AMAZON COMMERCIAL 6000 Count Compact Manual

AMAZON COMMERCIAL 6000 Count Compact Manual

Ip67, true rms, cativ 600v

Advertisement

6000 Count Compact Digital Multimeter, IP67, True rms,
CATIV 600V
Multímetro Digital Compacto de 6000 Cuentas,
con Temperatura, IP67, True RMS, CAT IV, 600 V
Multimètre Numérique Compact, Indice IP67 de Température,
à Valeur Efficace Vraie, CAT IV 600 V, Écran (6 000 Comptes)
B07W1BL3RH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6000 Count Compact and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMAZON COMMERCIAL 6000 Count Compact

  • Page 1 6000 Count Compact Digital Multimeter, IP67, True rms, CATIV 600V Multímetro Digital Compacto de 6000 Cuentas, con Temperatura, IP67, True RMS, CAT IV, 600 V Multimètre Numérique Compact, Indice IP67 de Température, à Valeur Efficace Vraie, CAT IV 600 V, Écran (6 000 Comptes) B07W1BL3RH...
  • Page 2 English                        3 Español                      44 Français                      90...
  • Page 3 IMPORTANT SAFEGUARDS Read these instructions carefully and retain them for future use. If this product is passed to a third party, then these instructions must be included. When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons including the following: WARNING...
  • Page 4 WARNING Risk of electric shock! Use special care when making measurements, if the voltages are greater than 25 V~ rms or 35 V  These voltages are considered a shock hazard. WARNING Risk of electric shock! Keep fingers away from the metal probe tips when taking measurements.
  • Page 5 Mode Maximum Input A~, A 10 A, 1000V fast acting fuse (max. 30 seconds every 15 minutes) mA~, mA 800 mA, 1000V fast acting fuse V~, V 1000 V~ rms/ Frequency, Resistance, Capacitance, Diode 250 V~ rms / Test, Continuity Surge Protection: 8 kV peak per IEC 61010 •...
  • Page 6 • Verify the product’s proper operation before use by measuring a known live voltage. • Always discharge capacitors and remove power from the device under test before performing diode, resistance or continuity tests. • Voltage checks on electrical outlets can be difficult and misleading because of the uncertainty of connection to the recessed electrical contacts.
  • Page 7 Battery Warnings • Always insert batteries correctly with regards to polarity (+ and –) marked on the battery and the product. • Exhausted batteries should be immediately removed from product and properly disposed. • Keep batteries out of the reach of children. •...
  • Page 8 This symbol, adjacent to another symbol or terminal, indicates the user must refer to the manual for further information. This symbol, adjacent to a terminal, indicates that, under normal use, hazardous voltages may be present. Product is protected by double insulation or reinforced insulation.
  • Page 9 Intended Use • This product is intended to perform electrical measurements on CAT III locations (3-phase and single phase distribution) and CAT IV locations (3-phase and single phase primary over-current protection devices). • This product covers CAT II and CAT I locations. •...
  • Page 10 Product Description...
  • Page 11 Display Positive input jack MAX/MIN button COM input jack RANGE button Probe tip shrouds MODE button Test probes with connector leads Function switch Rain caps 10A input jack Thermocouple probe adapter with caps uA/mA input jack Thermocouple probe RELATIVE button Battery compartment Hz/% button...
  • Page 12 H Display hold Relative Units of Continuity measurement % Percent Diode test (duty cycle) Minus sign Low battery indicator AC Alternating Auto power-off current/voltage Display reading DC Direct current/voltage Auto Range VFD Variable indicator frequency drive mode MAX-MIN indicator...
  • Page 13 Function switch Position Function / Measurement AC/DC current (µA) / frequency / duty cycle AC/DC current (mA) / frequency / duty cycle AC/DC current up to 10 A / frequency / duty cycle AC voltage / frequency / duty cycle / variable frequency drive mode DC voltage AC/DC voltage (mV) / frequency / duty cycle Resistance / diode test / continuity /...
