- Page 1 47cm Wide Under Counter Fridge Freezer Instruction Manual Model number(s): RH47UCFF1 (W)(B)(R)(SS)(C) For Customer Services & Spare Parts please call 0345 208 8750 or visit us at mda.russellhobbs.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
Contents Safety Instructions ………………………………………. Electrical Safety ………………………………………. Transportation & Handling ………………………………………. Installing & Switch on your Appliance ………………………………………. Before Switching On ………………………………………. Product Overview ………………………………………. Unit & Spare Parts ………………………………………. Usage ………………………………………. Temperature Selection ………………………………………. Door Reversal ………………………………………. 10-13 Replacing the Bulb ………………………………………. -
Page 3: Safety Instructions
Safety Instructions Important note: Please read this booklet before installing and switching on this appliance. The manufacturer assumes no responsibility for incorrect installation and usage as described in this booklet. arning: When positioning the appliance, ensure the supply cord is not trapped or damaged. - Page 4 • D o not plug in damaged plugs. • D o not pull, twist or damage the power cable. • D o not plug-in or un-plug the appliance with wet hands to prevent electrical shock. • T his appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
-
Page 5: Electrical Safety
• One-, two- and three -star compartments (if they are presented in the appliance) are not suitable for the freezing of fresh food. • If the appliance is left empty for long periods, switch off, defrost, clean, dry and leave the door open to prevent mount developing within the appliance. -
Page 6: Installing & Switch On Your Appliance
Installing and Switching on Your Appliance • Operating voltage for your appliance is 220-240V at 50Hz. • Before plugging in the power supply, ensure that the voltage on the rating label corresponds to the working voltage of your electrical system in your home. •... -
Page 7: Before Switching On
WARNING! During use, service and disposal of the appliance, please pay attention to symbol similar to the one shown, which is located on rear of the appliance (rear panel or compressor) and with a yellow or orange colour. It’s risk of fire warning symbol. There are flammable materials in refrigerant pipes and compressor. -
Page 8: Product Overview
Product Overview Freezer (4 star freezer rating) Crisper Light & thermostat Feet Adjustable glass shelf Freezer rack Drainage hole Door racks Fixed glass shelf Egg rack & ice cube tray Unit Parts & Spare Parts Before installation, check that all parts detailed in the product overview are present. -
Page 9: Usage
Usage Allow to stand for a minimum of 3 hours before plugging in to the mains The temperature in the appliance is controlled by the temperature control knob located inside the fridge. Rotate the control knob up or down to regulate the temperature inside the fridge. -
Page 10: Door Reversal
Door Reversal You will need to tilt the appliance backward to access the lower hinge which holds screws. Do not tilt more than 45 degrees and do not lay the appliance flat on its side. For your own safety, a minimum of 2 people should lift or tilt this product. Tools Required: Cross headed screwdriver and flat headed screwdriver 1. - Page 11 Door Reversal 3. Take off the middle hinge by removing the screws, support the door and remove the hinge and then the door. Place the door on a cushioned surface. Remove the screw cap covers that are on the left of the unit and fix them on to the opposite side.
- Page 12 Door Reversal 5. Tilt the appliance carefully, no more than 45 degrees and remove the adjustable foot from the left hand side and fit it to the opposite side. Take off the bottom hinge by removing the screws and remove the adjustable foot from the hinge.
- Page 13 Door Reversal 7. Remove the hinge stopper from the bottom of the freezer door and fix it to the opposite side of the freezer door, ensuring it is fixed securely. Then remove the hinge plug from the top of the freezer door and fix it to the opposite side.
-
Page 14: Replacing The Bulb
Replacing the Bulb The light is an energy efficient, long life LED. Therefore should not need replacing throughout the life of the product however if it does it has to be replaced by a qualified engineer. Please call the service team on 0345 208 8750. -
Page 15: Freezer Storage Advice
Freezer Storage Advice • Store fresh food in airtight boxes or wrap in bags or foil which are suitable for freezing. • Do not allow frozen food in to direct contact with food to be frozen. • Pre-frozen food must be placed in the freezer as quickly as possible after purchasing. -
Page 16: Energy Saving Advice
Energy Saving Advice • Do not install the appliance close to sources of heat, such as a cooker, dishwasher or radiator. • Locate the appliance in a cool well-ventilated room and make sure that the air vents are clear. • Try to avoid keeping the doors open for a long time, warm air will enter the cabinet and may cause a build-up of ice as well as affecting the energy consumption. -
Page 17: Maintenance & Cleaning
Maintenance & Cleaning Disconnect the appliance from the power supply before cleaning. Internal Cleaning • Do not pour water over the appliance. • The cavity should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water (5ml to 0.5 litre of water) •... -
Page 18: Defrosting
Maintenance & Cleaning Defrosting Note: Care must be taken when performing the following procedure. Defrost twice a year or when a frost layer of approximately 7 mm (1/4”) has formed. • 2 hours before the defrosting process, set the thermostat knob at the “7” position to make sure the food is at the lowest temperature before removing the frozen foods. -
Page 19: Trouble Shooting
Trouble shooting Problem Solution Check that the appliance is switched on. Check that there has not been a power cut. Check that the plug is not faulty. Check that the fuse has not blown. The fridge/freezer doesn't work Check that the voltage is correct for the appliance. Are there any faults with the socket? For this purpose, try the plug of your appliance by connecting it to a socket which you are sure is working. - Page 20 Trouble shooting Problem Solution Check all the food and drink that is in the fridge/freezer is in date and correctly packaged. If it isn’t then it should be removed immediately or repackaged. Check for spillages on each shelf, rack and drawer. You may need to remove the drawers to check that no spillages have settle underneath them.
-
Page 21: Connection To The Mains Supply
Connection to the Mains Supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC220V - 240V; 50HZ. Check that the voltage marked on the product corresponds with your supply voltage. For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which... -
Page 22: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship you must contact Product Care with the original proof of purchase so a replacement or refund can be arranged. Refund or replacement is at the discretion of Product Care. -
Page 23: Technical Specification
Technical Specification Model number RH47UCFF1 (W)(B)(R)(SS)(C) Rated Voltage 220V – 240V ~ 50Hz Capacity External Dimensions(HxWxD) 845mm x 470mm x 500mm... -
Page 24: Product Fiche
Product Fiche Model RH47UCFF1 (W)(B)(R)(SS)(C) Fresh Food Storage Compartment Volume (L) Frozen Food Storage Volume (L) Storage Temperature ( ° C) 0 – 8 & -12 to -26 Energy Consumption (kWh/per year) 210Kwh/y Energy Consumption (kWh/per year), based on standard test results for 24 hours... -
Page 25: Notes
Notes... - Page 26 Notes...
- Page 27 Notes...
- Page 28 Russell Hobbs is a registered trademark used under license from Spectrum Brands (UK) Ltd. Made under license by G2S Limited, Wigan, WN2 4AY/G2S (NI) Ltd, Belfast, BT5 5AD. Russell Hobbs Support: call 0345 208 8750 or visit: mda.russellhobbs.com The ‘wheelie bin’ symbol is known as the 'Crossed-out wheelie bin Symbol'.
