- Page 1 Aquatic Access Inc. Pool Lift Model IGAT-180 AD Installation Guide Instruction Manual AquaticAccess.com 1921 Production Drive, Louisville, Kentucky 40299-2110 USA 800.325.5438 502.425.5817 Fax: 502.425.9607...
-
Page 3: Table Of Contents
Contact: Aquatic Access Inc. 1921 Production Drive Louisville, KY USA 40299-2110 Toll Free 800.325.5438 Phone 502.425.5817 Fax 502.425.9607 info@AquaticAccess.com Table of Contents Installation........... -
Page 4: Installation
Aquatic Access before installing the socket. SOCKET INSTALLATION Some states and localities require grounding of any metal object within five feet of the pool edge, but this is sometimes difficult in retrofit versus new installations. -
Page 5: Lift Assembly
If your static water pressure measurement is greater than 70 PSI, a reducer must be used between the water sources and the lift or damage to the lift may result. Purchase a reducer at your local plumbing supply store. Aquatic Access Inc. is not liable or responsible for damage caused by excessive water pressure. -
Page 6: Water Pressure Chart
RIGHT side of the socket. Height requirements for a standard IGAT-180 AD installation are illustrated on the right. Weight Lifted at Open Flow Water Pressure (Add approximately 10% for static water pressure) -
Page 7: Safety Procedures
Installation variable may also require a higher water pressure than listed. These may be the result of the cylinder not being installed and maintained in a vertical position. In true low water pressure situations, electric pumps are available to provide sufficient water pressure for up to a 350 lb. -
Page 9: Service And Maintenance
SERVICE AND MAINTENANCE INSPECTION OF LIFT The lift should be inspected each day before use. Check for hose damage, loose connections, any corrosion or damage to any parts of the lift routinely before using the lift with a swimmer. Perform a more thorough inspection of the lift every three months if the unit is in use all year round: 1. -
Page 10: Disassemby Of Lift And Replacement Of Piston Seal
DISASSEMBLY OF LIFT AND REPLACEMENT OF PISTON SEAL 1. Remove seat assembly from lift and disconnect water supply. Drain water from Lift. 2. Remove lift from socket. 3. Remove four bolts at top of lift. 4. Pull the piston rod assembly completely out of cylinder. -
Page 11: Replacement Of Piston And/Or Top Guide
REPLACEMENT OF THE PISTON AND/OR THE TOP GUIDE 1. Follow directions for Disassembly of Lift and Replacement of Piston Seal, steps 1-3. 2. Remove piston from end of piston rod using a rubber or plastic mallet. Go to step 5 of this section if you are only replacing the piston and not replacing the top guide. -
Page 12: Replacement Of Seat Shell
Detail Showing Rub Block between the Piston Rod and the Piston Frame Orientation of Rub Block for (A) IGAT-180 Above Deck and IGAT-180/135 Above Deck, (B) IGAT-180 Above Deck Opposite Turn and IGAT 180/135 Opposite Turn, (C) IGAT-90 Above Deck, and (D) IGAT-90 Above Deck Opposite Turn. REPLACEMENT OF SEAT SHELL 1. -
Page 13: Replacement Of Valve Assembly
Make a note of the serial number and date of purchase below. This information will be needed should you wish to contact Aquatic Access. You will find the serial number on the label on the cylinder portion of your lift. -
Page 14: Replacement Of Valve Stem
REPLACEMENT OF VALVE STEM 1. Disconnect the water supply. 2.Unscrew the brass nut that secures the valve to the valve bracket so that the valve drops down where it can be accessed. Set the nut aside for reassembly. Hold the valve so the tab that mates with the control rod 3. -
Page 15: Troubleshooting
TROUBLESHOOTING Symptom Cause Remedy Seat bounces on descent Air in the cylinder Purge air out by running the lift up and down two or three times. See operating label. Air in Cylinder Every Day Air entering hose or cylinder if Purge air out by running the seat is left in the down position lift up and down two or three... -
Page 16: Addendum: Technical Specifications
ADDENDUM: TECHNICAL SPECIFICATIONS: Model IGAT-180 AD United States Patent #5,465,433 LIFTING CAPACITY 350 lb. @ 55-65 PSI / 159 kg@ 3.8-4.5 Bars operating pressure (10% higher if static pressure) STATIC LOAD TEST 525 lb. / 238 kg OPERATION Standard city water pressure will generally provide plenty of pressure for normal operation.
