smv MULTI-LIFT SYSTEM Instruction Manual

Stabilizer parking system for vehicles
Hide thumbs

Advertisement

Quick Links

Download this manual
MULTI-LIFT SYSTEM
INSTRUCTIONS MANUAL
INSTALLATION - USE - MAINTENANCE
STABILIZER PARKING SYSTEM FOR VEHICLES

Advertisement

loading
Need help?

Need help?

Do you have a question about the MULTI-LIFT SYSTEM and is the answer not in the manual?

Questions and answers

Related Manuals for smv MULTI-LIFT SYSTEM

Summary of Contents for smv MULTI-LIFT SYSTEM

  • Page 1 MULTI-LIFT SYSTEM INSTRUCTIONS MANUAL INSTALLATION - USE - MAINTENANCE STABILIZER PARKING SYSTEM FOR VEHICLES...
  • Page 2 INDEX INTRODUCTION RESPONSIBILITY AND GUARANTEE USING THE INSTRUCTIONS MANUAL METHOD OF USE COMPONENTS USING THE REMOTE CONTROL ABSOLUTE “MUST-NOTS”- PROHIBITED USE EMERGENCY MANOEUVRE GENERAL SAFETY MEASURES INSTALLATION HYDRAULIC ELECRTIC RECEIVER AUTOLEVEL SYSTEM AUTOLEVEL SETTING ADVISE CONTACTS BOTH INSTALLER AND USER MUST READ THE FOLLOWING MANUAL CAREFULLY TO ENSURE CORRECT USE AND MAXIMUM EFFICIENCY OF THE EQUIPMENT...
  • Page 3 RESPONSIBILITY AND GUARANTEE SMV reserve the right to carry out any modifications and improvements to the machine that are held necessary over time and without prior notice. Products manufactured by SMV are guaranteed against any breakdowns that can be attributed to manufacturing defects or materials used.
  • Page 4 SMV are available to carry out repairs to their own products even after the guarantee has expired. SMV will carry out repairs after many years of use (as long as it is economically viable). Availability of spare parts designed and manufactured by SMV is guaranteed up to 5 years from the product being out of production.
  • Page 5 USING THE INSTRUCTIONS MANUAL SMV recommend that users scrupulously adhere to the instructions set out in this Manual. Before carrying out work of any kind on components applied to the equipment read the following Instructions Manual carefully. This Instructions Manual is written for specialised and competent personnel and provides instructions for correct use of the product.
  • Page 6 METHOD OF USE The levelling system for camper vans, motor-homes, trailers etc. provides stability and levelling of the vehicle on four hydraulic feet, exploiting the run provided by suspensions and shock absorbers. Once levelled on its four feet, the vehicle becomes much more stable and no longer experiences annoying rocking caused by walking. On 4 feet, 95% of vehicle weight is removed from the suspensions and leaf springs, providing these parts with a longer lifespan.
  • Page 7 THE SYSTEM INCLUDES 4 hydraulic jacks 1 hydraulic power pack 1 emergency pump 1 electronic control panel 1 remote control 1 black box for control of jacks 4 integrated check valves 4 mechanical limit switches 1 tube and tube fittings kit Different attachment points and fixing systems are used according to the type of chassis.
  • Page 8 Danger! STOP THE MANOEUVRE IMMEDIATELY AND VERIFY THE CAUSE OF THE PROBLEM. In the case of “fixed” vertical jacks we will only see the red led of the mechanical switch limit light up. When the jacks move, the corresponding red leds light up on the receiver. With the autolevel system we will see on the receiver the autolevel movements.
  • Page 9  Warning Improper use of these buttons could cause damage to the structure and to persons. SMV DECLINE ALL RESPONSIBILITY FOR ANY DAMAGE CAUSED BY IMPROPER USE OF THE SYSTEM.
  • Page 10 REPLACING THE REMOTE CONTROL BATTERIES MODELS TXE-B (434,42 MHZ) TXE-G (433,42) • Remove the screw at the back of the remote control using a philips screwdriver . • Lift the printed circuit out by gently pushing the screwdriver inside the hole. •...
