Toky CI Series User Manual

CI Series Multi-function Counter
CI Series Multi-function Counter User Manual
For your safty, please read following content carefully before you are using our Meter!
1. Model Illustration
CI□□-R C 0
□□ 0: Without Communication 8: With RS485 Communication
Display Digit: 6: 6 digit
Alarm Output: C: Two Alarm
Control Ouput: R: Relay Output
Power Supply: Blank: 100-240V AC/DC F: 24V DC
Dimension(mm):
CI Series Multi-function Counter
Page 01
Features:
⊙Counting Speed can reach 10KCPS
⊙Free Setting Ratio 0.00001～999999
⊙Universal Input, Choose NPN or PNP
input through Software
⊙Up to two Counting / Length Counting alarm output,
one Batch Counting alarm output;
⊙Applicable to Light Industries, Machinery, Packing,
Food industries, etc. for control of Length and counting etc
S
4: 48H x 48W x 94.5L 7: 72H x 72W x 94.5L
8: 48H x 96W x94.5L 80: 80H x160W x83L
2. Model Type
No.
1
2
3. Technical Specification
Fluctuation range of Allowed Voltage
Input Frequency of INA, INB
Width of Input Pulse
Control Output
Power of External Sensor
Interferance (AC Power)
Vibrate
Impact
Using Life
4. Panel Indication
PS1: Lower line displays OUT1 setting value
PS2: Lower line displays OUT2 setting value
BA.S: Upper line displays batch counting value
Lower line displays batch setting value
KKCIE01-A/2-20140318
Model Size (mm) Output
Display Digit Alarm Output
80H×160W 6
CI80-RC60 Relay Output
CI80-RC68
80H×160W Relay Output 6
6
CI8-RC60 48H×96W Relay Output
6
CI8-RC68 48H×96W Relay Output
CI7-RC60
Relay Output
72Hx72W 6
CI7-RC68
72Hx72W Relay Output
6
Relay Output
CI4-RC60 48Hx48W 6
CI4-RC68 48Hx48W Relay Output
6
CI
Series
Display Dual Line 6 digit
Power Supply 100-240V AC/DC
90～110% of Rated Voltage (AC Power)
1Hz、30Hz、1KHz、5KHz、10KHz can be choosed
INA,INHIBIT,RESET,BATCH RESET,can choose 1ms or 20ms
Voltage Input: input impedance 5.4KΩ,"H"：5～30VDC
Input
No-voltage Input: for Short-circuit impedance is 1KΩ, Residual Voltage: Max 2V DC,
Open-circuit impedance Max 100KΩ
10/50/100/200/500/1000/2000/5000ms
One-shot Output
NO:250VAC 3A Impedance NC：250VAC 2A Impedance
Contact Capacity
Max: 30VDC ， Max: 100mA
SSR Capacity
10 Years
Data Saving Time
Less than 100mA
12VDC±10%
Ambient Temperature
-10℃～50℃ Unfreezing State
Storage Temperature
-25℃～65℃ Unfreezing State
Ambient Humidity 35-85%RH
Min: 100MΩ (at500VDC)
Dielectric Strength
2000V AC 50/60Hz one minute
Dielectric
±2kV Square-wave generator interference (width of pulse: 1us)
Mechnical Amplitude:0.75mm Frequency: 10-55Hz X,Y,Z each direction for one hour
Fault Amplitude:0.5mm Frequency: 10-55Hz X,Y,Z each direction for ten minutes
2 (about 30G) X,Y,Z each direction for three times
Mechnical 300/S
2 (about 10G) X,Y,Z each direction for three times
Fault 100/S
more than 10,000,000 times
Mechnical
more than 100,000 times (NO: 250V AC 3A Load
Electrical
CI7 SERIES COUNTER
Reset Key
Batch setting Key
Function Key
Parameter change Key
Page 02
Batching Output Communication
2
One Relay NO
RS485
One Relay
2
One Relay NO
One Relay RS485
One Relay
NO
One Relay RS485
NO NO
RS485
NO
"L":0～2VDC
NC: 250V AC 2A Load)
Lock: Button lock indication
OUT1, OUT2: OUT1 or OUT2 output indication
BA.O: Batch output indication (CI4 do not with this lamp)
KKCIE01-A/2-20140318
