- Page 1 JABO-2AG/2BG bait boat User manual 202008...
- Page 2 Please read this manual carefully before using bait boat JABO2AG/2BG is another product of the JABO series of intelligent bait boats. This product uses GPS positioning and electronic compass navigation. It can store 16 target bait points, and can automatically (manually) set the starting point to achieve the starting point.
-
Page 3: Main Specifications
4 Speed: 80 meters/minute 5 rRemote control (automatic navigation) distance: 300 meters 6 Drive components: dual 380 motor gearbox drive (2AG), dual 545 motor direct drive (2BG), built-in propeller. 7.Main actions: forward, reverse, turn right, turn left, release hook (feeding bait), automatic driving at fixed distances, automatic positioning, automatic nesting, and automatic return. - Page 4 Press and hold the power button for 2 seconds. The screen JABO enters the boot page. The "JABO" welcome page appears first. Calibration: Compass calibration is required for the initial...
- Page 5 Note: Compass calibration is required only when first used or when changing to another venue. The second time it is used on the same site, you can directly select “N” on the Compass Calibration page to enter the “Set GPS Origin” page. It should be noted that it takes 2-5 minutes for the boat’s receiver to establish a connection with the satellite system.
- Page 6 Depth range Depth range "ft": The factory setting is "Auto". Auto Boat speed speed adjustment, factory setting 90%, adjustment range 60-99% Refresh rate The refresh rate is to adjust the screen shift time of the LCD screen. The adjustment range is 0-9 seconds and the factory setting is 5 seconds.
- Page 7 ③ N key: navigation function selection key. Press the N key, there are 5 kinds of navigation function options: Return Save Dest Guide to DEST Set start Go Forward 1 Return : Directly press the "S" key to select the return route, at this time theboat starts to return, and stops after returning to the starting point.
- Page 8 5 Go Forward: This is the new directional fixed-range automatic navigation function of JABO2AG/2BG bait boats. Users can choose 20-300m directional fixed-range navigation in this option to replace the original need to manually set the nest point by remote control, which realizes the real automatic navigation Specific operation method: press ▼...
- Page 9 es After nesting the boat, you only need to op en the hatch cover (don’t pull out the plugs that have been inserted), an d connect the battery plug to the power socket insid e the boat. When co nnecting, pay special attention to the polarity of the battery and the reve rse connection.
- Page 10 4.Charger use and precautions: The JABO Lithium series bait boat has a lithium battery charge management circuit installed in the boat. Please pay special attention to the use of the original power adapter for charging.
-
Page 11: Battery Connection Diagram
4 JABO-2 series remote control boat is suitable for use in reservoirs, lakes and ponds. It cannot be used on flowing water to avoid being washed away by currents. Not suitable for use in stormy water. - Page 12 Fishing line lanyard diagram: Common problems when using the nest boat: 1 The nesting boat cannot return to the set starting point or is far away from the set nesting point: This situation is mainly because the time to set the starting point is relatively short after the ship is turned on, and the receiver has not received GPS signals stably.
- Page 14 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
