- Page 1 SIP 12T Hydraulic Pipe SIP Industrial Products Limited Gelders Hall Road Shepshed Bender Loughborough Leicestershire LE12 9NH 03683 United Kingdom For help or advice please contact your distributor, or sip directly on: Tel.: 01509 500400 Email:sales@sip-group.com or technical@sip-group.com www.sip-group.com...
-
Page 3: Table Of Contents
CONTENTS Page No. Description Contents Safety Instructions Guarantee Operating Instructions Maintenance Exploded Drawing Part List Notes Notes UK - Declaration Of Conformity EU - Declaration Of Conformity... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Danger / Caution: This picture indicates risk of personal injury and/ or the possibility of damage. Note: This picture indicates supplementary information. Important: Please read the following instructions carefully, failure to do so could lead to serious personal injury and / or damage to the item. - Page 5 SAFETY INSTRUCTIONS...cont DANGER! Check that the product is in sound condition and good working order; Take immediate action to repair or replace damaged parts. WARNING! Only operate on a level and stable surface and never use on soft ground where the product is likely to “sink” whilst in operation. NEVER STAND ON THE PRODUCT: The product is not designed for this purpose.
-
Page 6: Guarantee
GUARANTEE This SIP Pipe Bender is covered by a 2 year parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or... - Page 7 OPERATION The tool is provided with six Bending Formers. This enables the following sizes of British Standard Pipe, to BS1387, to be bent to any angle up to 180 degrees. 1/2 , 3/4, 1, 1-1/4, 1-1/2, and 2 inches Consult the chart below to ensure the correct die for the corresponding pipe is used. If the wrong former is used, the quality of bend will be severely compromised.
- Page 8 OPERATION...cont The Hydraulic Pipe Bender is designed for bending STEEL PIPE ONLY, either galvanised or black finish. Please familiarise yourself with its operation, so that it may be used properly in order to provide you with long and satisfactory service. CAUTION: This bender is not designed to bend thin wall tube - e.g.
-
Page 9: Maintenance
Always visually inspect before each use to ensure no welds are cracked or broken, and that the tool is in good general condition. If it is damaged or if in doubt as to its serviceability, consult SIP After Sales - 01509 500400 or your local SIP dstributor. -
Page 10: Exploded Drawing
EXPLODED DRAWING... -
Page 11: Part List
PART LIST Ref. No. Description Sip Part No. R-clip HY02-00125 Washer HY02-00126 Roller HY02-00127 HY02-00128 Bolt (M10x30) HY02-00129 Washer M10 HY02-00046 Spring washer M10 HY02-00047 Nut M10 HY02-00048 Spring HY02-00130 Plate HY02-00131 Pump HY02-00132 Handle HY02-00133 Frame HY02-00134 1/2” Pipe former HY02-00135 3/4”... -
Page 12: Notes
NOTES... -
Page 13: Notes
NOTES... -
Page 14: Uk - Declaration Of Conformity
England As the manufacturer within the UK, England, Scotland & Wales, declare that the SIP Ton Hydraulic Pipe Bender - SIP Part No. 03683 Conforms to the requirements of the following regulation(s), as indicated. Supply of Machinery (Safety) Regulations 2008... -
Page 15: Eu - Declaration Of Conformity
Republic of Ireland As the manufacturer’s authorised representative within the EC declare that the SIP 12 Ton Hydraulic Pipe Bender - SIP Part. No. 03683 Conforms to the requirements of the following directive(s, as indicated. 2006/42/EC - Machinery Directive And the relevant harmonised standard(s), including... - Page 16 FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP Please dispose of packaging for the product in a DIRECTLY ON: responsible manner. It is suitable for recycling. Help TEL: 01509 500400 to protect the environment, take the packaging to EMAIL: sales@sip-group.com or...
