Summary of Contents for Wizard Scarecrow 15
- Page 1 Instructions manual UV-c air disinfection system Model Scarecrow 15...
-
Page 2: Table Of Contents
Index 1. Introduction ................1.1. Operating principle ..................1.2. Manufacturer ....................1.3. Technical specifications ................2. Product operation ..............3. Machine components ............3.1. Tactile button ....................3.2 Active carbon filter and hepa filter ............. 3.3 Air circulation ....................3.4 UV-c lamps ....................... 4. -
Page 3: Introduction
1.1 Operating principle UV-C light has a germicidal capacity that has been widely studied and proven. The genetic information of viruses, bacteria, fungi and other microorganisms, responsible for their microbial replication, is stored in the DNA and RNA chains. UV radiation is an electromagnetic radiation capable of inhibiting the microorganisms’... -
Page 4: Technical Specifications
1.3 Technical specifications UVc wavelength Air flow m3/min UVc power radiation Treated zone 0-250 Voltage +- 10% Weight Power DIMENSIONS 547 x 257 x 1243 -Structure: internal steel and external aluminum structure -Standard programs: 10 working speeds -Low energy consumption. -Operation light sign and tactile button for program selection. -
Page 5: Product Operation
2. Product operation Connect the machine to the electrical current (220V AC, 50Hz). Always make sure that the equipment is on a stable surface before plugging in the connection cable. Preferably place in the center of the room to be disinfected. Press the power switch. -
Page 6: Machine Components
Program error If there is a failure in the fans, the tactile button will light up red and the device will stop working. Consult the manufacturer to fix it If there is a failure in any lamp, the tactile button will light up red, but if it is pressed again, the device will work. -
Page 7: Air Circulation
3.3 Air circulation The device has a 7-blade axial fan for sucking the air of the room to disinfect it inside and two radial fans to expel it. The air flow produced is 6 m3 / min. The maximum sound level, produced at maximum speed, is 60dB. 10 working speeds are available. -
Page 8: Maintenance
4.MAINTENANCE Clean the device with non-abrasive products. Always with a damp cloth, never with a spray bottle, to prevent the electronic components from getting wet and causing internal short circuits. Do not force the equipment and follow the instructions in the manual to work safely. - Page 9 The active carbon filter must be replaced after 12 months of use. Consult the manufacturer for a replacement. The HEPA 13 filter must be replaced after 12 months of use. The filter can be changed by non-specialized personnel. Consult the manufacturer for a replacement.
-
Page 10: Product Applications
5. PRODUCT APPLICATIONS This device is useful for the disinfection of viruses, bacteria, fungi and other microorganisms in closed rooms up to 250 m2. Suitable for commercial areas, hospitals, clinics, laboratories, residences, schools, shops, restaurants, coffee shops, hotels, spas, beauty centers, hairdressers, gyms and sports centers. - Page 11 Warning: The device cannot be opened while it is in operation. To replace the lamps, consult the manufacturer. Do not apply UVC radiation to disinfect hands or any other skin area. When working with UVC radiation, face shields or specific safety glasses (Standard EN166 and EN170) must be used and the skin must be covered with laboratory coats and nitrile gloves.
