transfer of electrical energy from one wire to another), keep input wiring isolated from high-current output and power wiring. -
Page 34: Speaker Wiring
VIP-Series Voice Integration Package Installation/Operation Manual 3.8.4 Speaker Wiring Each VIP-50 supplies four NACs (Notification Appliance Circuit) for speaker connections. The speaker circuit can be supervised and wired Class B (Style Y) or Class A (Style Z). The speaker circuit is capable of 50 watts of power at 25 Vrms or 70.7 Vrms. 3.8.4.1 Wiring Lengths Table 3-1 Wire Lengths Number Of Speakers... -
Page 35: Class B (Style Y)
Installation 3.8.4.2 Class B (Style Y) Figure 3-18 illustrates how to wire speakers to the control panel using Class B (Style Y) supervision. Supervised Power Limited 15kΩ EOL UL Listed Model 7630 Figure 3-18 Class B (Style Y) Speaker Configuration 3.8.4.3 Class A (Style Z) Figure 3-19 illustrates how to wire speakers to the control panel using Class A (Style Z) wiring. -
Page 36: Vbus Wiring
VIP-Series Voice Integration Package Installation/Operation Manual 3.8.5 VBUS Wiring The VBUS is an analog voice bus that carries the recorded voice messages from the VIP- VCM to the VIP-50s, or the voice messages generated from a system microphone to the VIP- 50s. -
Page 37: Sbus Wiring
Installation 3.8.6 SBUS Wiring This section contains information on how to connect VIP-50s (up to 8) onto the main control SBUS. Refer to Section 3.3 for SBUS specifications. Wire the SBUS as shown in Figure 3-21 or Figure 3-22. Control Panel Supervised Power Limited Figure 3-21 SBUS Connections of the VIP-50... -
Page 38: Connecting Ac Power
VIP-Series Voice Integration Package Installation/Operation Manual 3.8.7 Connecting AC Power The AC inputs are rated as 120 VAC, 60 Hz (transformer P/N 115061) or 230 VAC, 50 Hz (transformer P/N 115031). To install the AC transformer into the VIP-50 cabinet follow these steps: 1. - Page 39 Installation 4. Connect AC to the Transformer as Shown in Figure 3-24. Figure 3-24 AC Connections 5. Plug the transformer output to the AC connector on the control panel as shown in Figure 3-24. 53796 3-23...
-
Page 40: Backup Battery For Vip-50
VIP-Series Voice Integration Package Installation/Operation Manual 3.8.8 Backup Battery for VIP-50 The following steps explain how to connect the batteries (refer to Figure 3-25): 1. Connect the black wire of the battery harness to the (-) side of the battery #2. 2. -
Page 41: Calculating Current Draw And Standby Battery
Installation 3.8.9 Calculating Current Draw and Standby Battery This section helps you determine the current draw and standby battery needs for your installation (18 Ampere Hours max. will fit in cabinet). Complete the remaining instructions in Table 3-2. Batteries larger than 18 AH will not fit in the main control cabinet, and must be housed in the RBB Accessory Battery Cabinet. -
Page 42: Installing The Vip-125
VIP-Series Voice Integration Package Installation/Operation Manual Installing the VIP-125 This section provides information on how to install the VIP-125 for use with VIP-series products. 3.9.1 VIP-125 Board Layout Figure 3-26 shows the location of terminals, DIPs, and Expander connection, used in the installation of the VIP-125 Figure 3-26 Components Layout of VIP-125 3-26... -
Page 43: Mounting The Vip-125
Installation 3.9.2 Mounting the VIP-125 The VIP-125 is equipped with a separate enclosure. Refer to Section 3.1 when selecting a mounting location for the VIP-125. The panel should be accessible to main drop wiring runs. It should be mounted as close to the center of the building as possible and located within a secured area, but should be accessible for testing and service. -
Page 44: Wiring Specifications
VIP-Series Voice Integration Package Installation/Operation Manual 3.9.3 Wiring Specifications All wiring and devices installed in the system must meet the standards described in National Electrical Code (NFPA 70), NFPA Standard 72, and Life Safety Code (NFPA 101). To avoid induced noise (transfer of electrical energy from one wire to another), keep input wiring isolated from high-current output and power wiring. -
Page 45: Speaker Wiring
Installation 4. High frequency noise, such as that produced by the inductive reactance of a speaker or bell, can also be reduced by running the wire through ferrite beads or by wrapping it around a ferrite toroid core. Figure 3-28 provides an example. Figure 3-28 Wire Routing Example for VIP-125 3.9.4 Speaker Wiring... - Page 46 VIP-Series Voice Integration Package Installation/Operation Manual Table 3-3 Wire Lengths Number Of Speakers Total Load Wire Distance in Feet @1/2 W @1 W Vrms Watts 18 AWG 16 AWG 14 AWG 12 AWG 25Vrms 20W 1100 1750 2780 4420 25Vrms 26W 1200 1920 3050...
