Quick Start Guide
PR-600 Series
HPRT-HT100
Appearance and Components
Front View
Printer Cover
Cover Open Levers
Rear View
Power Switch
Power Receptacle
USB Port
Inside View
Printhead Module
Moveable Roll Holders
Locking Tab
Platen
！
Note: The views above are for your reference. Ports vary
by your choice.
Rev.1.0
Feed Button
(Status Indicator)
Ethernet Port
Serial Port
Kick-stand Cover Lock
Moveable Label Guides
Moveable Label Sensor
Printer
USB Cable
CD
！
Note: The packing materials are actually based on the order.
Loading the Roll
1.Pull and lift the cover.
2.Pull the roll holders open and place the roll between
them.
-1-
Power Cord
AC Adapter
Ribbon
Label Roll
Quick Start Guide
Quick Start Guide
Advertisement
Related Manuals for IDZOR HPRT-HT100
Summary of Contents for IDZOR HPRT-HT100
- Page 1 Quick Start Guide Power Cord AC Adapter Printer PR-600 Series HPRT-HT100 Ribbon Label Roll USB Cable Quick Start Guide Quick Start Guide ！ Note: The packing materials are actually based on the order. Appearance and Components Loading the Roll Front View 1.Pull and lift the cover.
- Page 2 2.Connect the AC adapter to power receptacle. 3.Connect the power cord to AC adapter. 4.Connect the other end of power cord to the outlet. Power Cord AC Adapter Varies by regions ！ Note: Please refer to windows driver installation in PR-600 Series HPRT-HT100 User Manual. Rev.1.0...
