Summary of Contents for Mimosa 0082322
- Page 1 OUTDOOR GAS HEATER TALL FLAME-MATTE BLACK Provides warmth and ambiance for outdoor settings AGA Gas Certified 0082322 0082322 GFH004 Important: Please retain these instructions for future use...
- Page 2 Gas Leak Test Gas connections on the heater are leak tested at the factory prior to shipment. A complete gas tightness check must be performed due to possible mishandling in shipment or excessive pressure being applied to the heater gas connections. 1.Make a soap solution of one part liquid detergent and one part water.
- Page 3 WARNING WARNING WARNING DANGER WARNING WARNING WARNING...
-
Page 4: Table Of Contents
Table Of Contents Caution ............Page 1 Heater Location ..........Page 2 Gas Requirements......... Page 4 Leakage Test..........Page 4 Operation and Storage......... Page 5 Cleaning and Care ........Page 6 Parts and Specifications ....... Page 6 Assembly Parts ..........Page 8 Assembly Steps .......... -
Page 5: Caution
Caution PLEASE READ CAREFULLY THE FOLLOWING SAFETY GUIDELINES BEFORE OPERATION. Page 1... -
Page 6: Heater Location
Heater Location The heater is primarily for outdoor use only (see diagrammatical representations of outdoor areas). Do not use it for indoors or in an enclosed area. Always ensure that adequate fresh air ventilation is provided. Do not use the heater for heating inside domestic premises. Do not use the heater in the basements or below ground level. - Page 7 Both ends open 30 percent or more in total Open side at least of the remaining wall area 25% of total wall area is open and unrestricted Page 3...
-
Page 8: Gas Requirements
Open side at least 30 percent or more in total 25% of total wall area of the remaining wall area is open and unrestricted Gas Requirements Refer to the Data label for confirmation of the gas type to be used with your appliance. Use only the pressure regulator and hose assembly supplied with this appliance. -
Page 9: Operation And Storage
Operation and Storage After approximately 10 seconds, release the control knob. maximum Warning: check that the glass is not broken before operation. Off: the heater stop work Hi: maximum temperature position Lo: minimum temperature position lgniter Igniter Variable control knob Disconnect the regulator from the gas cylinder valve. -
Page 10: Cleaning And Care
Cleaning and Care Wipe off powder coated surfaces with soft, moist rag. Do not clean heater with cleaners that are combustible or corrosive. Remove debris from the burner to keep it clean and safe for use. If carbon deposits and glass tube goes black, remove the safety guard and clean it with soapy water. Instructions for cleaning the glass, should it require cleaning on the inside. - Page 11 A . Construction and characteristics Heater with dancing flame enclosed in transparent glass tube Heat emission from the reflector Heat diffuser provides more warmth. Tilt switch shuts off heater automatically when appliance is accidentally knocked down B . Specifications For outdoor use only Gas type –...
-
Page 12: Assembly Parts
Assembly Parts Tools needed: Philips screwdriver w/ medium blade Spray bottle of soap solution for leakage test Parts List: Reflector Damper Top plate Glass Tube Upper Leg Support Protective Guard Black Silicone Ring Control Box Assy Lower Leg Support Side Panel Cylinder Securing Strap Bracket Front Panel... - Page 13 Assembly Parts HARDWARE CONTENTS Wing nut Reflector spacer Flat 3/16” Screw Screw Qty. 3 Qty. 3 washer Qty. 42 M5 X 12 Qty. 6 Qty. 6 Philips Knob Stud screwdriver Fixing Bracket Qty. 1 Qty. 3 Qty. 1 Qty. 4 Page 9...
-
Page 14: Assembly Steps
Assembly Steps 1. Insert the locator pins of the base into the holes on the lower leg support and press to secure. Using 4 pcs screw M5x12 to secure the lower leg support and base. Insert the locator pins on the control box assembly to the holes on the lower leg support and press to secure. - Page 15 3. Assemble the upper leg support. Insert the 4pcs upper leg support to the lower leg support. Secure them with 8 pcs screw 3/16”. Hardware Used 3/16” Screw Philips screwdriver 4. Assemble the top plate to the upper leg support. Secure the top plate to upper leg support using 8pcs screw 3/16".
- Page 16 5. Carefully install the glass tube by lifting up and inserting through the center hole in the upper plate. Ensure the black silicone ring is attached to the lower edge of the glass tube as illustrated. Slide the glass tube through the hole of the lower plate cover and onto the To aid in installation middle plate.
- Page 17 7.1 Put the damper plate onto 3pcs stud then use the 3pcs reflector spacers to secure it. 7.2 Put the 3pcs Ø8 washer on the top of 3pcs spacer and put reflector onto spacers, and secure them with 3pcs Ø8 washer and 3pcs M8 wing nut.
- Page 18 9. Attach the three side panels to the heater using 18pcs screw 3/16”. Note : Do not cover the front side where the control knob is. Hardware Used 3/16” Screw x 18 Philips screwdriver 10. Install the knob to M4x6 screw. Hang the chain from the inside front panel to the hole on the control box assembly.
- Page 19 11. Hose connection (Propane Only) After the cylinder is placed inside the heater, secure the cylinder with the strap then connect the regulator to the gas cylinder. Ensure this connection is done correctly. WARNING! Ensure the hose does not contact any high temperature surfaces, or it may melt and leak causing a fire.
- Page 20 13. Leak Check. WARNING! of the gas system is replaced. WARNING! erty, serious bodily injury, or death. manifolds and valves. If the leak cannot be stopped, Hose / Regulator connec on Regulator / Cylinder connec on Page 16...
-
Page 21: Pilot Service
Pilot Service The pilot burner should produce a small blue burner Follow these steps to service the pilot burner: Page 17... - Page 22 3/ Remove the 4 cover panel screws inside the cylinder housing. 4/ Raise the cover panel. 5/ Remove the screws and nuts which secure the control system to access the pilot burner. Page 18...
- Page 23 To service the pilot burner, insert a pipe cleaner into the air holes at the base of the pilot tube, and in the pilot burner tube as shown below to clear spider webs or nests. Blow air through the pilot burner tube and through the air holes at the base of the pilot tube to clear the pilot burner of dead moths or...
-
Page 24: Problems Check List
Problems Check List PROBLEM PROBABLE CAUSE SOLUTION Pilot will not light Gas valve may be OFF Turn the gas valve ON Tank fuel empty Refill LPG tank Opening blocked Clean or replace opening Air in supply system Purge air from lines ose connections Check all fittings The battery in igniter exhausted... -
Page 25: Product Warranty
P R O D U C T W A R R A N T Y Any claim under this warranty must be made within 12 Months of the date of purchase of the product. To make a claim under the warranty, take the product (with proof of purchase) to any Bunnings store (see www.bunnings.com.au or bunnings.co.nz for store locations)
