K8NL
6. Additional tools
To close the double lock seam you need the double
lock hand seamer K7-1. The K7-1 closes the
pre-closed standing seam into a double lock seam
in one operation, item no.: 91515-1.
Max Draenert Apparatebau GmbH & Co. KG
Gutenbergstrasse 15-17
D-73779 Deizisau
:
+49-(0)7153-82170
:
www.dracotools.com
@:
info@dracotools.com
Manual
Read, observe and follow this manual
and the other applicable documents,
especially all safety instructions and
warnings.
Standing seam closers
K5, K8N, K8NL
Fig. K5
Type
Item no. Closing length Length
K5
91505
70 mm
K8N
91530
200 mm
K8NL
91535
350 mm
Special lengths available on request.
Max Draenert Apparatebau GmbH & Co. KG
Gutenbergstrasse 15-17
D-73779 Deizisau
Always wear
protective gloves!
Fig. K8N/ K8NL
Width
Weight
120 mm
260-430 mm
1,0 kg
250 mm 260-430 mm
2,1 kg
400 mm 310-530 mm
3,1 kg
:
+49-(0)7153-82170
:
www.dracotools.com
@:
info@dracotools.com
