- Page 1 MODEL： PAGE: PRODUCT ZT-809 1 OF 4 DESCRIPTION INSTRUCTION Wireless Camera ZT-809 WIRELESS CAMERAL USER’S MANUAL REVISIONS DESCRIPTION DATE DESIGN APPROVAL SHENZHEN ZHONGWANG ELECTRON CO.,LTD PAGES FILE ISSUE DATE CHECK TOTAL NUMBER DESIGN...
- Page 2 MODEL：ZT-809 PAGES: 2 OF 4 FILE NUMBER： Operation instruction 1. Connecting receive antenna (figure 1). 2. Connecting 12V direct current stabilizer (figure 2), pilot lamp lighting (figure 3). 3. Connecting the audio and video output with the input of monitor, the television should be in AV model.
- Page 3 MODEL：ZT-809 PAGES: 3 OF 4 FILE NUMBER： Technical data ITEM Transmitter Receiver Frequency 2.400~2.483GHz Electric power: DC 5V Output power 0±3dBm Video output: Power consumption current 100mA 250mA Suitable environmental temperature -20℃~+60℃ Effective range 30m(no obstacles) Including 1. Wireless camera 2.
- Page 4 MODEL：ZT-809 PAGES: 4 OF 4 FILE NUMBER： ⑤ ⑦ Wireless transmission ① ⑥ ③ ② ④ 2.4G Receiver TEL：+86-755-8336 1499 SHENZHEN ZHONGWANG ELECTRON CO.,LTD FAX：+86-755-8336 1433 http://www.ZTV.cc...
- Page 5 Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
