- Page 1 2000 Count Manual Ranging Digital Multimeter Multímetro Digital de Rango Manual, 2000 Cuentas Multimètre Numérique à Sélection de Gamme Manuelle, Écran (2 000 Comptes) B07VY41YHM...
- Page 2 English 3 Español 28 Français 56...
-
Page 3: Important Safeguards
IMPORTANT SAFEGUARDS Read these instructions carefully and retain them for future use. If this product is passed to a third party, then these instructions must be included. When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons including the following: WARNING... - Page 4 WARNING Risk of electric shock! Use special care when making measurements, if the voltages are greater than 25 V~ rms or 35 V . These voltages are considered a shock hazard. CAUTION Risk of injury! The probe tips are sharp for accuracy. Be careful when handling and reattach the probe tip shrouds after use.
- Page 5 • Do not measure current on a CAT II circuitry whose voltage exceeds 600 V. • Do not measure current on a CAT III circuitry whose voltage exceeds 600 V. • When measuring volts, do not switch to current/resistance modes. •...
-
Page 6: Battery Warnings
• Do not use, if the product seems to be damaged or if it is not working properly. If in doubt, replace the product. • Comply with all applicable safety codes. Use approved personal protective equipment when working near live circuits − especially with regard to the possibility of arc flash hazards. -
Page 7: Explanation Of Symbols
Explanation of Symbols The signal word that indicates WARNING a hazard with a medium level of risk which, if not avoided, could result in death or serious injury. The signal word that indicates CAUTION a hazard that if not prevented could result in minor or moderate injury. - Page 8 Earth (ground) terminal/potential. CAT II Product is designed to protect the user during measurements performed on 600V circuits directly connected to the low voltage installation (up to 600 V). • Single phase receptacles and connected loads • Household appliances, power tools •...
-
Page 9: Intended Use
Intended Use • This product is intended to perform electrical measurements on CAT II (household appliances, portable tools and similar equipment) and CAT III locations (3-phase and single phase distribution). • This product covers CAT I locations. • This product may be used only under the conditions and for the purposes for which it was designed. -
Page 10: Product Description
Product Description... - Page 11 Battery Display compartment HOLD button 200 mA fuse Function switch 10 A fuse 10A input jack Tilt stand Test probes with COM input jack connector leads Probe tip shrouds backlight button V/Ω/mA input jack...
- Page 12 HOLD Display hold Minus sign Low battery indicator Display reading Function switch AC voltage DC voltage DC current (<200 mA) DC current Battery test Diode test / Resistance continuity...
-
Page 13: Changing Batteries
Changing Batteries WARNING Risk of electric shock! Disconnect the product from any circuit, remove the connector leads (L) from the input jacks (D)/ (E)/(G), and turn OFF the product before opening the battery compartment (H). Do not operate the product with an open battery compartment. NOTICE Replace the battery when the low battery indicator (3) is shown on the display (A). - Page 14 • To switch the product off, set the function switch (C) to the OFF position. Switching the display backlight on/off • Press and hold the backlight button (F) to switch the display backlight on/off. Display hold • To freeze the display reading, press the HOLD button (B).
- Page 15 NOTICE Risk of damage! Do not measure motors with unstable power. Large voltage surges may occur that can damage the product. • Set the function switch (C) to the appropriate voltage measurement mode: Voltage Function switch (C) position ≤ 200 mV 200 mV ≤...
- Page 16 AC voltage measurement CAUTION Risk of electric shock! The contact plates in powered AC outlets may be recessed too far for the test probes to make a connection. This may give false measurements. Contact point of measurement must be visible for a true reading.
- Page 17 • Insert the black connector lead (L) into the COM input jack (E). • Insert the red connector lead into the V/Ω/mA input jack (G). • Connect the test probes (L) in parallel to the circuit under test. • The stabilized value on the display (A) is read as the actual reading.
- Page 18 • For current measurements of up to 200 mA, set the function switch (C) to the 200 mA position and insert the red plug connector lead into the V/Ω/mA input jack (G). • For current measurements of up to 10 A, set the function switch (C) to the 10 A position and insert the red plug connector lead into the 10A input jack (D).
- Page 19 NOTICE For best results, disconnect one side of the part under test. This is to avoid the other components in the circuit to inhibit the measurement. • Insert the black connector lead (L) into the COM input jack (E). • Insert the red connector lead into the V/Ω/mA input jack (G).
- Page 20 • Insert the black connector lead (L) into the COM input jack (E). • Insert the red connector lead (L) into the V/Ω/mA input jack (G). • Place the test probes (L) across the diode being measured. • If the diode was measured in reverse, the display (A) shows I.
- Page 21 • The stabilized value on the display (A) is read as the actual reading. • If the resistance is less than approximately 30 Ω, an audible signal is emitted. • If the circuit is open, I lights up on the display (A). Battery test •...
-
Page 22: Cleaning And Maintenance
Cleaning and Maintenance NOTICE Switch the product off and all the connector leads before cleaning. NOTICE During cleaning do not immerse the product in water or other liquids. Never hold the product under running water. Cleaning • To clean the product, wipe with a soft, slightly moist cloth. -
Page 23: Specifications
NOTICE Always use a fuse of the proper size and value: – 200 mA/250 V fast blow for the 200 mA range – 10 A/250 V fast blow for the 10 A range • Open the tilt stand (K). • Loosen the screws of the battery compartment cover. - Page 24 NOTICE *f.m. = from measurement AC voltage Range Resolution Accuracy 200 V 0.1 V ±1.2 % f.m.* ±10 digits (50/60 Hz) 600 V • AC voltage bandwidth: 45 Hz to 450 kHz (sinusoidal); 50/60 Hz (all waves). DC voltage Range Resolution Accuracy 200 mV 2000 mV...
- Page 25 Resistance Range Resolution Accuracy 200 Ω 0.1Ω 2000 Ω 1 Ω ±0.8 % f.m.* ±2 digits 20 kΩ 0.01 kΩ 200 kΩ 0.1 kΩ 2000 kΩ 1 kΩ ±1 % f.m.* ±2 digits Test current: <0.35 mA. Continuity Measurement Output Test current max. 1 mA Beeping tone when resistance is less than (30 Ω) Diode...
- Page 26 General Power supply: 1 x 9 V Max. measurement Cat III: 600 V voltage: Pollution degree: Fuses: Fuse 1: 200 mA/250 V ceramic fast blow Fuse 2: 10 A/250 V ceramic fast blow Battery test current: (6 mA) 1.5 V (100 mA) Overrange indication: I is displayed Display:...
-
Page 27: Battery Disposal
Storage humidity: <80 % Operating altitude: max. 7000' (2000 m) Dimension: 5.5 x 2.6 x 1.53 in (140 x 66 x 39 mm) Net weight: 0.37 lbs (169.2 g) Battery Disposal Do not dispose of used batteries with your household waste. Take them to an appropriate disposal/collection site. - Page 28 amazon.com/AmazonCommercial MADE IN CHINA HECHO EN CHINA FABRIQUÉ EN CHINE V01-10/19...
