Quick Installation Manual
Packing List
AP(1)
Mounting Kit(1)
1
Equipment Introduction
Device Port and Indicator
2
No
Name
Ethernet Port（48V POE）
1
ETH
Reset Button, Press to Restart;
2
Reset
Press more than 5 seconds
reset to factory default
EAP280-L
Mounting Plate(1)
M4X30(2)
Quick Installation
Manual(1)
1
Description
Expansion
Tube(3)
Qualification
Card(1)
5
6
No
Name
Light Always On: System Normal
3
PWR
Light Always On: Wireless enabled
4
WLAN
Light Flash: Data is transferring
Light Always On: Wireless
5
ETH
connection stable
Light Flash: Data is transferring
Reserved LED
6
ST4.2X25(3)
Warranty Card(1)
DCN Products Warranty Card
4
3
Description
Advertisement
Table of Contents
Related Manuals for DCN EAP280-L
Summary of Contents for DCN EAP280-L
- Page 1 ST4.2X25(3) Mounting Kit(1) Expansion Tube(3) M4X30(2) Quick Installation Qualification Warranty Card(1) Manual(1) Card(1) DCN Products Warranty Card Equipment Introduction Device Port and Indicator Name Description Name Description Ethernet Port（48V POE） Light Always On: System Normal Reset Button, Press to Restart;...
-
Page 2: Equipment Installation
Equipment Installation Preparing for Installation Before installation, installation personnel must take the necessary safety measures to ensure personal safety Do not put AP and Tool on walkways to avoid damage Device support wall mounting and ceiling mounting，make sure the ceiling and walls can bear safety before installation Installation may need tools listed on the below picture.(Tools need to self prepared) Ladder... -
Page 3: Ceiling Mount
Ceiling Mount Attention Ceiling mount need to use screws which is 30mm long. It is suitable for 15 mm thick ceiling. When need to use for thicker ceiling, customers need to prepare for longer screws. Warning Ceiling mount need to use covert security installation to prevent AP take off from the mount. ≤15mm Take down the ceiling and use 4mm drill to open two hole on ceiling. -
Page 4: Fcc Notice
FCC Notice Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 5 EAP280-L Indoor Wireless AP...
-
Page 6: Product Overview
Intelligent RF management mobile access, quality of service (QoS) guarantee, and seamless roaming, the EAP280-L may be used with DCN wireless ACs to DCN smart APs may be used with a wireless AC to perform perform data forwarding, security, and access control of wireless automatic power and channel adjustment. - Page 7 Intelligent identification of terminals ► Secure user admission DCN smart APs may be used with DCN wireless ACs and a unified authentication platform to intelligently identify the size, DCN smart APs may be used with wireless ACs to provide multiple system type, and type of each terminal;...
-
Page 8: Product Specifications
RF monitoring and real-time spectrum protection. By implementing communications and data collection through DCN smart APs may work in fit or fat mode and can flexibly the respective AP, the RF collection module performs wireless switch between the fit mode and the fat mode according to environment quality monitoring, wireless network capability network planning requirements. - Page 9 EAP280-L Software Specifications Item Feature EAP280-L Product positioning Indoor single-frequency Working frequency band 2.4 GHz Maximum number of access users Virtual AP (BSSID) Number of spatial streams Dynamic channel adjustment (DCA) Transmit power control (TPC) Blind area detection and repair...
- Page 10 EAP280-L Item Feature EAP280-L Encryption 64/128 WEP, dynamic WEP, TKIP, and CCMP encryption 802.11i WAPI MAC address authentication LDAP authentication PEAP authentication WIDS/WIPS Real-time spectrum protection Protection against DoS attacks Anti-DoS for wireless management packets Forwarding security Frame filtering, white list, static blacklist, and dynamic blacklist...
- Page 11 (PoE module need to be separately purchased.Don’t support local power) DCWL-PoEINJ-G+ 10/100/1000 Mbps 1-port 802.3at PoE module Optional Contact us Digital China Networks Limited For more detail information about DCN product, contact: URL: http://www.dcnglobal.com Email: sales@dcnglobal.com Address: Digital Technology Plaza, NO.9 Shangdi 9th Street, Haidian District, Beijing, China...
