- if the thermometer was produced with the sole internal temperature setting, the
ORAL, RECTAL, AX. and CORE settings would not be available for changing.
- The measurement of the body temperature must be taken always at the centre of the
forehead (par. #4.1) or at the eyelid (par. #4.2), no matter what the current setting is: in
fact, the axillary, oral, rectal or core settings provide a forehead temperature value that
is a valid approximation of the axillary, oral or rectal/internal temperature respectively
(see par. #3).
If the thermometer is handled at length or if there is a significant temperature difference
with respect to the room temperature, a countdown will appear on the display indica-
ting that you should wait until automatic temperature calibration has been completed.
Pressing the "face"
At this point you have 2 options:
1. Automatic Quick Calibration System (AQCS): without touching the thermome-
ter, wait until the countdown has run its course and automatic quick calibration is com-
pleted. The countdown will continue updating as long as differences in temperature
are detected (for example, because the thermometer has been continuously handled).
At the end of the countdown, the thermometer can take sufficiently accurate readings.
When the thermometer is in stand-by mode, "AQCS" appears on the display indicating
that automatic quick calibration has been performed.
2. Manual Quick Calibration System (MQCS): the alternative is to promptly correct
the thermometer temperature, adapting it to the real temperature of the room where
the reading has to be taken.
Proceed as follows:
• press the "face"
(fig. 8) simultaneously: the symbol CAL will ap-
pear.
• within 10 seconds focus the thermometer on an
internal wall (not the inside of an external wall) or
wardrobe with uniform temperature and at a point
approximately 80/150 cm (30 to 60 inches) from
the floor. Press the "home"
• once the right distance is reached (temperature
value between the dots, fig. 5), release the but-
ton: the lights flash slowly and the display shows
the room temperature.
To ensure a reliable temperature reading, do not
focus the thermometer on an outside wall, win-
dow, source of heating or cooling (radiator, air
conditioner, lamp, computer, surface in contact
with the human body, etc.).
8. ROOM TEMPERATURE CALIBRATION
button, the projection shows "CAL".
and "home"
;
buttons
Fig. 8
MQCS
8
