PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
RELATED DRAWING
NO MODIFICATIONS PERMITTED
WITHOUT THE APPROVAL OF
THE AUTHORIZED PERSON

.625 [15.88]
B
.98 [24.9]
MOUNTING STUD
MODEL 080A156
A
(SUPPLIED)
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.03
XXX ±.010

ANGLES 2 DEGREES
FILLETS AND RADII
.003 - .005
2
1
8 HEX ALLEN KEY REQUIRED
DIMENSIONS IN MILLIMETERS
BB
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.8
XX ± 0.25

ANGLES 2 DEGREES
FILLETS AND RADII
0.07 - 0.13
2
REV
E
1.58 [40.1]
9
16 [14] HEX
1/2-20 UNF - 2A
1/4-28 UNF - 2A
DRAWN CHECKED
5/15/15 ECB 5/15/15
OUTLINE DRAWING
MODEL 607 SERIES
ACCELEROMETER
1
REVISIONS
DESCRIPTION
ADDED RELATED BLOCK
MOLDED INTEGRAL CABLE
TERMINATING IN BLUNT CUT
10 FT [3 M] FROM APPLICATION
ENGINEER
GGS 5/15/15
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 2.5X
1
DIN
44208
B
WHITE: SIG/POWER
BLACK: GROUND
A
12441
SHEET 1 OF 1
