- Page 1 World leaders in sample preparation Stomacher® 400 EVO User Manual...
- Page 2 A cut-off switch ensures the unit cannot work while the protective seal is open or the cover is missing. Stomacher® is a registered Trademark and may not be used without the express permission of Seward Ltd. www.seward.co.uk...
-
Page 3: Table Of Contents
World leaders in sample preparation Contents . Control panel.....................3 2. Operation....................4 3. Strip down....................5 4. Eco bag operation................... 7 5. Paddle reset....................8 6. Warnings/Cautions/Guidance..............9 7. Specifications...................11 8. Bags & Accessories.................12... -
Page 4: Control Panel
World leaders in sample preparation 1. Control panel 1. Start 2. Stop 3. Clear 4. Lock (Press 4 then 3 to open) 5. Adjust time (9 mins 55 secs in 5 second increments) 6. Adjust speed - Slow, Medium or Fast 7. Program store - 8 program slots Operation 1. -
Page 5: Operation
World leaders in sample preparation 2. Operation Drop Stomacher bag into the machine Press the start button... -
Page 6: Strip Down
World leaders in sample preparation 3. Strip down and clean Remove cover Cover CLEANING INSTRUCTIONS DISCONNECT from mains when cleaning DO NOT immerse or spray with water Wipe with damp cloth or anti bacterial wipes Use only non phenolic cleaning products Bag seal Strike plate Drip tray... - Page 7 World leaders in sample preparation Strip down and clean Remove bag seal Pull paddles off Pull drip tray off...
-
Page 8: Eco Bag Operation
World leaders in sample preparation 4. Eco bag operation Install small paddles Install bag seal Install bag platform and replace strike plate... -
Page 9: Paddle Reset
World leaders in sample preparation 5. Paddle reset If the paddle shafts prevent the strike plate being reattached then: Reattach the bag seal Reattach the cover Switch the machine off and on again at the mains filter outlet The machine will go through it’s set up processes including levelling the paddles Once it has done this, remove the cover, reattach the strike plate and replace the cover... -
Page 10: Warnings/Cautions/Guidance
PAT testing should be carried out by a competent person after installation. CALIBRATION Stomacher® is supplied fully calibrated by the manufacturer using equipment traceable to national standards. Calibration by the user directly following installation is not required. Following the expiry of the warranty period service packages are available from your authorised dealer or from... - Page 11 Processing time can be set up to 9 minutes 55 seconds in 5 second increments. Duty cycle 2 minutes with 45 seconds change over time at full speed. The Stomacher will not restart after a fault or power interruption. PERFORMANCE QUALIFICATION REMOVAL OF THE REAR COVER OF THE MACHINE BY UNQUALIFIED PERSONNEL SHOULD NEVER BE ATTEMPTED.
-
Page 12: Specifications
World leaders in sample preparation 7. Specifications STOMACHER 400 EVO Cat No. 0400/002 Dimensions H300mm x W310mm x D480mm Weight (unpacked) 18.8kg Supply voltage 100-240V Supply frequency 47-63Hz Max rated power 100W Plug top fuse F5A (UK chord set) Mains inlet fuse 1.0A, 250V, anti surge... -
Page 13: Bags & Accessories
World leaders in sample preparation 8. Bags & Accessories To get the optimum performance from the Stomacher® EVO 400 we recommend that only genuine Seward Stomacher® bags and accessories as shown in the table below, are used. Stomacher 400 Eco Bags and Accessories ®... - Page 14 Phone +44 (0)1903 524 600 Email info@seward.co.uk Seward Laboratory Systems Inc. (USA) 155 Keyland Court Bohemia NY 11716 Phone +1 631 337 1808 Email info@sewardusa.com FermionX GmbH Münstertäler Straße 12 Eschbach DE-79427 Germany Email info@seward.co.uk www.seward.co.uk Seward is a part of the FermionX Group.
