HP Compaq dc7100 SFF Supplementary Manual

HP Compaq Business Desktop
dc7100 Series Personal Computer
Illustrated Parts Map
Small Form Factor
System Unit
1 Computer cover assy with front bezel and no inserts
1 Computer cover assembly with front bezel and no
inserts (not painted, for Blue Angel use only)
2 Power supply, PFC
3 Chassis assembly
Cables
1 SATA hard drive cable, 24" (326965-007)
1 SATA hard drive cable, 18", (326965-002)
2 Power switch/LED cable - use switch holder
(370857-001)
3 Audio cable (CD to system board) (387527-001)
4 Front I/O device with cable
* Diskette drive cable (168999-006)
* UATA data cable, 8.6" (108950-054)
* Cable for PCI serial port card (use with 283984-005) 302652-005
* Y-adapter Zip drive cable assembly (use with
333504-005 and 326772-005)
* RJ-11 telephone cable (use with 361286-021 and
361287-021)
*Not shown
© 2005 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
All other product names mentioned herein may be
trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided "as is" without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
Standard and Optional Boards
1 System board with alcohol pad and thermal grease
2 Riser board (riser board is spared complete with
expansion/riser card holder and computer backwall)
378007-001
Memory Modules
367855-001
* 128 MB/400 MHz FSB
350030-001 * 256 MB/400 MHz FSB
not spared * 512 MB/400 MHz FSB
* 1.0 GB/400 MHZ FSB
Intel Pentium 4 Processors with alcohol pad and thermal grease
* 2.8 GHz\800 MHz FSB, 1MB cache
* 3.0 GHz\800 MHz FSB, 1MB cache
* 3.2 GHz\800 MHz FSB, 1MB cache
* 3.4 GHz\800 MHz FSB, 1MB cache
* 3.6 GHz\800 MHz FSB, 1MB cache
* 3.8 GHz\800 MHz FSB, 1MB cache
Intel Celeron D Processors with alcohol pad and thermal grease
* 2.66 GHz/533 MHz FSB, 256 KB cache
* 2.8 GHz/533 MHz FSB, 256 KB cache
Other Cards
* TPM security module
* PCI Modem, International, FH bracket
* PCI Modem, International, LP bracket
* Broadcom Gigabit NIC, FH bracket
* Broadcom Gigabit NIC, LP bracket
* Intel Gigabit NIC
* Intel Pro 10/100/1000 MT NIC, LP bracket
* FireWire 1394 card, 2 ext/1 int port, LP bracket
* FireWire 1394 card, 2 ext/1 int port, FH bracket
* PCI serial port card without internal cable/mtg bkt.
(see cable 302652-005)
368388-001
Wireless LAN adapters (802.11b)
346142-005
* 14 channel, LP bracket, antenna, Japan only
368387-001
* 14 channel, antenna
149806-005
* 14 channel, LP bracket, PCI, antenna
368386-001
Graphics Solutions
370499-001
* 4 Layer ADD2 Graphics, LP bracket
368389-001
* ATI RV370 VGA graphics, 64M, LP bracket
* ATI RV370 VGA graphics, 128M, LP bracket
374794-001
* Quadro NVS 280, 64M, PCI-E, SFF
*Not shown
198220-005
LP= Low profile mounting bracket
FH = Full height mounting bracket
Development Company, L.P.
warranty.
First Edition, September 2004
Second Edition, January 2005
Document Number
361291-002
361682-001
371921-001
335697-005
335698-005
335699-005
335700-005
367594-001
366643-001
366644-001
367415-001
367416-001
377483-001
375361-001
375362-001
366504-001
361286-021
361287-021
321793-005
367853-001
314901-005
338154-005
361551-001
361552-001
283984-005
359721-291
377160-001
377161-001
361264-001
364833-001
364834-001
377158-001
Mass Storage Devices (not illustrated)
40 GB\7200 RPM SATA hard drive
80 GB\7200 RPM SATA hard drive
120 GB\7200 RPM SATA hard drive
160 GB\7200 RPM SATA hard drive
Diskette drive with mounting screws
48X CD-ROM drive with mounting screws
52X CD-ROM drive
48X/32X/48X CD-RW drive
48X/32X/48X +16X DVD/CD-RW drive
8X DVD+R/RW drive
16X DVD+R/RW drive
16/40X DVD ROM drive
Zip 250 drive with mounting bracket
Zip 250 drive without mounting bracket
MultiBay Components
MultiBay drive adapter
Diskette drive, MultiBay
24X CD-ROM MultiBay drive
24X/24X/24X/8X CD-RW/DVD ROM MultiBay
8X/24X DVD-ROM MultiBay drive
Miscellaneous Parts
1 Front bezel assembly with no inserts
* 5.25" Bay bezel blank (carbonite)
2 CD drive bezel with diskette drive slot
2 CD drive bezel with diskette drive slot (Blue Angel)
3 CD drive bezel without diskette drive
4 CD drive bezel with Zip drive slot
4 CD drive bezel with Zip drive slot (Blue Angel)
5# Speaker with alcohol pad and thermal grease
6 Heatsink with thermal grease and alcohol pad
7 Chassis fan
* Heatsink duct baffle
8 Heatsink retention plate with thumbscrew
9 Solenoid lock with cable
* Hood sensor
* Mouse, 2-Button, PS/2 with scroll wheel
* Mouse, 2-Button, USB, optical with scroll wheel
* Mouse, 2-Button, USB, with scroll wheel
* Power switch holder with LED holders (use with
368387-001 switch)
* Drive Key, USB flash drive, 16 MB
* Drive Key, USB flash drive, 128 MB
* Drive Key, USB flash drive, 256 MB
* Drive Key II, USB flash drive, 256 MB
* Real-time-clock battery
* Port control cover
* Universal clamp lock without cable
* Universal clamp lock with cable
* Flying serial port with cable
Modem Cable Adapters (not illustrated) (use with 198220-005)
Belgium 316904-181 Israel
Cameroon 316904-AR1 Italy
Czech 234963-225 Netherlands
Denmark 316904-085 Norway
Germany 316904-045 Poland/Russia
Greece 316904-151 Sweden
Finland 316904-355 Switzerland
France 316904-051 Turkey
Hungary 234963-215 U.K.
*Not shown
#You must remove the heatsink before removing the speaker. When
reinstalling the heatsink, clean the mating surfaces between the heatsink
and the processor with the alcohol pad provided, and apply fresh thermal
grease.
Miscellaneous Screw Kit (not illustrated)
Miscellaneous screw kit, including:
M3 x 5mm, hitop (263585-001) 4 ea
#6-32 x .250, hitop (262508-001) 8 ea
#6-32 x .250, pan head (101517-067) 3 ea
#6-32 x .312, hitop (262508-002) 4 ea
#6-19 x .312, pan head (101346-068) 2 ea
#6-19 x .315, T15 head (331310-001) 2 ea
See next page for keyboard spares
365555-001
345713-005
365556-001
345712-005
333505-005
326773-005
333969-005
346788-005
359493-005
358688-005
381417-001
325313-005
333504-005
326772-005
335805-005
335169-005
325314-005
346789-005
325316-005
368086-001
335937-005
370501-001
374792-001
367852-001
370504-001
374793-001
368084-001
367857-001
366641-001
375514-001
370709-001
367854-001
267529-005
323614-005
323615-005
323617-005
370857-001
324780-005
349988-005
344249-005
372889-001
153099-001
367856-001
335808-005
335809-005
370500-001
316904-BB1
316904-065
316920-335
234963-095
316904-241
316904-105
304398-115
316904-141
158593-035
337237-005