-
Page 47: Class B (Style Y)
Installation 3.9.4.2 Class B (Style Y) Figure 3-29 illustrates how to wire speakers to the control panel using Class B (Style Y) supervision. 15k Ω EOL Supervised UL Listed Power Limited Model 7630 Figure 3-29 Class B (Style Y) Speaker Configuration 53796 3-31... -
Page 48: Class A (Style Z)
VIP-Series Voice Integration Package Installation/Operation Manual 3.9.4.3 Class A (Style Z) Figure 3-30 illustrates how to wire speakers to the control panel using Class A (Style Z) wiring. Supervised Power Limited Figure 3-30 Class A (Style Z) Speaker Configuration 3-32 53796... -
Page 49: Vbus Wiring
Installation 3.9.5 VBUS Wiring The VBUS is an analog voice bus that carries the recorded voice messages from the VIP- VCM to the VIP-125s, or the voice messages generated from a system microphone to the VIP- 125s. The maximum resistance on the VBUS is 20Ω. Connect the VBUS from the VIP-VCM to the VIP-125s as shown in Figure 3-31. -
Page 50: Sbus Wiring
VIP-Series Voice Integration Package Installation/Operation Manual 3.9.6 SBUS Wiring This section contains information on how to connect VIP-125s (up to 8) onto the main control SBUS. Refer to Section 3.3 for SBUS specifications. Wire the SBUS as shown in Figure 3-32 or Figure 3-33 Figure 3-32 SBUS Connections of the VIP-125 3-34... - Page 51 Installation To next VIP-125 (Max 8) Figure 3-33 Connecting Multiple VIP-125s to the SBUS See Section 3.12 for information on setting SBUS addresses. 53796 3-35...
-
Page 52: Connecting Ac Power
VIP-Series Voice Integration Package Installation/Operation Manual 3.9.7 Connecting AC Power At installation, connect the AC terminals to the power source as shown in Figure 3-34. It may be necessary for a professional electrician to make this connection. The AC terminals are rated as 120 VAC, 60 Hz or 230 VAC, 50 Hz. Figure 3-34 AC Connection 3-36 53796... -
Page 53: Backup Battery For Vip-125
Installation 3.9.8 Backup Battery for VIP-125 The following steps explain how to connect the batteries (refer to Figure 3-35): 1. Connect the black wire of the battery harness to the (-) side of the battery #2. 2. Connect the jumper wire provided form the positive (+) side of battery #2 to the negative side of battery #1. -
Page 54: Calculating Current Draw And Standby Battery
VIP-Series Voice Integration Package Installation/Operation Manual 3.9.9 Calculating Current Draw and Standby Battery This section helps you determine the current draw and standby battery needs for your installation (18 Ampere Hours maximum will fit in cabinet). Complete the remaining instructions in Table 3-4. Batteries larger than 18 AH will not fit in the main control cabinet, and must be housed in the RBB Accessory Battery Cabinet. -
Page 55: Installing The Vip-Ce4
Installation 3.10 Installing the VIP-CE4 The VIP-CE4 adds four audio circuits to the VIP-50 or VIP-125. The VIP-CE4 mounts inside the VIP-50 or VIP-125 cabinet. Follow these steps to install the VIP-CE4: 1. Using the four supplied screws mount the VIP-CE4 in the VIP-50/VIP-125 cabinet as shown in Figure 3-36. - Page 56 VIP-Series Voice Integration Package Installation/Operation Manual 2. Connect the audio expander harness (PN 130426) from the connector labeled “Audio Expander” on the VIP-50/VIP-125 to the connector on the VIP-CE4 as shown in Figure 3- VIP-CE4 Connector VIP-50/ VIP-125 Audio Expander Figure 3-37 Audio Expander Wire Harness Connections 3.
-
Page 57: Installing The Scss-700Rm
Installation 3.11 Installing the SCSS-700RM The SCSS-700RM is a combination supervised remote microphone and annunciator. 3.11.1 SCSS-700RM Board Layout The following is a description of the SCSS-700RM voice control module components. Note: The VIP-VCM and SCSS-700RM circuits boards look identical, but they are not interchangeable. The VIP- VCM is mounted in the SCSS-700VS cabinet and the SCSS-700RM is mounted in the SCSS-700RM cabinet. - Page 58 VIP-Series Voice Integration Package Installation/Operation Manual Active Label Windows and LEDs Dead Front Dead Front Panel Mounting Panel Mounting Holes Holes Select Buttons and LEDs Figure 3-39 Front View SCSS-700RM 3-42 53796...
