- Page 1 MODELRANGE REACH STACKER SC 4127 - 4535 TA / SC 4023 - 4531 CA...
- Page 2 1 Spares catalogue for the lift-machine using the specified lubricant. SMV original spares. This is necessary 1 User manual for the lift-machine in order for your SMV machine to 1 Machine card Maintenance must be carried out only retain its original technical standard.
- Page 3 Authorised manual. Follow the guidelines and - special functions of the SMV SMV dealers can supply information safety regulations applicable to: machine extra equipment on these.
- Page 4 Instruction book SC - TA/CA OUTLINE PICTURE OF THE LIFT TRUCK DESCRIPTION Lift boom Damping cylinders 2 pcs Steer axle Attachment Tilt cylinders attachment 4 pcs Counterweight Twistlocks Lifting cylinders Driver's cab Drive axle Trailer lift legs. (CA mod) Publ. nr 6053.411 0315...
- Page 5 Instruction book SC - TA/CA ID PLATES AND SERIAL NUMBERS Boom number Steer axle number Chassis number Load capacity plate Engine number Drive axle number Attachment Transmission number Publ. nr 6053.411 0315...
- Page 6 Instruction book SC - TA/CA TECHNICAL DESCRIPTION TECHNICAL DESCRIPTION Specification SC 4127 TA means: SC = Silver Container handler 41 = 41 tons lift capacity in first row The steer axle is mounted in to the right of the driver. The joystick 27 = 27 tons lift capacity in "spherelastic"...
- Page 7 Instruction book SC - TA/CA CONTENTS YOUR SMV LIFT- TRUCK ..........2 TIGHTENING BOLTED JOINTS SAFETY REGULATIONS ..........3 Tightening torque, torque table, tightening wheel OUTLINE PICTURE OF THE LIFT TRUCK ..... 4 nuts, universal drive shaft ..........47 ID-PLATES AND SERIAL NUMBERS ......5 Differential nuts, engine mounting, gearbox ....
- Page 8 Instruction book SC - TA/CA CONTROLS AND INDICATORS IN THE CAB H 1076 DESCRIPTION Steering wheel Accelerator Recirculation Instrument panel with switches Brake pedal Display for EMC Ignition switch Declutch switch Direction and gear selector Emergency stop Joystick Air condition Adjustment steering wheel Heater Publ.
- Page 9 Instruction book SC - TA/CA DISPLAY FOR ELECTRONIC SYSTEM H1089 DESCRIPTION Parking brake Enginge electronic system (DSI 12) Joystick steering (optional) Working lights boom Support legs up (optiona) Central lubrication (optional) Working lights attachment Support legs down (optiona) Central lubrication (optional) Working lights optional Emergency switch Emergency lowering...
- Page 10 Instruction book SC - TA/CA BEFORE DRIVING Adjusting the driver's seat - To elevate the seat, turn the hand wheel (3) clockwise. Weight adjustment is automatic. - Adjust tilting of the seat cushion, by the hand wheel (2). - Adjust tilting of the backrest with hand wheel (1). H021 H 021eca - Lift the clamp (4), to adjust the seat forward/backwards...
- Page 11 Instruction book SC - TA/CA BEFORE DRIVING Adjustment lever of steering wheel When positioning the steering wheel: - Pull lever (1) upwards adjust the tilt. - Push lever (1) downward to adjust the height. Daily maintenance and service before operation Points to check: - Water level of the radiator page 11.
- Page 12 Instruction book SC - TA/CA BEFORE DRIVING Checking the engine oil level - Lift the engine casing. - The dip stick (1) is on the right-hand side of the engine. - Remove the dip stick (1) completely and dry it off with a clean cloth.
- Page 13 Instruction book SC - TA/CA BEFORE DRIVING Hydraulic system Checking the hydraulic oil level - Check that the oil level is between the MIN and MAX marks on the indicator at the side of the hydraulic oil tank (the boom should be lowered & fully retracted). H 1056 Topping up the hydraulic oil WARNING...
- Page 14 Instruction book SC - TA/CA BEFORE DRIVING Filling with fuel - Open the tank cap located on the left-hand side of the machine and fill with the recommended fuel. See page 84. - Screw on the cap. The fuel capacity of the tank is 770 liters. NOTE To avoid air being sucked into the fuel injection system, the fuel tank should never be run completely empty.
- Page 15 Instruction book SC - TA/CA BEFORE DRIVING Description of the drive monitor type IQAN The drive monitor’s purpose is to efficiently control the reach stacker’s hydraulic system and drive line by utilising both analog and digital information from various sensors. For example, prevent lowering, hoisting and extension in an overload situation.
- Page 16 Instruction book SC - TA/CA BEFORE DRIVING First page picture menu The picture menu contains three pages where various digital and analog values are shown. Load indication - (2) forward. - (4) backwards. Gear Enginespeed - (5) can be used to change between the picture 1 2 3 4 and text menues.
- Page 17 Instruction book SC - TA/CA BEFORE DRIVING Text menu, first page The text menu is optained by pressing key (5) and includes two pages with sub menues. - (8) tune menu. - (6) load indicator. - (2) text menu second page. Tune - (5) return to picture menu.
- Page 18 Instruction book SC - TA/CA BEFORE DRIVING Text menu, second page The second page is reached by pressing key (2) on the first text menu page and contains the following sub menues: Info - (9) information Display - (8) display - (7) service Service - (6) trouble shooting...
- Page 19 Instruction book SC - TA/CA BEFORE DRIVING Submenu Service This menu gives further sub menues. - (9) E-gas is an automatic setup for electric foot throttle. (Only Scania DSI 9). E-gas - (8) adjustment of forward/reverse interlock. - (7) adjustment of upgear. F/R Interlock - (6) adjustement of downgear.
- Page 20 Instruction book SC - TA/CA BEFORE DRIVING Sub menu up gear. - Press key (9) to activate the function forshifting from to 2 Box will light up. 1 -> 2 - Adjust by keys (1) and (3) to in/decrease the value and by that change the speed when shift 2 ->...
