Content 1. BASICS OF THE CAR RADIO ..............................1 1.1 Power on and off ..............................1 1.2 Screen function key ..............................1 1.3 Home and Application interface ..........................1 1.4 Drop-down menu and status bar..........................2 2. MAIN FUNCTIONS OF YOUR CAR RADIO DEVICE ........................ 3 2.1 Navigation function ..............................
1. BASICS OF THE CAR RADIO Warning: Before using this device, please make sure you read this manual. 1.1 Power on and off Power on: When you plug in the car keys, the car’s ACC power is switched on. The device will automatically power on, displaying the boot animation LOGO idMEDIA.
1.4 Drop-down menu and status bar Drop-down menu and status bar icon functions: ICON FUNCTION DETAILS WiFi Click to connect and disconnect WiFi. Bluetooth Click to see the Bluetooth connection status and enter BT page. Click to enter DSP settings. Screensaver Click to go to screensaver.
2. MAIN FUNCTIONS OF YOUR CAR RADIO DEVICE 2.1 Navigation function 2.1.1 Use of maps Click on the Navigation icon in the main interface or in the application interface to enter the map interface. 2.2 Radio function In the main interface, click the Radio icon to enter the audio interface.
Click to tune the radio frequency backward. Click to tune the radio frequency forward. Click to enter the DSP settings. 2.3 Bluetooth function You can enter the Bluetooth interface from the main interface by clicking on the Bluetooth icon 2.3.1 Pairing equipment When the device has not yet paired the equipment, it can only enter the setting and search interface.
Click to enter DSP settings. Click to play the previous song. Click to play & pause. Click to play the next song. Note: With some types of mobile phones, you need to start playing the music player first to be able to use the Bluetooth music function.
Find contacts: After downloading the phone book, click in the phone book page. The search box will pop up to let you enter the name or phone to find the contact as shown below: To delete the phone book in the device, click 2.3.4 Dial and Call In the Bluetooth interface, click the dialing icon to enter the Bluetooth Dial interface.
Click the numbers on the interface. If the input is wrong, click to delete the entered numbers. 2) Enter the phone number. Click to initiate the call. Click to end up the call. 3) When you already are on a call via the car radio, press to switch to listen to the call on the mobile phone and click this icon again to switch back to the car radio.
ICON FUNCTION Missed calls Received calls Dialed calls Delete all call records 2.4 Music Player Click in the application interface to enter the music playback interface. The audio player supports the following formats:MP3/MP2/WMA/APE/FLAC/AAC/WAV/OGG. ICON FUNCTION ICON FUNCTION Playlist for all songs Single circle play mode Song playlist from external SD card Play last song...
ICON FUNCTION ICON FUNCTION Playlist for all videos Play/Pause Video playlist from external SD card Play next video Video playlist from USB disk Zoom in Video playlist from storage itself Back to homepage DSP settings Zoom out Play last video Back to last page 2.6 DSP Function 2.6.1 Interface...
Page 13
3) Click to set surround sound settings. Choose the mode you need on the left and select the scene you need under . Or drag the yellow ball to anywhere you’d like 4) Click to set Bass boost settings. There are 2 bars to set the audio in the car: one for the front and the other for the rear. Drag the cursor to set the effect you need.
6) Click to do Bass filter settings Drag the bar to set the bass filter for the front and for the rear. Note: in custom mode, the user can customize the effect mode by the effect regulator and reset the bass. It is effective only when the external 4.1 amplifier is connected.
2.8 DAB+ Function Click the DAB+ icon to enter the following page: When you enter the DAB interface, the radio stations logos display in the bottom part. You can click and choose any radio station to play it. 2) Click to choose the program type.
2.9.1 Connection You can connect your mobile phone with the original USB cable in any page or click the Zlink icon in the application page, it is automatically recognized as Android or Apple as shown below: 2.9.1.1 Andriod Auto connection The Android Auto app should be downloaded and installed in the mobile phone.
2.9.2 Cautions You can check the activated Zlink mode and version. Click Zlink to open it and then click About to see the activated Zlink mode and version as shown below:...
3. SET UP BASICS Click in the application interface or drop-down menu to enter the settings interface. 3.1 Network and Internet settings Click Network & Internet to access the WiFi connection settings. Turn on the WiFi to see the available WiFi networks. Select the network you need and enter the password to connect.
3.3 Sound Setting Voice settings includes four main functions: Reverse mute, Navi audio channel, Navi volume and Device ringtone: 3.3.1 Reverse mute By default, radio sound is on. When you remove the tick for Reverse mute, sound will be mute. 3.3.2 Navi volume Navigation: the volume of the navigation can be adjusted with the slider.
3.3.3 Device ringtone Device ringtone is the sound of the phone when a call is received through the idMAEDIA device. Set it so that the ringtone sounds when you receive a call.
3.4 System settings In this interface, you can set Language & input and Date & time and check the About Device information. 3.4.1 Languages & input To add a language, click Languages and then click Add a language. Select the language you need and move up the target language to the first place.
If you want to set the date & time and time zone that matches the network, please slide Automatic date & time and Automatic time zone to ON. The date / time / time zone the internet provided after you connected to WiFi will display. If you want to self-define the time / date / time zone, you can slide Automatic date &...