-
Page 59: Wiring The Scss-700Rm
Installation 3.11.2 Wiring the SCSS-700RM 1. Refer to Figure 3-41 to properly connect the SCSS-700RM to the FACPs SBUS. SCSS-700RM Supervised Power Limited FACP (SCSS-700 used as an example) Figure 3-40 SBUS Connections 2. See Section 3.12 to set SBUS addressing. 3. - Page 60 VIP-Series Voice Integration Package Installation/Operation Manual 4. Set the SBUS address on the annunciator and the SCSS-700RM board. See Section 3.12. 5. Connect the SCSS-700RM to the VBUS and VIP-125. VIP-125 SCSS-700RM Figure 3-42 VBUS and VIP-125 Wiring for SCSS-700RM 3-44 53796...
-
Page 61: Installing The Microphone
Installation 3.11.3 Installing the Microphone To install the microphone follow these steps: 1. Clip the microphone into the micro phone clip. See Figure 3-43. Figure 3-43 Sliding Microphone into Microphone Clip 2. Insert Microphone cord through hole at the bottom of the dead front panel. See Figure 3-44. -
Page 62: To Remove The Scss-700Rm
VIP-Series Voice Integration Package Installation/Operation Manual 3. Attach strain relief clip to microphone cord. The strain relief clip should have about 2-3/4” of micro phone cord through it. See Figure 3-45. 2-3/4” Figure 3-45 Installing Strain Relief Clip 4. Push the strain into the hole in the dead front panel. 3.11.4 To Remove the SCSS-700RM To remove the SCSS-700RM follow these steps: 1. - Page 63 Installation 4. Unplug the Microphone from the microphone connector. See Figure 3-46. Figure 3-46 Back View of Dead Front Panel 5. Remove the six ¼" hex nuts that hold the SCSS-700RM in place. 6. Lift the SCSS-700RM off of the dead front panel. 53796 3-47...
-
Page 64: Addressing Sbus Devices
VIP-Series Voice Integration Package Installation/Operation Manual 3.12 Addressing SBUS Devices When installing a hardware module (such as, 5815XL, 5824, 5496, 5895XL, 5865-3 or 5865- 4, VIP-50,VIP-125, VIP-VCM, and SCSS-700RMs), you must use the DIP switches on the module to assign an ID# to the module. Address zero is an invalid address and is not allowed. Figure 3-47 shows all possible DIP switch positions and their correlation to a numerical ID. -
Page 65: Voice Operation Overview
Voice Operation Overview Section 4 Voice Operation Overview This section of the manual describes the voice operation concept and how the control panel output groups operate together to create an effective integrated voice evacuation system. Note: For complete manual programming operation, refer to the programming section of the main control panel installation manual. - Page 66 VIP-Series Voice Integration Package Installation/Operation Manual Each of the 4 Circuits can be mapped to a single switch on the VIP-VCM so that when the button corresponding to the voice output group is pressed the speakers in that voice output group will be activated when the microphone is used.
-
Page 67: Recording Custom Messages
Voice Operation Overview Recording Custom Messages The VIP-Series controls come with three recorded messages (see Table 4-1). Message 1 & 2 can be changed through the 7780 software; Message 3 can be recorded from the microphone or by using the 7780 software. Message 1 & 2 are 32 seconds long, and Message 3 is 49 seconds long. -
Page 68: Input User Message 3 From The Aux Audio Input
VIP-Series Voice Integration Package Installation/Operation Manual 4.2.1 Input User Message 3 From the Aux Audio Input Follow these steps to input user message 3 into the VIP-VCM: Note: Refer to the FACP’s installation manual section 7 for detailed programming information. 1. -
Page 69: Input Message 3 Using Microphone
Voice Operation Overview 4.2.2 Input Message 3 Using Microphone 1. Enter programming mode at main control panel. 2. Select option 9 VIP-VCM Maint. 3. Select option 2 Local Recording. 4. Select which module you wish to have the playback from. 5. - Page 70 VIP-Series Voice Integration Package Installation/Operation Manual 2. Connect the PC to the VIP-VCM using a standard 9-pin serial cable. See Figure 4-5. Figure 4-5 Serial Cable Connections 3. Run the 7780 software. 4. Select the appropriate COM port that you are using. 5.
-
Page 71: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan.
