- Page 1 Operating Instructions Translation of the original Angle tube strainer Type 7027 DN25 - DN150 with Slotted strainer insert Welding end S - S Threaded connection G - G Union connection K/M - G P D F • a k • 0 8 / 0 8 / 2 0 2 2 ENGLISH...
- Page 2 . k i e s e l m a n n . d e • i n f o @ k i e s e l m a n n . d e Copyright: © KIESELMANN FLUID PROCESS GROUP...
-
Page 3: Table Of Contents
KIESELMANN GmbH Table of Contents T a b l e o f C o n t e n t s 1 General informations .............................. 4 Informations for your safety ............................... 4 Marking of security instructions............................ 4 General designated use .............................. 4 Personnel ..................................... -
Page 4: General Informations
We will be at your disposal also after expiration of the warranty. In addition, you will also find all necessary instructions and spare part data for maintenance in this instruction manual. If you don't want to carry out the maintenance by yourself, our KIESELMANN - service team will naturally be at your disposal. -
Page 5: Modifications, Spare Parts, Accessories
KIESELMANN GmbH | Operating Instructions General informations | 1 1.5 Modifications, spare parts, accessories Unauthorized modifications, additions or conversions which affect the safety of the fitting are not permitted. Safety devices must not be bypassed, removed or made inactive. Only use original spare parts and accessories recommended by the manufacturer. -
Page 6: Safety Instructions
2 | Safety instructions Operating Instructions | KIESELMANN GmbH 2 S a f e t y i n s t r u c t i o n s 2.1 Intended use The elbow tube strainer is used to filter solid matter in liquids in the food and drinks industry. -
Page 7: Function And Operation
KIESELMANN GmbH | Operating Instructions Function and operation | 3 3 F u n c t i o n a n d o p e r a t i o n 3.1 Description of function The elbow tube strainer is used to filter solid matter in liquids. When the liquid flows through the strainer in the direction of the arrow (see figure), the solid matter is retained in the mesh bottom. -
Page 8: Technical Data
4 | Technical data Operating Instructions | KIESELMANN GmbH 4 T e c h n i c a l d a t a Model Angle tube strainer with slotted strainer insert • Screening direction from inside to outside • Screening direction from outside to inside... -
Page 9: Disassembly And Assembly | 5
KIESELMANN GmbH | Operating Instructions Disassembly and assembly | 5 5 D i s a s s e m b l y a n d a s s e m b l y 5.1 Disassembly Disassembly • Unscrew the slotted nut (1). -
Page 10: Drawings And Dimensions
6 | Drawings and dimensions Operating Instructions | KIESELMANN GmbH 6 D r a w i n g s a n d d i m e n s i o n s 6.1 Drawings Fig. 1Example drawing with welding connection... - Page 11 KIESELMANN GmbH | Operating Instructions Drawings and dimensions | 6 Angle tube strainer with threaded connection (G - G) Nominal size Ø D1 Ø D2 DN 25 Rd 52 x DN 32 Rd 58 x DN 40 Rd 65 x...
-
Page 12: Wearing Parts
7 | Wearing parts Operating Instructions | KIESELMANN GmbH 7 W e a r i n g p a r t s 7.1 Wearing parts list Nominal size EPDM HNBR Pos. 2 Pos. 6 Pos. 2 Pos. 6 Seal O-ring...
