Denver - 2 Drawer 2 Door Robe
Assembly Instructions -
Dimensions
Width - 75cm
Depth - 50cm
Height - 181cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
359/2807
333/6908
362/8685
MADE IN
BRITAIN
Issue 3 - 16/01/15
Advertisement
Related Manuals for Denver 359/2807
Summary of Contents for Denver 359/2807
- Page 1 Denver - 2 Drawer 2 Door Robe Assembly Instructions - 359/2807 Please keep for future reference 333/6908 362/8685 Dimensions Width - 75cm Depth - 50cm MADE IN Height - 181cm BRITAIN Important - Please read these instructions fully before starting assembly...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 52kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Top/Base (D1574A) (718 x 494mm) Rail (D1570A) (718 x 60mm) Hanging Rail (FHR710) (710mm long)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the drawer fronts Note: Tighten the metal dowels up fully against the panels.
-
Page 6: Table Of Contents
Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base... - Page 7 Assembly Instructions Step 7 Prepare the left side Place 2 runners the left side . Slide back the top of runner and use the 2nd hole Finished from the front to fit the front edge 1st screw Slide the runner back the other way and fit the 2nd screw into...
-
Page 8: Step 8
Assembly Instructions Step 8 Prepare the right side Place 2 runners the right side . Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into Finished... -
Page 9: Front 6 . 7
Assembly Instructions Step 9 Prepare the 3 top and base panels Tap 2 wooden dowels into each of the top and base panels Note: Wooden dowels must not stick out from the edge by more than Finished 10mm or they may front edge damage other panels. - Page 10 Assembly Instructions Step 11 Fit the vertical rail Attach the vertical rail to the top and base using 4 screws Step 12 Prepare the 2 rails Plain chipboard surface Tap 2 wooden dowels into each of the rails Note: Wooden dowels must not stick out from 10mm the edge by more than...
-
Page 11: And
Assembly Instructions Step 14 Fit the other base Push the other base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base Finished front edge Step 15 Fit the left side Push the left side onto the assembly. -
Page 12: Hold The Drawer Back
Assembly Instructions Step 16 The measurement from top corner X to bottom corner X must be Fit the back equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y. -
Page 13: Slide The Drawer Base 10
Assembly Instructions Step 18 Fit the hanging rail and drawers Push the hanging rail into the rail holders fitted to the side panels. Starting with the bottom drawer, slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the... - Page 14 Assembly Instructions Step 20 Fit the 2 doors Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 15 Assembly Instructions Step 19 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 16 Assembly Instructions Step 20 Screw Fit the overbalance protector Washer Wall fixing Strap (not supplied) To prevent possible Strap Washer overbalancing we recommend that this unit Screw is secured to a suitable (not supplied) wall by use of the overbalance protector kit fitted to the unit or, an alternative fixing method of your choice.
