Toky CA-X Series Instruction Manual

Digital Counter
CA-X series
C A- X Se rie s Digit al Cou nte r
INSTRUCTION MANUAL
Thank you for purchasing TOKY products. Please
read the instruction manual carefully before using this
product, and use the product correctly. Also, please keep
this instruction manual where you can view it any time.
I. Suffix Code
Model Code
□ □ □ □ □
CA -
4
Size 7
8
-
Power
voltage
F
Alarm RB
Display digits 6
0
Communication
8
Version
II. Technical Parameter
Power Supply
Total Power Consumption
Relay Capacity
Output Power
Insulation Resistance
Insulation Strength
Anti-interference
Input Signal (sine wave,
square wave)
Counting Input Speed
Counting Range
Delay Time
Coefficient Setting Range
External Signal
TOKY ELECTRICAL CO., LTD.
No.8, Minke West Road, Shiqi District,
Zhongshan City,
Guangdong Province,
China
TEL: +86-760-23371807
http://www.toky.com.cn
KKCAX-A01C-20180120
Content
□
X- CA-X series digital counter
48(W) X 48(H) X 91(D) mm
72(W) X 72(H) X 88.5(D) mm
96(W) X 48(H) X 88.5(D) mm
AC/DC 100~240V
AC/DC 24V
1 relay output
6 digits display
No communication
RS485 communication
X-A Version A
A C / D C 1 0 0 ～2 4 0 V 5 0 / 6 0 H z
≤ 4 W
A C 2 5 0 V / 3 A
D C 1 2 V ± 5 V ( ≤2 5 m A )
≥ 2 0 M Ω
A C 2 k V
Power:3000Vp-p、I/0 terminal:1000Vp-p
Signal Level: Hight:3~30V Low:0~2V
≤ 1 / 3 0 / 3 0 0 / 5 0 0 0 H z (4 s p e e d
s e l e c t a b l e )
-199999~999999
0 . 01 ~ 4 9 9 . 9 9 s
0 . 00 0 0 1 ~ 9 9 9 9 9 9
Ex te r n a l r e s e t f r e q u e n c y
1、2 0 m s s e l e c t a b l e
III. Panel Illustration
Operation indicator
OUT: Turns on
during output
operation
OUT
SET
S E T
SHIFT
Name
(1) Menu key: press it 3 sec to enter or exit setup mode．
Set key
S E T
(2) Confirm key: confirm and save the modified set value.
Reset key In operation mode, press it to reset PV.
RST
Up key In modification state, press it to increase set value.
(1) In operation mode or setup mode, press it to
activate the set value modification.
Shift key
(2) In modification state, press it to move set
value row.
Note: If there is no operation for long time, meter will automatically
return back to measuring state (set parameter is not saved.)
IV. Dimension & Panel Cutout
Panel Size
A
D
B
Classification
A
B
CA4:(48×48) 48 48
CA7:(72×72) 72 72
CA8:(48×96) 96 48
Remark Unit：(mm) tolerance +0.5% (unless there is special
specific illustration)
V. Connection Diagrams
CA4
AC/DC
OUT
100~240V
5 4 3 2 1
10 9 8 7 6
RST GND +12V INB INA
OUT
1 2 3
Note: If there is any change, please subject to the drawing on the meter.
1
PRESENT VALUE
(1) Display present value in
operation mode
(2) Display parameter code
PV
in setup mode
SET VALUE
SV
(1) Display set value in
operation mode
(2) Display parameter set
value in setup mode
RST
5
RESET
UP
Content
Side Size
C
E
+0.5
J
-0
K
F
Panel dimension Panel cutout
G
C D E F H(Min)
97.5 6.5 91.0 45 45.5
97.5 9.0 88.5 67 67.5
97.5 9.0 88.5 44.5 92
CA7
INA INB +12V GND
1 2 3 4
13 14
AC/DC
100~240V
CA8
AC/DC
100~240V
9
15 16 17 18 19
INHIBIT RESET GND +12V INB
Cutout Size
+0.5
G H
-0
J
K(Min)
25 45.5 25
25 67.5 25
25 45 25
RESET INHIBIT
5 6
1 7 1 8 1 9
OUT
10
2 0
INA