  • Page 11 ABSOLUTE “MUST NOTS”! • Use of the machine for unauthorised manoeuvres , improper use and lack of periodical maintenance can determine serious danger for persons as well as compromising proper functioning and the intrinsic safety of the machine. • The following list of actions, which obviously cannot completely cover the entire potential range of possible "misuse”...
  • Page 12 TROUBLESHOOTING POSSIBILE CAUSE SOLUTION Remote control with flat batteries Replace batteries Remote control with malfunctioning buttons Replace remote control Incorrect pressure on buttons Press exactly in the centre of the button The remote control doesn't carry out command Check if the programmed automatic cut off time is over. Reset the ON-OFF switch Recharge battery.
  • Page 14 GENERAL SAFETY MEASURES All installation, assembly, maintenance and disassembly operations of the equipment and components used with the equipment must be carried out fully respecting safety measures: there must never be any pressure (zero pressure) inside the hydraulic circuit and no weight of any kind must be placed on the jack springs or the control unit used (zero load). ...
  • Page 15 DISPOSAL OF HYDRAULIC FLUID Hydraulic fluids have special waste disposal rules: disposal of hydraulic fluid into the environment is prohibited by law, thus disposal must adhere to manufacturer indications and laws concerning this subject. CHOICE OF HYDRAULIC FLUID Any mineral based hydraulic fluid is suitable for use. When choosing a hydraulic fluid, it is necessary to keep in mind optimum temperature/viscosity when the system is functioning, operating data and the temperature of the environment.
  • Page 16 DESCRIPTION, ASSEMBLY AND INSTALLATION The versatile and modular nature of the SMV hydraulic system, gives rise to a compact, versatile and easy-to-install unit. An essential condition for ensuring that the hydraulic power pack and the system to which it is applied work well, is that assembly and installation are carried out under conditions of maximum cleanliness.
  • Page 17 PROCEDURAL STANDARDS FOR CORRECT INSTALLATION FILLING TANK If the power pack is supplied with the tank, fill it with hydraulic oil filtered during racking to a filtration value of 25 micron or lower and check the level using the level rod located on the filling cap or by using the visual level, if present. If the power pack is not equipped with a tank, install the collector in its dedicated space checking that the collector ring on the connection interface is tight enough;...
  • Page 18 SYSTEM START UP Once the system has been started up, check the exact functioning of all the command switches and the calibration of the adjustable valves, using the pressure gauge outlet. If not specified when ordered, the pressure gauge plug should be inserted to complete the system.
  • Page 19 CONTROL AND MAINTENANCE Safety and the good working order of the system also depend on correct and scheduled maintenance .  Warning After a brief period of running in of the system, check that the screws, nuts, fittings and tubes are correctly tightened: vibrations can cause dangerous loosening of the above mentioned components.
  • Page 20 BREAKDOWN PROBABLE CAUSES POSSIBLE SOLUTIONS Pump does not supply - blocked filter - disassemble and clean (or replace) the required flow - air intake in the suction tube - Check closure grip -Collector leakage caused by fusion defect -Replace collector - Breakage of coupling for pump-motor - Disassemble and replace connection...
