Operating Instructions
Fibre Panel Heater with WiFi
Model: GFP215

Advertisement

loading
Need help?

Need help?

Do you have a question about the GFP215 and is the answer not in the manual?

Questions and answers

Related Manuals for Coldair GFP215

Summary of Contents for Coldair GFP215

  • Page 1 Operating Instructions Fibre Panel Heater with WiFi Model: GFP215...
  • Page 2 General Care and Safety Guide YOUR SAFETY IS IMPORTANT TO US. PLEASE ENSURE YOU TAKE NOTE OF THE INSTRUCTIONS AND WARNINGS OUTLINED IN THIS MANUAL. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
  • Page 3 General Care and Safety Guide • Never use the appliance to dry clothes. • Always unplug appliance when not in use. • When the appliance has been unpacked, check it for transport damage and ensure all parts have been delivered. If parts are missing or the appliance has been damaged, contact the Customer Services Team.
  • Page 4 General Care and Safety Guide • The appliance must not be immersed in any liquids. • There are no user serviceable parts installed in the unit. • Do not place the unit in wardrobes or other enclosed spaces as this may cause fire hazards.
  • Page 5 Wall Mounting & Position Instructions Always choose a safe location for the heater, keeping in mind the safety precautions outlined below. The heater needs to be mounted so that the power switch is in the top right hand corner. Do not run the power cord behind the heater. This will determine where you mount the heater in relation to where the power socket is located.
  • Page 6 Wall Mounting & Position Instructions cont. The appliance must not be located immediately below a socket outlet. The panel heater must be mounted on the wall with the power switch in the top right hand position as shown below. THIS WAY UP Note: Do not run power cord behind the heater.
  • Page 7 Wall Mounting & Position Instructions cont. NOTE: Your Panel Heater should be installed with at least 300mm clearance from the floor and any other surrounding parts including other appliances, side walls, ceilings, shelves and soft furnishings. 1. Mark the positions of the four holes to be drilled on the wall. Ensure there is a 300mm clearance on all sides of the heater.

  • Page 8: Operating Your Heater

    Operating Your Heater Always choose a safe location for the heater, keeping in mind the safety precautions outlined. Ensure all packaging has been removed from the unit before use. Please follow the below instructions. WARNING: In order to avoid overheating or fire, do not cover the heater. WARNING: Keep all objects at least 1 metre from the front and 300mm from the sides of the appliance.
  • Page 9 Operating Your Heater Your Panel Heater will provide background warmth. This Panel Heater is designed to take the chill off the room. The surface of this Panel Heater can be painted with good quality paint (acrylic or enamel). Decorating tip: All wall mounted heaters may cause paint to discolour or wallpaper to lift.
  • Page 10 Operating your Appliance continued Press the ON/OFF button on the display panel once and the "ON" indicator will display on the LCD screen. The heater is in the power-on state. If the ambient temperature is below 25℃, the heater will heat. If the ambient temperature is above 25℃, you will need to set the temperature to a higher temperature before the heater will start to heat.
  • Page 11 WiFi – Downloading and Setting up APP This APP is supported only on 2.4GHz Wi-Fi channels. Please ensure your phone is 2.4GHz capable Note this device will only work within your home WIFI system. This does not operate on 3G or 4G internet connections. You will need a connection to your home Wi-Fi.
  • Page 12 Pairing APP to Device Details for pairing this heater to the Goldair App can be found at the below website link. Either scan the QR code below or enter the website into your browser. New Zealand Products Australia Products https://www.goldair.com.au/ https://www.goldair.co.nz/ goldair-app goldair-app...
  • Page 13 Operating Your Heater SAFETY DEVICES This appliance has two protection devices: • Resettable Thermal Links - this will automatically disconnect the power to the appliance at a pre-set overheat temperature. After cooling down it will reset and power on again. If this occurs, investigate what is causing the appliance to overheat.

  • Page 14: Three Year Warranty

    Three Year Warranty Thank you for purchasing this Goldair product. Your product is warranted against faults and manufacture when used in normal domestic use for a period of three years. In non-domestic use Goldair limits the voluntary warranty to three months. Goldair undertake to repair or replace this product at no charge if found to be defective due to a manufacturing fault during the warranty period.
  • Page 16 New Zealand PO Box 100707, North Shore Mail Centre, Auckland, 0745 www.goldair.co.nz Australia PO Box 574, South Morang, Victoria, 3752 www.goldair.com.au...
