- Page 1 Aquatic Access Inc. ® Pool Lift Model IGMT Installation Guide Instruction Manual AquaticAccess.com 1921 Production Drive, Louisville, Kentucky 40299-2110 USA 800.325.5438 502.425.5817 Fax: 502.425.9607...
-
Page 3: Table Of Contents
Contact: Aquatic Access Inc. 1921 Production Drive Louisville, KY USA 40299-2110 Toll Free 800.325.5438 Phone 502.425.5187 Fax 502.502.425.5817 info@AquaticAccess.com Table of Contents Installation .......... -
Page 5: Installation
POOL LIFT MODEL IGMT INSTALLATION PLACEMENT OF SOCKET Install the socket for the IGMT pool lift at least 3’ from any pool corner to insure that there is enough room for the seat’s rotation and for the swimmer’s feet to clear the edge of the pool. - Page 6 ASSEMBLY OF LIFT Your IGMT pool lift has been assembled and tested in the factory before shipping. All parts are included in your shipment. Study the illustration of the lift in order to become familiar with its parts and their names.
-
Page 7: Assembly Of Lift
Carton #1: One long carton contains the lift cylinder, the valve, the socket, the socket cover, and possibly any accessories you ordered. Carton #2: The square box contains the seat assembly, and possibly any accessories. Carton #3: The mast is contained in the third package. After you have installed the socket and allowed the cement to cure overnight, insert the mast into the socket and check that it rotates freely. -
Page 8: Water Connection
Do not leave the water turned on when the lift is not in frequent use. Your IGMT pool lift operates using normal household water pressures of 55-65 PSI. No electricity is used. With sufficient water pressure and proper installation, the IGMT will lift a 300 lb. -
Page 9: Operation Of Lift
OPERATION OF THE LIFT Before operating the lift for the first time each day, turn on the water and run the lift up and completely down two or three times to purge air from the system. Always perform this operation before anyone is seated on the lift. -
Page 10: Disassembly Of Lift
cleaning with the pad, apply a good quality car wax to maintain its bright appearance. 4. If the lift is installed on a wooden deck, check the deck for any signs of decay. Replace any worn or damaged decking. DISASSEMBLY OF LIFT TOOLS REQUIRED: •... - Page 11 7. Remove the 1/2” top mounting bolt at the top of the cylinder and slide out the square key tube. Put a finger against the white piston to prevent its sliding out with the square key tube. If it does slide out, simply slide it back inside, being careful not to damage the black seal.
-
Page 12: Determining The Cause Of A Leak
Some leaks are caused by a seal developing a split, by hard water deposits on the seal of the inside cylinder wall, or simply by age or wear. Replacement seals are always available from Aquatic Access. CLEANING OF THE INSIDE OF THE CYLINDER To clean the inside of the cylinder, spray the inside with an all-purpose cleaner (Formula 409®... -
Page 13: Before Using The Lift Again
piston rod while it is being inserted. While holding horizontally, insert the bottom of the piston rod through the top of the cylinder, taking special care to gently insert the outer lip of the top seal so that it will not be cut or torn on the top of the piston rod. Insert so that the white piston is at least 6”... - Page 14 After normal use hours, turn off the water and lower the lift slightly to relieve the pressure on the piston and seals. If you have any questions or concerns regarding your IGMT Pool Lift, please call Aquatic Access Inc. at (800) 325.5438 (LIFT) or e-mail us at CustomerService@AquaticAccess.com Remember to send in your warranty card to Aquatic Access, 1921 Production Drive, Louisville, KY 40299-2110.
-
Page 15: Safety Procedures
SAFETY PROCEDURES Your IGMT model swimming pool lift is not a toy, but a tool that enables a physically challenged individual to access water activities. It is designed with safety as a primary concern, but exercise prudence when using the lift. With proper care and usage, your IGMT swimming pool lift will serve many years. - Page 16 If water pressure is very high, seat may You will fi nd a label similar in style move too quickly. Experiment to find the best settings to this one on every Aquatic Access for your water pressure. lift cylinder.
-
Page 17: Troubleshooting
TROUBLESHOOTING Symptom Cause Remedy Seat bounces on descent. Air in cylinder Purge air out by running the lift up and down several times. See operating label. Air in cylinder every day. Air entering the hose of Purge air out by runing cylinder if seat is left in the lift up and down two the up position and the... -
Page 18: Addendum: Technical Specifications Of Above-Ground Pool Lifts
Lift can be removed from socket and stored. Warranty Aquatic Access provides a 6-year limited warranty on all structural components of the Pool LIft IGMT, and a 2-year limited warranty on the valve, and all plastic and rubber components. IGMT Instructions Revised 9/16/13...