  • Page 14 Changing Batteries WARNING Risk of electric shock! Disconnect the product from any circuit, remove the connector leads (N) from the input jacks (F)/(G)/ (K)/(L), and turn OFF the product before opening the battery compartment (R). Do not operate the product with an open battery compartment. NOTICE Replace the battery when the low battery indicator (4) is shown on the display (A).
  • Page 15 • To switch the product off, set the function switch (E) to the OFF position. Automatic power OFF • In order to conserve battery life, the product automatically emits a beeping signal that the product has been idle for 15 minutes. Right after 1 minute, the product turns off.
  • Page 16 Changing the measurement range By default, the measurement range is set automatically and the Auto Range indicator (7) lights up. It is possible to set the measurement range manually. • Press the RANGE button (C) to activate the manual mode and to disable the automatic range setting.
  • Page 17 • Press the REL button (H) again to return to normal operation mode. The indicator (9) goes off. NOTICE This feature is not applicable for functions: Position Function / Measurement Resistance / diode test / continuity / capacitance Frequency / duty cycle Temperature Maximum/minimum measurement •...
  • Page 18 DC voltage measurement NOTICE Doing voltage measurements while the + connector lead (N) is left on the ampere input jacks (F,G) will blow the product’s internal fuse if it draws a current greater than the internal fuses current rating. Check that the (+) red connector lead (N) is on the correct terminal.
  • Page 19 • The stabilized value on the display (A) is read as the actual reading. AC voltage measurement CAUTION Risk of electric shock! The contact plates of powered AC outlets may be recessed too deep for the test probes (N) to reach. This may give false measurements.
  • Page 20 • Set the function switch (E) to the V~ Hz % VFD position. “AC” will be indicated on the display. • Insert the black connector lead (N) into the negative COM input jack (L). • Insert the red connector lead (N) into the positive input jack (K).
  • Page 21 Frequency Mode (V~) • In AC voltage measurement mode, press the Hz/% button (I). Hz (Hertz) lights up. • Connect the test probes (N) in parallel to the circuit or component being measured. • The stabilized value on the display (A) is read as the actual reading.
  • Page 22 • In AC voltage measurement mode, press the Hz/% button (I) twice. % (percent) lights up. • Connect the test probes (N) in parallel to the circuit or component being measured. • The stabilized value on the display (A) is read as the actual reading.
  • Page 23 • Connect the test probes (N) in parallel to the circuit under test. • The stabilized value on the display (A) is read as the actual reading. Frequency mode (mV~) • In AC voltage measurement mode, press the Hz/% button (I). Hz (Hertz) lights up. •...
  • Page 24 • Insert the black connector lead (N) into the negative COM input jack (L). • For current measurements of up to 6000 μA, set the function switch (E) to the μA Hz % position and insert the red plug connector lead (N) into the μA/mA input jack (G).
  • Page 25 • Turn off the power to the circuit under test. Break the connection line/track and separate securely the 2 points where the flow of current must be measured. • Connect in series by securely attaching the test probes (N) each at the 2 open points of the track/line.
  • Page 26 • The stabilized value on the display (A) is read as the actual reading. Resistance measurement WARNING Risk of electric shock! To avoid electric shock, disconnect power from the unit under test and discharge all capacitors before taking any resistance measurements. Remove the batteries or unplug.
  • Page 27 • Insert the red connector lead (N) into the positive input jack (K). • Ω should light up on the display (A). • Place the test probes (N) across the circuit or part under test. • The stabilized value on the display (A) is read as the actual reading.
  • Page 28 • Press the MODE button (D) to switch to diode test mode. (11) should light up on the display (A). • Place the test probes (N) across the diode being measured. • If the diode was measured in reverse, the display (A) shows OL. Reverse the probes (N) position to get the correct polarity.
