Foldable Engine Cranes
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the environ-
ment, take the packaging to the local amenity tip and place
into the appropriate recycling bin.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
03685 & 03687
TEL: 01509500400
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
Ref: 080519
24
Advertisement
Table of Contents
Related Manuals for SIP 03685
Summary of Contents for SIP 03685
- Page 1 FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: 03685 & 03687 TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
- Page 2 As the manufacturer's authorised representative within the EC declare that the 1 Ton Foldable Engine Crane - SIP Part No. 03685 2 Ton Foldable Engine Crane - SIP Part No. 03687 Conforms to the requirements of the following directive/s, as indicated.
-
Page 3: Table Of Contents
HY01-00722 Washer M12 Getting to Know Your Engine Crane Spring washer M12 Nut M12 Assembly Instructions Bolt (M16x80) Operating Instructions Bolt (M16x110) Maintenance Troubleshooting Exploded Drawing 03685 & 03687 Parts List - 03685 Parts List - 03687 Declaration of Conformity... -
Page 4: Washer M16
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL PARTS LIST - 03685 Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. Danger / Caution: Indicates risk of personal injury and/or the possibility of Castor (3½") HY01-00710 Bolt (M16x90) damage. - Page 5 EXPLODED DRAWING 03685 & 03687 SAFETY INSTRUCTIONS….cont WARNING! Only operate on a level and stable surface and never use on soft ground where the engine crane is likely to “sink” whilst in operation. NEVER STAND ON THE ENGINE CRANE: The engine crane is not designed for this pur- pose.
-
Page 6: Guarantee
Discontinue use, contact tion. supplier. These SIP engine cranes are covered by a 12 month parts and labour warranty cover- ing failure due to manufacturers defects. This does not cover failure due to misuse or Reservoir overfilled. - Page 7 NOTES CONTENTS & ACCESSORIES CLEANING 03685 1 Ton Engine Crane Periodically check the hydraulic ram piston for signs of rust or corrosion. Clean as Box-P1 needed and wipe with an oily cloth. Leg (x2) Support (x2) Post Boom Boom Extension...
-
Page 8: Technical Specifications 03685
TECHNICAL SPECIFICATIONS - 03685 MAINTENANCE….cont ADDING OIL Recommended Oil - ISO 15. Oil Capacity (approximately) - 03685 700ml, 03687 1407ml. ¼T Max Step 1: Lower the hydraulic ram so its at its lowest position (turn the release valve anti- ½T Max ¾T Max... -
Page 9: Technical Specifications 03687
OPERATING INSTRUCTIONS….cont TECHNICAL SPECIFICATIONS - 03687 Step 4: On the bottom of the hydraulic ram there is a release valve, put the ram han- dle onto the release valve and turn it fully clockwise to close it. Step 5: Insert the ram handle into the slot on the bottom of the hydraulic ram and pump repeatedly until the engine has been lifted to the desired height and is clear of any obstructions. -
Page 10: Getting To Know Your Engine Crane
GETTING TO KNOW YOUR ENGINE CRANE OPERATING INSTRUCTIONS PRE-OPERATION CHECKS Inspect before each use. Do not use if broken, bent, cracked or damaged parts are noted. If the engine crane appears damaged in any way, or operates abnormally it should be removed from service immediately. If the engine crane has been or sus- pected to have been subjected to a shock load (a load dropped suddenly, unex- pectedly upon it), immediately discontinue use until the engine crane has been checked by an authorised service centre / agent (contact your distributor or manufac-... - Page 11 ASSEMBLY INSTRUCTIONS….cont ASSEMBLY INSTRUCTIONS Note: Do not tighten any bolts/nuts until the assembly has finished, this will ensure that the frame lines up correctly. Washer Step 9: Fit the bottom of the hydraulic ram between the slot on the lower post (see Caution: Due to the size and weight of the engine crane and compo- right), secure by using 1x M16x90 bolt, 1x nents;...
- Page 12 ASSEMBLY INSTRUCTIONS….cont ASSEMBLY INSTRUCTIONS….cont Base Step 7: Secure the supports to the in- side of the base by using the 2x Bolt M16x100 bolts, 2x M16 washers and 2x Washer M16 nuts. Next, secure the top end of Step 4: Slide both legs into the base. the supports to the post by using 1x M16x110 bolt, 1x M16 washer and 1x Legs...