  • Page 21 SYSTEM ASSEMBLY Nr. 4 hydraulic jacks Nr. 1 hydraulic power pack Nr. 1 electric control panel with manual buttons and circuit Nr. 1 remote control Nr. 1 black control box Nr. 1 electric cable with connectors and power supply Nr. 4 mechanical limit switches Nr.
  • Page 22 SIMPLIFIED ELECTRIC DIAGRAM...
  • Page 23 It is often necessary to personalise the type of anchoring brackets used on the chassis because of different vehicle disposition. Brackets must always be anchored to the supporting chassis in a structural way. In the event of difficulty or doubt in deciding on the correct position for brackets please consult our technical department.
  • Page 24 DOUBLE EFFECT TELESCOPIC JACKS...
  • Page 25 DOUBLE EFFECT EASYHUB...
  • Page 26 HEAVY JACKS...
  • Page 27 Both the bushing and the insert must be greased or oiled Use only original SMV tube fittings Insert the bushing into the tube and screw tighten in an anticlockwise direction until reaching its mechanical stop. Screw the tube fitting in a clockwise direction inside the bushing until you reach the end of thread without interruption.
  • Page 28 HYDRAULIC TUBE FITTING...
  • Page 29 HYDRAULIC SCHEME...
  • Page 30 CONNECTING HYDRAULIC TUBES...
  • Page 31 CONNECTING HYDRAULIC TUBES When assembling tubes be careful not to confuse the various connections. A double effect jack corresponds to each block. All the tubes that go on the lower part of the jacks must be connected on the operating side of the emergency pump. All the tubes that go on the upper part of the jacks must be connected on the opposite side.
  • Page 32 DIMENSIONS...
  • Page 33 ELECTRIC CABLING ON HYDRAULIC POWER PACK WITH 800 WATT-12V MOTOR IMPORTANT: POWER CABLE FROM BATTERY SECTION 25 mm²...
  • Page 34 ELECTRIC CABLING ON HYDRAULIC POWER PACK WITH 1600 WATT-12V MOTOR IMPORTANT: POWER CABLE FROM BATTERY SECTION 25 mm²...
  • Page 35 RECEIVER MODEL RXVESNS-05-B/G This unit is designed to be used for the control of solenoid valves which operate the hydraulic drives installed on motor vehicles (market place vans, motorhomes, auto market, trailer motors with closure devices for awnings etc) or on applications that use battery power.
  • Page 36 EV1, EV2 CONTROL THE FRONT LEFT JACK. EV3, EV4 CONTROL THE FRONT RIGHT JACK. EV5, EV6 CONTROL THE BACK LEFT JACK. EV7, EV8 CONTROL THE BACK RIGHT JACK. 3) CONNECT THE NUMBER-CODED CABLES TO THE J2 TERMINAL BOARD There is a small bridge on the J3 terminal board. If necessary, connect a key switch or remote switch, eliminate the bridge and connect the two 2.5 mm section wires.
  • Page 37 Each time a remote control button or a manual switch on the control panel is pressed, the corresponding solenoid valve as well as the pump will be enabled. 7) Close the waterproof case using the two remaining screws. 8) Install the inductive and mechanical sensors onto the hydraulic jacks. Connect the inductive and mechanical sensors with the connection cables supplied and insert the connectors into the sockets located in the lower part of the power pack following the sequence.
  • Page 38 With this software version, by pressing remote control buttons A,B,G,H,I the corresponding exits will be activated provided that the contacts of the mechanical limit switches are closed. Exit Mechanical limit Operation switches MEC. EV1 EV1 activated only if MECH. EV1 contact is closed (red LED rouge ON). MEC.
  • Page 39 CONTROL UNIT Terminal board for rear right limit switch Terminal Terminal Terminal board for front board for board for left limit front right rear left switch limit switch limit switch RED LED MICRO SWITCH YELLOW LED ON/OFF LED MAGNETIC SENSOR COMMAND SWITCHES FLAT BATTERY...
