IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this
product or require any replacement
fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed
unless the item is found to be faulty. Should you need to return the unassembled product,
please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple
step by step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
PRODUCT INFORMATION
Made in Poland.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down
the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
Avoid keeping furniturein direct sunlight or closeto any heat sources as this can cause cracking,
discolouration or warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
All assembly fixings should always be tightened properly and periodically check all fixings and
tighten if necessary.
• The finish will mellow and change colour over time.
865283 LOFT CHEST
ASSEMBLY INSTRUCTIONS.
1 of 14
P5--MK 43

Advertisement

loading
Need help?

Need help?

Do you have a question about the LOFT 865283 and is the answer not in the manual?

Questions and answers

Summary of Contents for Next LOFT 865283

  • Page 1 865283 LOFT CHEST ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
  • Page 2 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction FLOOR AREA 1.5 M x 1.5 M 1 hr 2 PERSON ASSEMBLY APPROXIMATE ASSEMBLY TIME REQUIRED ASSEMBLY SPACE REQUIRED ASSEMBLY TOOLS ASSEMBLED DIMENSIONS 851 mm ATTENTION!! High-gloss finish item ! 865283 White gloss After completed assembly remove carefully protective foil from the fronts. DO NOT USE SHARP TOOLS! 2 of 14 P5--MK 43...
  • Page 3: Parts List

    DESCRIPTION: Assembly 865283 LOFT CHEST Instruction PARTS LIST NO PART LIST (1) BOTTOM PANEL (2) PLINTH (3) LEFT SIDE PANEL (4) RIGHT SIDE PANEL (5) BACK PANEL (6) TOP PANEL (7) BOTTOM DRAWER FRONT (8) SLAT ( OPTION OAK ) (9) SLAT (OPTION WHITE ) (10L) LEFT DRAWER SIDE (10R) RIGHT DRAWER SIDE...
  • Page 4: Hardware List

    DESCRIPTION: Assembly 865283 LOFT CHEST Instruction HARDWARE LIST DO NOT MIX CONTENT OF HARDWARE BOXES ATTACH TO DRAWER ATTACH TO CARCASS 8x28mm DOWEL CAM BOLT CAM LOCK BAG 1 BAG 1 BAG 1 3x Left / 3x Right L=350mm ROLLER RUNNER BAG 2 3,5x13mm 4x30mm...
  • Page 5 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction Top Tips before you start! Please check that all parts are present before you start the assembly of your furniture, as once assembled, the furniture is exempt from our home approval policy. For ease and speed of assembly, we recommend that before you commence each step of the assembly, that you identify all the parts required for that step.
  • Page 6 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction SCREW IN CAM SCREWS PRESS IN CAM LOCKS. ARROW ON CAM ONLY DOWN TO FIRST RING. LOCK MUST FACE HOLE IN PANEL EDGE. FLUSH WITH DO NOT INSERT DOWELS PANEL IN CAM SCREW / LOCK HOLES. TO SECURE PANELS, PRESS PANELS TOGETHER ALIGNING TURN CAM LOCKS 1/2 TURN CLOCKWISE.
  • Page 7 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction ASSEMBLY INSTRUCTION FOR DRAWER SLIDE A&B 350mm SPECIAL TIPS FOR DRAWER SLIDE A FRONT BACK Step 1 SIXTH HOLE SECOND HOLE TENTH HOLE SECOND HOLE 3,5x13mm 6x11 mm 6x11 mm 6x11mm ATTENTION ! Make sure second hole of drawer slide A is put on first front hole of panel.
  • Page 8 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction 3x Left 2x 2x LEFT 8 of 14 P5--MK 43...
  • Page 9 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction 3x Right 2x 2x RIGHT 9 of 14 P5--MK 43...
  • Page 10 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction 1/2 TURN CLOCKWISE. 10 of 14 P5--MK 43...
  • Page 11 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction OPTION OAK DO THIS STEP TWICE (2x) OPTION WHITE 1/2 TURN CLOCKWISE. 7 13 11 of 14 P5--MK 43...
  • Page 12 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction OPTION OAK OPTION WHITE 1/2 TURN CLOCKWISE. 12 of 14 P5--MK 43...
  • Page 13 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction DO THIS STEP THREE TIMES (3x) L=350mm 3x Left / 3x Right 3,0x13mm ATTENTION!! High-gloss finish item ! 865283 White gloss After completed assembly remove carefully protective foil from the fronts. DO NOT USE SHARP TOOLS! 13 of 14 P5--MK 43...
  • Page 14 DESCRIPTION: Assembly 865283 LOFT CHEST Instruction STEP STEP NOT SUPPLIED___ Wall fixings are not supplied with this product as different wall materials require different types of fixing devices( such as Rawl plugs used on brick work).You must use fixing devices suitable for the type of wall you intend to mount this product to. Please ensure that the head of any screw used has a diameter greater than the diameter of the mounting hole on the product and that the fixing is safe and secure before use.