  • Page 29 • Insert the black connector lead (N) into the negative COM input jack (L). • Insert the red connector lead (N) into the positive input jack (K). • Press the MODE button (D) twice to switch to continuity check mode. (10) should light up on the display (A).
  • Page 30 • Set the function switch (E) to the Ω position. • Insert the black connector lead (N) into the negative COM input jack (L). • Insert the red connector lead (N) into the positive input jack (K). • Press the MODE button (D) 3 times to switch to capacitance measurement mode.
  • Page 31 NOTICE When measuring electrolytic capacitors, follow the polarity (+, –) of its leads to have a precise measurement. Frequency/duty cycle measurement (electronic) • Set the function switch (E) to the Hz % position. • Insert the black connector lead (N) into the negative COM input jack (L).
  • Page 32 • The stabilized value on the display (A) is read as the actual reading. Temperature measurement • Insert the thermocouple probe adapter (P) with the black connector into the negative COM input jack (L) and with the red connector into the positive input jack (K).
  • Page 33 • Place the thermocouple probe tip to the component under test. • The stabilized value on the display (A) is read as the actual reading. NOTICE For longer period of measurements, use a thermal tape to attach the thermocouple probe to the surface being measured. NOTICE Risk of product damage! Disconnect the thermocouple probe (Q) before...
  • Page 34 Replacing the fuses WARNING Risk of electric shock! Disconnect the product from any circuit, remove the connector leads (N) from the input jacks (F)/(G)/ (K)/(L), and turn OFF the product before opening the battery compartment (R). Do not operate the product with an open battery compartment.
  • Page 35 Storage • Store the product in its original packaging in a dry area. Keep away from children and pets. Specifications NOTICE Accuracy specifications consist of two elements: – (% f.m.*) – This is the accuracy of the measurement circuit. – (+ digits) –...
  • Page 36 AC voltage (45 Hz to 1 kHz) Range Resolution Accuracy 60 mV 0.01 mV ±0.9 % f.m.* ±9 digits 600 mV 0.1 mV 0.001 V ±0.8 % f.m.* ±3 digits 60 V 0.01 V 600 V 0.1 V ±0.8 % f.m.* ±8 digits 1000V •...
  • Page 37 DC current Range Resolution Accuracy 6.000 A 0.001 A ±1.5 % f.m.* ±3 digits 10 A 0.01 A 10 A: Max. 30 seconds with reduced accuracy. AC current (45 Hz to 1 kHz) Range Resolution Accuracy 600 μA 0.1 μA 6000 μA 1 μA ±1.5 % f.m.* ±3 digits 60 mA...
  • Page 38 Resistance Range Resolution Accuracy 600Ω 0.1Ω ±1.0 % f.m.* ±2 digits 6 kΩ 0.001 kΩ 60 kΩ 0.01 kΩ ±0.8 % f.m.* ±2 digits 600 kΩ 0.1 kΩ 6 MΩ 0.001 MΩ ±1.2 % f.m.* ±2 digits 60 MΩ 0.01 MΩ ±1.0 % f.m.* ±5 digits Test current: <0.35 mA.
  • Page 39 Frequency (electronic) Range Resolution Accuracy 9.999 Hz 0.001 Hz 99.99 Hz 0.01 Hz 999.9 Hz 0.1 Hz 9.999 kHz 0.001 kHz ±0.1 % f.m.* ±4 digits 99.99 kHz 0.01 kHz 999.9 kHz 0.1 kHz 9.999 MHz 0.001 MHz Sensitivity: 0.8 V rms minimum at 20 % to 80 % duty cycle and <100 kHz;...
  • Page 40 Duty cycle Range Resolution Accuracy 0.1 to 99.9 % 0.1 % ±1.2 % f.m.* ±2 digits Pulse width: 100 μs to 100 ms Frequency: 5 Hz to 150 kHz Continuity Measurement Output Test current Beeping tone when max. 0.35 mA resistance is less than (50 Ω) Diode Measurement Output Test A is max.
  • Page 41 General Power supply: 1 x 9 V battery Max. measurement CAT III: 1000 V voltage: Cat IV: 600 V Pollution degree: IP rating: IP67 Shock proof 6.5' (2 m) (drop test): Crest factor: <3 at full scale up to 500 V, decreasing linearly to <1.5 at 1000 V.
  • Page 42 Operating temperature: 41 °F to 104 °F (+5 °C to +40 °C) Storage temperature: -4 °F to 140 °F (-20 °C to +60 °C) Operating humidity: max. 80 % up to 87 °F (31 °C) decreasing linearly to 50 % at 104 °F (+40 °C). Storage humidity: <80 % Operating altitude: max.
  • Page 43 Feedback and Help Love it? Hate it? Let us know with a customer review. AmazonCommercial is committed to delivering customer-driven products that live up to your high standards. We encourage you to write a review sharing your experiences with the product. amazon.com/review/ review‑your‑purchases# amazon.com/gp/help/customer/...
  • Page 44 amazon.com/AmazonCommercial MADE IN CHINA HECHO EN CHINA FABRIQUÉ EN CHINE V01-10/19...