  • Page 40 OPTIONAL - Handbrake Terminal board for the warning buzzer and LED accessory for the limit switch position SUPPLEMENTARY BUZZER (“black box”) OPTIONAL – Cable for connection Handbrake Fuse 15 A Fuse 500 mA Fuse 1 AT Hole to access button below for programming the control unit.
  • Page 41 Jumper on board: IMPORTANT: to activate the hand-brake function, remove jumper JP2 by touching the 2 pads with the soldering tip to remove solder. CONTROL MODE BLACK BOX BLACK BOX + JACK PLUG JACK PLUG JACK PLUG (BROWN WIRE) (BROWN + (WHITE WIRE) WHITE WIRE) Jumpers...
  • Page 42 ELECTRO-HYDRAULIC SYSTEM SCHEME Follow the number-coded sequence of the solenoid connectors as shown below: 1 – 3 – 5 – 7 2 – 4 – 6 - 8 As shown in the figure above, besides connecting up the hydraulic system we must also connect up the electrical part which includes various cables and various sets of cables to be connected: Connect up the positive red cable and the negative black cable from the vehicle battery to the hydraulic control unit.
  • Page 43 connect +12 volt red wire of the black box under ignition key, insert the protective fuse on the cable in a way that it can be easily inspected. Insert the plugs of the 4 limit switches into the receiver box manually checking the correct sequence: front left – front right –...
  • Page 44 AUTOLEVEL SYSTEM SETUP AND PROGRAMMING PROCEDURE (FOR INSTALLER ONLY) Ceci signifie : Voyant allumé ****FOLLOW THIS PROCEDURE STEP BY STEP TO ENTER THE PROGRAMMING MODE**** SETTING UP THE POSITION OF CENTER BUBBLE LEVEL It must first memorize the Zero level and for this it is necessary that the vehicle will be level in manual mode with the remote control.
  • Page 45 To enter the programming mode, Press PROG button and hold for 2 seconds and at the same time, turn the main switch on the control panel to ON. After 3 seconds, the first beep sounds, keep the button pressed and wait the second beep.
  • Page 46 2) SELECT THE LAY-DOWN CONTROL AFTER LEVELLING BY PRESSING THE PROGRAMMING KEY TO TOGGLE BETWEEN DIFFERENT MODES SINGLE JACKS JACKS SINGLE CONTROL IN PAIRS JACKS JACKS IN PAIRS A beep sounds. 3) SELECT THE TYPE OF INSTALLED JACKS BY PRESSING THE PROGRAMMING KEY TO TOGGLE BETWEEN THE MODES.
  • Page 47 5) SELECT THE LENGTH OF FINAL LEVELLING PULSES (recommended values are 2 – 3 - 4) BY PRESSING THE PROGRAMMING KEY TO TOGGLE BETWEEN DIFFERENT MODES. VALUE 1 VALUE 3 VALUE 4 VALUE 2 (recommended) (recommended) (recommended) Motorhome Motorhome very heavy very light 3,5 Ton ALKO 5 Ton...
  • Page 48 7) SELECT THE MAX. INCLINATION REQUIRED BY PRESSING THE PROGRAMMING KEY TO TOGGLE BETWEEN MODES ( WARNING !! ) a) THE INCLINATION SHOULD ALLOW THE LEVELLING OPERATION WITHOUT LIFTING THE WHEELS FROM THE GROUND!!!!!!. b) THE SET VALUE SHOULD BE LOWER THAN THE MAX. JACK STROKE (at least 4 cm) ~ +/-1,5°...
  • Page 49 ~ +/-3,5° ~ +/-4 ° ~ +/-5 ° ~ +/- 6°...
  • Page 50 LED DISPLAY Yellow leds are lighting when the camping car is not good levelled. Green led is lighting and the buzzer stop ringing, the camping car is levelled. AUTOLEVEL SYSTEM DOESN’T WORK IF… 1° CONDITION IF SOMEONE OF THE FOUR YELLOW LEDS INDICATING THE POSITION OF CENTER BUBBLE LEVEL IS BLINKING.
  • Page 51 2° CONDITION IF THE IGNITION KEY IS TURNED OR THE VEHICLE’S MOTOR IS RUNNING, THE LED CORRESPONDING TO ICON TURNS ON. IN THIS CONDITION YOU CAN USE THE REMOTE CONTROL TO CONTROL THE JACKS, BUT IF YOU PRESS THE AUTOLEVEL BUTTON , THE SYSTEMS BLOCKS.
  • Page 52 Installation class (overvoltage): Operating temperature: -20°C/+55°C Size (L x H x P) 193 mm x 145 mm x 80 mm Cable length : 4 - 6 – 8 metri Cable section: 1,5 mm Technical notes on the waterproof case Conformity to CEI-670, IEC 695-1-2 standards The case is sealable Accessories Remote switch...
