This quick installation guide describes the procedure
of installing the WLAN AP of WL8200-WH2.
It includes the basic introduction, installation procedure,
and the suggestion of initial conÀguration, etc. It provides
the wireless hotspot service of WiFi for users.
This quick installation guide faces the engineers who
need to install the product and deploy the network
equipment. The engineers should comprehend the basic
local area network knowledge and the wireless network
and equipment knowledge.
Yunke China Information Technology Limited
Add: Digital Technology Plaza 3F, Shangdi nine street. 9th,
Haidian District, Beijing.
Postcode: 100085
WL8200-WH2
WALL AP
Advertisement
Related Manuals for DCN WL8200-WH2
Summary of Contents for DCN WL8200-WH2
- Page 1 WL8200-WH2 WALL AP This quick installation guide describes the procedure of installing the WLAN AP of WL8200-WH2. It includes the basic introduction, installation procedure, and the suggestion of initial conÀguration, etc. It provides the wireless hotspot service of WiFi for users.
- Page 2 The panels of WL8200-WH2 are shown as below:...
- Page 3 The explanation of the front panel is shown as below: The explanation of the back panel is shown as below: Uplink(POE) The explanation of the side panel is shown as below: Power interface, which is connected to the power adapter. (input 48V 0.22A DC).
-
Page 4: Wall Installation
Wall installation The wall installation method is used for WL8200-WH2 and the steps are shown as below: Step 1: Fix the mounting bracket and the cassette in the wall with the screws. Attention: the side of the bracket with a hook must be installed in left. - Page 5 Step 3: Fix the chassis to the wall according to the corresponding position of the screws and the lugs, Àxed AP with screws in AP left.
- Page 6 Supply power for AP WL8200-WH2 supports POE or power adapter. These two methods can be used at the same time. If the POE power is used, the POE switch should be used for power supporting. If the power adapter is used, user should buy the adapter.
- Page 7 The installation engineers need to tear out the MAC address label on AP to stick it in the following table and record the actual position of AP in collection. XX F in XX WL8200-WH2 Building XX.
- Page 8 1.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 2.changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 9 The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. The equipment should be installed and operated with minimum distance 20cm between the radiator & your body. And operations in the 5.15-5.25GHz band are restricted to indoor usage only. DC YunKe Networks Co.,Ltd.
