Denver - 3 Door Mirror Robe

Assembly Instructions -

Dimensions

Width - 113.5cm

Depth - 50cm

Height - 181cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800

Please keep for future reference

360/2546

335/9806

359/7596

MADE IN

BRITAIN

Issue 3 - 13/07/15

Need help?

Do you have a question about the 360/2546 and is the answer not in the manual?

Questions and answers

Summary of Contents for Denver 360/2546

Page 1 Denver - 3 Door Mirror Robe Assembly Instructions - 360/2546 Please keep for future reference 335/9806 359/7596 Dimensions Width - 113.5cm Depth - 50cm MADE IN Height - 181cm BRITAIN Important - Please read these instructions fully before starting assembly...
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 80kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base (DF1877A) (1105 x 494mm) Horizontal (DF3100A) (718 x 470mm) Left Side Right Side Divider...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the left side Screw 6 metal dowels into the left side Push a rail holder into Finished the left side .
Page 6 Assembly Instructions Step 3 Prepare the 2 top and base panels Tap 2 wooden dowels into each of the top and base panels Note: Wooden dowels must not stick out from Finished front edge the edge by more than 10mm or they may damage other panels.
Page 7 Assembly Instructions Step 5 Fit the 2 vertical rails Attach each of the vertical rails to the and base using 4 screws Step 6 Prepare the divider Screw 2 metal dowels into the divider Push a rail holder into the divider .
Page 8 Assembly Instructions Step 7 Fit the 2 divider Attach the divider the top and base using 4 screws Step 8 Prepare the horizontal Tap 2 wooden dowels into the horizontal Insert 4 large locking nuts into the Finished horizontal front edge Step 9 Fit the horizontal Push the horizontal...
Page 9 Assembly Instructions Step 10 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the top , base the horizontal Step 11 Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the sides...
Page 10 Assembly Instructions Step 12 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back panels Square up the unit by making sure that measurement x:x equals y:y.
Page 11 Assembly Instructions Step 13 Fit the hanging rail and shelves Push the hanging rail into the rail holders fitted to the side panels. For each of the 3 shelves , insert 4 shelf studs Lower the 3 shelves down onto the shelf studs...
Page 12 Assembly Instructions Step 14 Fit the brackets to the vertical rails Fit one bracket to the vertical rail horizontal using screws Fit second bracket the other vertical rail and the divider using screws Step 15 Prepare the 3 doors Warning: Lay the doors down onto Glass! Handle with care...
Page 13 Assembly Instructions Step 16 Fit the 3 doors Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 14 Assembly Instructions Step 17 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
Page 15 Assembly Instructions Step 18 Screw Fit the overbalance protector Washer Wall fixing Strap (not supplied) To prevent possible Strap Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by use of the overbalance protector kit fitted to the unit or, an alternative fixing method of your choice.
Page 16 IMPORTANT INFORMATION ABOUT THIS PRODUCT This product complies with the requirements of BS 7449:1991 and has been manufactured by DECORATIVE PANELS FURNITURE LTD, TEESSIDE INDUSTRIAL ESTATE, THORNABY-ON-TEES, CLEVELAND, TS17 9LT. The product code for this unit and the item code(s) for the glass components are listed in the Assembly Instructions along with a description of the type of glass used.
