QTech Q71B Quick Start Manual

1200 bps fsk radio modem for datran base stations'

Q71B – 1200 bps FSK Radio Modem

for DATRAN Base Stations

Quick Start Guide

Table of Contents

Need help?

Do you have a question about the Q71B and is the answer not in the manual?

Page 1 Q71B – 1200 bps FSK Radio Modem for DATRAN Base Stations Quick Start Guide...
Page 2 The Q71B Base modem is used at DATRAN Base Stations and provides the communication interface to 1200bps analogue radio networks. The Q71B Base modem is a direct replacement for the previous Q70 modem and uses the default DATRAN comms port settings of 1200 baud, odd parity, 8 data bits,1 stop bit.
Page 3 Q71B Base Station Modem – Quick Start Guide – v1.2 – May 2022 Modem Connections Serial Connector – RJ45 The connector is labelled “Base PC” and connects to the DATRAN Base Station PC via the D9 female connector. Pin Number Function Data carrier detect (DCD) from modem to terminal.
Page 4 Pin Number Function Ground DC Supply 8 to 13.8V DC Not Connected The Q71B Base modem is supplied with a 12V DC plug pack with a pre terminated power connector. Status Indications LED status Indication PWR Power applied...
